F-215
ET60S–00–24–04–L–VT1
(5,50 mm) .217"
(PWR)
(2,54 mm) .100"
(SIG)
ET60S–00–24–04–L–RT1
ET60S SERIES
EXTreme Ten60Power SOCKET
™
Mates with:
ET60T
ET60S
POWER
POS. RIGHT
SIGNAL
POSITIONS
POWER
POS. LEFT
PLATING
TAIL
GP
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?ET60S
Insulator Material:
Black LCP
Terminal Material:
Signal: Copper Alloy
Power: Copper Alloy
Plating:
Au or Sn over
50µ" (1,27 µm) Ni
Current Rating:
Power: 60 A max per blade
(2 pins powered @ 95°C;
30°C temperature rise)
Signal: 2.8 A max
(6 pins powered @ 95°C;
30°C temperature rise)
Operating Temp Range:
-40°C to +105°C
Voltage Rating:
250 V max
RoHS Compliant:
Yes
–00, –02,
–03, –04, –06
(2,54)
.100
–00,
–24
–00,
–02, –03,
–04, –06
(5,50)
.217
–L
= 10µ" (0,25 µm)
Gold on contact,
Matte Tin on tail
–VT1
= Vertical
Through-hole
(Use with (1,60 mm)
.062" thick card)
(2,54)
.100
(14,38)
.566
–RT1
= Right Angle
Through-hole
(Use with (1,60 mm)
.062" thick card)
D
(0,91)
.036
A
+
C
+
B
+ (13,50) .531
(7,50)
.295
–VP
E
(2,50)
.098
–VP
= Vertical
Press Fit
(Not available with
Right Angle)
Processing:
Lead–Free Solderable:
Yes
(14,38)
.566
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
D
(2,54)
.100
(3,00)
.118
ET60S–03–24–00–L–VT1
(5,17)
.204
(0,64)
.025
SQ
E
(0,91)
.036
(7,50)
.295
(2,50)
.098
POWER
A
POSITIONS (Right)
B
(Left)
(2,54)
.100
(2,54)
.100
(5,50)
.217
(10,00)
.394
–00
–02
–03
–04
(0,64) .025 SQ
A
+
C
+
B
+ (13,50) .531
–06
D
(11,00)
.433
(00,00)
.000
(13,00)
.512
(18,50)
.728
(24,00)
.945
(35,00)
1.378
SIGNAL
POSITIONS
(00,00)
.000
(13,00)
.512
(18,50)
.728
(24,00)
.945
(35,00)
1.378
C
(00,00)
.000
(23,26)
.916
–00
–24
(25,22)
.993
(3,33)
.131
DIA
TAIL
D
E
–VT1
(3,28) (2,60)
.129 .102
–RT1
(2,84) (2,84)
.112 .112
–VP
(3,28) (2,83)
.129 .111
(4,48)
.176
Note:
*EXTreme Ten60Power
™
is a trademark of Molex
Incorporated and is dual
sourced by Molex
®
Note:
Some lengths, styles
and options are non-standard,
non-returnable.
(5,81)
.229
(5,17)
.204
(5,50)
.217
(5,50)
.217
(3,00) .118
E
ET60S–03–24–00–L–RT1
WWW.SAMTEC.COM
Due to technical progress, all designs, specifications and components are subject to change without notice.
