Sullins Headers
.100”[2.54mm] Contact Centers, Female Header
Dip Solder/Right Angle/SMT
SPECIFICATIONS
•
•
•
•
3 amp current rating per contact
UL Flammability Rating : 94V-O
Insulator : Nylon 6-T/Polyester
Contact Material : Phosphor Bronze
READOUT
ONE (1)
TWO (2)
TERMINATION TYPE
B
Sullins Headers
P/N
CODE
A
ROWS
1
TERM
STRAIGHT
STRAIGHT
A
.334 [8.50]
.334 [8.50]
B
.094 [2.50]
.197 [5.00]
TAIL
.125 [3.20]
.125 [3.20]
STRAIGHT
LFB
TAIL
2
B
P/N
CODE
A
ROWS
1
2
TERM
RIGHT ANGLE
RIGHT ANGLE
A
.334 [8.50]
.334 [8.50]
B
0.094 [2.40]
0.197 [5.00]
TAIL
.125 [3.15]
.125 [3.15]
RIGHT ANGLE
LGB
LJB
TAIL
B
P/N
CODE
A
ROWS
1
2
TERM
SMT
SMT
ENTRY
A
B
TAIL
SMT
KFX
KFM
TOP ENTRY .279 [7.10] .098 [2.50] .169 [4.30]
TOP ENTRY .279 [7.10] .197 [5.00] .265 [6.80]
TAIL
Refer to
Mounting Style
MOUNTING STYLE
Pin 1
Pin 1
No Mounting
Standard (N)
One Row SMT,
Pin 1 Left (C)
One Row SMT,
Pin 1 Right (D)
Two Row SMT,
Without Guide Post (S)
Guide Post
Two Row SMT,
With Guide Post (P)
80
www.sullinscorp.com
|
760-744-0125
|
toll-free 888-774-3100
|
fax 760-744-6081
|
info@sullinscorp.com
Sullins Headers
.100”[2.54mm] Contact Centers, Female Header
Dip Solder/Right Angle/SMT
PART NUMBER CODING
PP
P C 36 1 LFB N - RC
RoHS Compliant
Consult Factory For Modifications
PLASTIC HOUSING
PP = Polyester/Phosphor Bronze (Thru Hole Only)
NP = Nylon 6-T/Phosphor Bronze (SMT or Thru Hole)
CONTACT FINISH - RoHS Compliant
P = Gold Flash Overall
T = 100% Pure Tin Overall
CONTACT CENTERS
C = .100” [2.54mm]
NUMBER OF POSITIONS
01 Thru 40
(e.g. 36 position has 72 contacts)
NUMBER OF ROWS (Opposite Page)
1 = 1 Row
2 = 2 Row
MOUNTING STYLE
N = No Mounting
C = SMT, One Row, pin 1 Left
D = SMT, One Row, pin 1 Right
P = SMT, 2 Row with guide pins
S = SMT, 2 Row without guide pins
TERMINATION TYPE
LFB = Straight
LGB = 1 Row Right Angle
LJB = 2 Row Right Angle
KFX = 1 Row SMT (NP SERIES ONLY)
KFM = 2 Row SMT (NP SERIES ONLY)
DIMENSIONS
Dimensions in [ ] are in millimeters, all others are in inches.
Number
of
Positions
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
B
.238 [6.05]
INSERTION DEPTH
.100[2.54]
A
.050
[12.70]
.027x.015
[.69x.38]
SINGLE READOUT,
STRAIGHT TAIL SHOWN
B
.238 [6.05]
INSERTION DEPTH
.100[2.54]
A
.050[12.70]
.027x.015
[.69x.38]
DUAL READOUT,
STRAIGHT TAIL SHOWN
A
A
.100[2.54]
.100
[2.54]
.040[1.02]
.100
[2.54]
.040[1.02]
Recommended P.C.Board
Hole Layout
Number of
Contacts
1
2
Row
Row
1
2
2
4
3
6
4
8
5
10
6
12
7
14
8
16
9
18
10
20
11
22
12
24
13
26
14
28
15
30
16
32
17
34
18
36
19
38
20
40
21
42
22
44
23
46
24
48
25
50
26
52
27
54
28
56
29
58
30
60
31
62
32
64
33
66
34
68
35
70
36
72
37
74
38
76
39
78
40
80
DImension
A
Inches
.100
.200
.300
.400
.500
.600
.700
.800
.900
1.000
1.100
1.200
1.300
1.400
1.500
1.600
1.700
1.800
1.900
2.000
2.100
2.200
2.300
2.400
2.500
2.600
2.700
2.800
2.900
3.000
3.100
3.200
3.300
3.400
3.500
3.600
3.700
3.800
3.900
[mm]
2.54
5.08
7.62
10.16
12.70
15.24
17.78
20.32
22.86
25.40
27.94
30.48
33.02
35.56
38.10
40.64
43.18
45.72
48.26
50.80
53.34
55.88
58.42
60.96
63.50
66.04
68.58
71.12
73.66
76.20
78.74
81.28
83.82
86.36
88.90
91.44
93.98
96.52
99.06
Dimension
B
Inches
.220
.320
.420
.520
.620
.720
.820
.920
1.020
1.120
1.220
1.320
1.420
1.520
1.620
1.720
1.820
1.920
2.020
2.120
2.220
2.320
2.420
2.520
2.620
2.720
2.820
2.920
3.020
3.120
3.220
3.320
3.420
3.520
3.620
3.720
3.820
3.920
4.020
[mm]
5.58
8.12
10.66
13.20
15.74
18.28
20.82
23.36
25.90
28.44
30.98
33.52
36.06
38.60
41.14
43.68
46.22
48.76
51.30
53.84
56.38
58.92
61.46
64.00
66.54
69.08
71.62
74.16
76.70
79.24
81.78
84.32
86.86
89.40
91.94
94.48
97.02
99.56
102.10
