F-211-1
MTMS–130–02–G–D–100
MTMS–110–02–G–D–100
(1,27mm) .050"
MTMS, HMTMS SERIES
MTMS–125–51–G–S–200
MODIFIED MICRO HEADER
SPECIFICATIONS
For complete specifications
see www.samtec.com?MTMS
or www.samtec.com?HMTMS
Insulator Material:
Black Liquid Crystal
Polymer
Terminal Material:
Phosphor Bronze
Plating:
Au or Sn over
50µ" (1,27µm) Ni
Current Rating:
1A
Operating Temp Range:
-55°C to + 105°C with Tin
-55°C to + 125°C with Gold
RoHS Compliant:
Yes
Mates with:
SMS, SLM, RSM
Board Stacking
BO AR D
SP AC E
OV ER AL L
PI N
(O AL )
PO ST
M AX
IN SE RT IO N
DE PT H
SO CK ET
PR OF ILE
BO DY
PR OF ILE
Position anywhere
in the body with
(3,05mm) .120"
minimum tail
TA IL
Single row
and double row
Ideal for board
stacking
applications
TYPE
STRIP
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
ROW
OPTION
POST
HEIGHT
OPTION
Note:
This Series is
non-standard, non-returnable.
01
thru
50
MTMS
= Modified Standard
–L
= 10µ" (0,25µm)
Gold on post,
Matte Tin on tail
–S
= Single
Row
–“XXX”
= “B”
Dimension
(Specify
Post Height
in inches
(0,13mm)
.005"
increments)
–“XXX”
= Polarized
Position
(Specify
position of
omitted pin)
–D
= Double
Row
Processing:
Lead-Free Solderable:
Yes
–G
= 10µ" (0,25µm)
Gold on post,
Gold flash on tail
Note:
Other Gold plating
options available.
Contact Samtec.
HMTMS
= Modified High Temp
(1,27) .050 x No. of Positions
(2,48)
.098
50
02
01
100
B
LEAD
STYLE
–01
–02
–25*
–51
–52
–53
–54
–55
–56
–57
–58
–59
–60
OAL
(Maximum
when C =
.120 (3,05) )
(11,43) .450 (5,84) .230
(8,13) .320
(8,38) .330
(2,54) .100
(3,18) .125
(10,41) .410 (4,83) .190
(10,80) .425 (5,21) .205
(12,83) .505 (7,24) .285
(14,10) .555 (8,51) .335
(15,49) .610 (9,91) .390
(15,88) .625 (10,29) .405
(16,51) .650 (10,92) .430
(17,91) .705 (12,32) .485
(19,18) .755 (13,59) .535
(20,96) .825 (15,37) .605
(2,54)
.100
01
99
(4,98)
.196
HMTMS –D
BODY DESIGN
B
(0,00) .000
MIN
(2,54)
.100
(0,46) .018 SQ
(1,27) .050 TYP
OAL
(3,05)
C
.120
MIN
*
(0,51)
.020
(0,51) .020 DIA
www.samtec.com
SINGLE ROW
DOUBLE ROW
Tail DIA is .020" (0,51mm) for min .120" (3,05mm).
Balance of tail is .018" (0,46mm) SQ.
*Style -25 tail C = (2,67) .105 min
is available.
WWW.SAMTEC.COM
