ZL series
Subminiature toggle switches • metal bushing
DISTINCTIVE FEATURES
Ø 4.83 mm threaded bushing
Solder lug and straight PC terminals
ENVIRONMENTAL SPECIFICATIONS
• Operating temperature : -30 °C to +85 °C (-22 °F to +185 °F)
• Moisture : 21 days 95 % (NFC 20-603 - IEC 8-2-3)
ELECTRICAL SPECIFICATIONS
• Max. current/voltage rating with resistive load :
- gold plated contacts : 0.4 VA 20 V max. AC or DC
- silver plated contacts : 0.5 A 48 V max. AC or DC
• Minimum load : 10 mA 50 mV - 10 µA 5 VDC
• Contact resistance : 20 mΩ max.
• Insulation resistance : 1,000 MΩ min. at 500 VDC
• Dielectric strength: 1,000 Vrms 50 Hz min. between terminals and
frame, 500 Vrms 50 Hz min. between terminals
• Electrical life at full load :
Contacts
Number of cycles
2 positions
Gold plated
Silver plated
60,000
20,000
3 positions
30,000
10,000
GENERAL SPECIFICATIONS
• Strength of terminals : pull-out force 10 N max.
• Torque : 1 Nm max. applied between the 2 nuts
• Max. panel thickness : 1.5 mm (.059) with 2 nuts
The company reserves the right to change specifications without notice.
1
PANEL SWITCHES
71
-1
1
PANEL SWITCHES
ZL series
Subminiature toggle switches • metal bushing
MATERIALS
• Case : thermoplastic UL94-V0
• Actuator : brass, nickel plated
• Bushing : zamac, tin plated
• Contacts and terminals :
0
: brass, gold plated (standard)
1
: brass, silver plated
3
: brass, gold plated (1.27 micron gold)
• Terminal seal : epoxy
PANEL CUT-OUT
WITH FLAT
Ø
4.90
(.193
DIA)
Ø
4.90
(.193
DIA)
Ø
2.40
(.094
DIA)
4.39
(.172)
4.50
(.177)
6.10
(.240)
WITH KEYWAY
Ø
4.90
(.193
DIA)
Ø
4.90
(.193
DIA)
Ø
2.40
(.094
DIA)
SOLDERING
• Hand soldering : 280 °C (536 °F) max. for 5 seconds max.
• Wave soldering : 260 °C (500 °F) max. for 5 seconds max.
4.39
(.172)
0.76
(.030)
4.50
(.177)
0.60
(.024)
6.10
(.240)
TERMINALS
1.50
(.059)
0.75
(.029)
3.30
(.129)
1.50
(.059)
0.70
(.027)
Solder lug
S0
Straight
P0
ELECTRICAL FUNCTIONS
1
3
1 2 3
Function
1
Other function
2
ZL series
Subminiature toggle switches • metal bushing
BUILD YOUR PART NUMBER
BASIC PART NUMBER
ZL
SERIES
NUMBER OF POLES
ELECTRICAL FUNCTIONS
TERMINALS
3
Single pole
1
6
9
7
8
2
ON
ON
ON
MOM
ON
ON
-
-
OFF
OFF
OFF
-
OFF
ON
ON
MOM
MOM
MOM
S0
P0
Solder lug
Straight PC
OPTIONS
CONTACT AND TERMINAL MATERIALS
BUSHINGS
MODELS
0
1
3
Brass, gold plated
Brass, silver plated
Brass, gold plated
(1.27 micron gold)
01
02
Threaded, with flat
Threaded, with keyway
00
Standard model
ABOUT THIS SERIES
On the following pages, you will find successively basic part numbers of switches and options in the same order as in above chart.
Mounting accessories :
Standard hardware supplied with all models : 2 hex nuts 7 mm (.275) across flats P/N U5731, 1 locking ring
P/N U5821 (with keyway) or U5831 (with flat) and 1 lockwasher P/N U5841.
3
PANEL SWITCHES
PANEL SWITCHES
ZL series
Subminiature toggle switches • metal bushing
SOLDER LUG TERMINALS
III
ZL31S0
ZL36S0
ZL39S0
ZL37S0
ZL38S0
ZL32S0
ON
ON
ON
MOM
MOM
MOM
II
-
-
OFF
OFF
OFF
-
I
OFF
ON
ON
MOM
ON
5.00
(.196)
8.10
(.318)
FLAT
Ø
2.40
(.094
DIA)
III
II
24
I
5.60 5.50
(.220) (.216)
Ø
4.83-48UNS-2A
(10-48UNS-2A)
Ø
6.00
(.236
DIA)
EPOXY
1.50
(.059)
4.00 8.60
(.157) (.338)
3
2.54
(.100)
2
1
0.50
(.019)
ON
4.39
(.172)
STRAIGHT PC TERMINALS
III
ZL31P0
ZL36P0
ZL39P0
ZL37P0
ZL38P0
ZL32P0
ON
ON
ON
MOM
MOM
MOM
II
-
-
OFF
OFF
OFF
-
I
OFF
ON
ON
MOM
ON
ON
FLAT
Ø
2.40
(.094
DIA)
III
II
24
I
(10-48UNS-2A)
8.60
5.60 5.50
(.338) (.220) (.216)
Ø
4.83-48UNS-2A
Ø
6.00
(.236
DIA)
EPOXY
2.54
(.100)
2.54
(.100)
3 2 1
0.50
(.019)
8.10
(.318)
5.00
(.196)
Ø
1.10
(.043
DIA)
4.39
(.172)
Shown with threaded bushing code
01
CONTACT & TERMINAL
MATERIALS
BASIC P/N
00
0
1
3
Brass, gold plated (standard)
Brass, silver plated
Brass, gold plated (1.27 micron gold)
BUSHINGS
BASIC P/N
00
01
02
Threaded, with flat
Threaded, with keyway
4
3.30
(.129)
0.50
(.019)
2.80
(.110)
0.50
(.019)
