(1/2)
001-01 / 20030824 / e9713_acm.fm
EMC Components
ACM Series
Common Mode Choke Coils for DC Power Line
SMD
PRODUCT IDENTIFICATION
ACM 0706 -102 - 2PT - T
(1)
(2)
(3) (4) (5)
(1) Series
(2) Dimensions L×W
0706: 7.0×6.0mm
(3) Impedance[at 100MHz]
801: 800Ω
102: 1000Ω
(4) Number of lines
2P:2-line
(5)Packaging style
T: ø180mm reel taping
TL: ø330mm reel taping
FEATURES
• A chip-type common mode filter for high current applications.
Common mode impedance surpasses 600 to 1000Ω at 100MHz.
Noise is greatly suppressed.
• Capable of handling the highest current (up to 6A) of any chip-
type common mode filter.
• This series of choke coils handles a range of current settings
from 1 to 6A.
• Height and size have been considered, resulting in a compact
and light-weight choke coil. Applicable for the miniaturization
required to reduce the size and weight of portable equipment.
APPLICATIONS
Used for power line noise suppression for any electronic devices.
Used to counter adapter/battery line noise for relatively large elec-
tronic devices such as notebook PCs, stand-alone word proces-
sors, etc.
SHAPES AND DIMENSIONS
ACM3225, 4532 TYPES
1
2
4
CIRCUIT DIAGRAM
ACM0706, 0908, 1110 TYPES
Marking
W
1
2
4
4
3
3
1
Insulation
resin
T
L
Terminal
electrode
Ferrite
2
3
W
L
D1
D1
D2
D2
Terminal
electrode
Ferrite
Type
ACM3225
ACM4532
L
3.2±0.2
4.5±0.2
W
2.5±0.2
3.2±0.2
T
2.3 max.
3.0 max.
D1
0.7
1
D2
0.65
1
D
D
D
D
Dimensions in mm
Type
ACM0706
ACM0908
ACM1110
L
7±0.2
9±0.2
11±0.2
W
6±0.2
8±0.2
10±0.2
T
4.5 max.
4.5 max.
5.9 max.
T
Dimensions in mm
D
2
3
3.5
RECOMMENDED PC BOARD PATTERN
REFLOW SOLDERING
c
a
b
a
Dimensions in mm
Type
ACM3225
ACM4532
ACM0706
ACM0908
ACM1110
c
d
a
1.5
1.8
3.5
4.5
5
b
1.6
2.3
2
2
3
c
1.4
1.75
2.5
3.5
5
d
1.1
1.1
2
2
3
• All specifications are subject to change without notice.
(2/2)
001-01 / 20030824 / e9713_acm.fm
EMC Components
ACM Series
Common Mode Choke Coils for DC Power Line
SMD
ELECTRICAL CHARACTERISTICS
Part No.
ACM3225-601-2P-X
∗
ACM4532-601-2P-X
ACM4532-801-2P-X
ACM0706-102-2P-X
ACM0908-801-2P-X
ACM1110-102-2P-X
∗
Impedance
(Ω)typ.[100MHz]
600
600
800
1000
800
1000
DC resistance
(mΩ)max. (1 line)
200
100
100
12
6
4.5
Rated voltage
Edc(V)max.
50
50
50
50
50
50
Rated current
Idc(A)max.
1.0
1.5
1.0
4.0
5.0
6.0
X:Packaging style(T:Taping[ø180mm reel], TL:Taping[ø330mm reel], only TL is available for ACM1110-102-2P)
TYPICAL ELECTRICAL CHARACTERISTICS
IMPEDANCE vs. FREQUENCY CHARACTERISTICS
ACM3225-601-2P
ACM4532-601-2P
1000
Common mode
MEASURING CIRCUITS
ACM4532-801-2P
1000
Common mode
Common mode
1000
Common mode
Impedance(
Ω
)
Impedance(
Ω
)
Impedance(
Ω
)
100
100
100
HP4291A
10
Differential mode
10
Differential mode
10
Differential mode
10
100
1000
Frequency (MHz)
Differential mode
1
1
10
100
Frequency (MHz)
1000
1
1
1
1
10
100
Frequency (MHz)
1000
HP4291A
ACM0706-102-2P
10000
ACM0908-801-2P
10000
ACM1110-102-2P
10000
Impedance(
Ω
)
Impedance(
Ω
)
Common mode
100
Differential mode
100
Differential mode
Impedance(
Ω
)
1000
Common mode
1000
1000
Common mode
100
Differential mode
10
10
10
1
1
10
100
Frequency (MHz)
1000
1
1
10
100
Frequency (MHz)
1000
1
1
10
100
Frequency (MHz)
1000
• All specifications are subject to change without notice.
