(1/2)
3-terminal Filters(SIP)
For Signal Line / Power Line
ZJK, ZJKD Series
FEATURES
• These SIP type EMC filters provide superior attenuation
capabilities from MF to VHF bands. They are particularly
effective in the microcomputer frequency range, where they
provide attenuation characteristics far superior to tantalum
capacitors.
• Its SIP type structure allows a wide variety of applications to IC
substates.
• The use of chip capacitors results in a high degree of
miniaturization, enabling these parts to be used in high-density
circuit board designs.
• Transfer molding is used to strengthen types -00 and -05.
APPLICATIONS
OA equipment (Computers, terminal equipment, word processors,
facsimiles, etc.)
FA equipment (Robots, NC manufacturing machineries, process
controllers, etc.)
AE equipment (Automotive engine control units, etc.)
HE equipment (Personal computers and micro computerized digi-
tal equipment)
SHAPES AND DIMENSIONS
ZJK-00-01
B
Conformity to RoHS Directive
CIRCUIT DIAGRAM
ZJK-05-01
B
ZJKD-15-01
B
1
A
A
4
A
C
C
1
E
F
2 3
4
C
1 2 3 4
D
1 2 3 4
D
E
F F F
2
3
E
D
F F F
G
F
Dimensions in mm
D
5+1, –2
5+0, –2
4.5±0.8
E
0.5× 0.25t
0.5× 0.25t
0.5× 0.3t
F
5±0.3
2.5±0.3
2.5±0.3
G
2.5±0.3
—
—
Part No.
A
B
C
∗
ZJK51R1-00-01, 51R5-00-01, 5103-00-01
17±1
5±1
8±1
ZJK51R1-05-01, 51R5-05-01, 5103-05-01
12.5max.
4.5max.
8max.
ZJKD51R1-15-01, 51R5-15-01, 5103-15-01
11.5max.
4.5max.
8max.
∗
The "-01" designation at the end of the product code indicates Lead-free compatible product.
• -00 and -05 types:Transfer molding, -15 type: Dip molding
ELECTRICAL CHARACTERISTICS
Part No.
Rated voltage Edc(V) max.
Rated current(A) max.
Withstand voltage Edc(V)
[Between terminal No.1 to 2, No.3 to 4/5s]
Insulation resistance(MΩ)min.[DC. 50V, 1 min]
DC resistance(Ω)max.[Between terminal No.1 to 4]
Operating temperature range(°C)
20dB
Attenuation frequency range
(MHz)[+5 to +35°C]
40dB
Interchangeable with existing products
ZJK51R1-00-01 ZJK51R5-00-01 ZJK5103-00-01 ZJK51R1-05-01
ZJKD51R1-15-01
50
50
50
50
0.1
0.5
3
0.1
125
100
11
–25 to +85
0.2 to 200
0.5 to 30
ZJK51R1-02
FP51R11
FP51R3
125
100
0.45
–25 to +85
1 to 200
2 to 30
ZJK51R5-01
ZJK51R5-02
125
100
0.02
–25 to +85
2 to 200
3 to 30
125
100
11
–25 to +85
0.7 to 300
1.5 to 80
ZJK51R5-05-01
ZJKD51R5-15-01
50
0.5
125
100
0.45
–25 to +85
4 to 300
7 to 80
ZJK5103-05-01
ZJKD5103-15-01
50
3
125
100
0.02
–25 to +85
7 to 300
15 to 80
• No application of this series component may exceed any of the above operational criteria.
• Conformity to RoHS Directive: This means that, in conformity with EU Directive 2002/95/EC, lead, cadmium, mercury, hexavalent chromium, and specific
bromine-based flame retardants, PBB and PBDE, have not been used, except for exempted applications.
• All specifications are subject to change without notice.
001-01 / 20060803 / e9644_zjk.fm
