Specification Control Drawing
100G1131
Issue 9
9th January 2015
Page 1 of 2
Page 2 is for internal use only
THREE CONDUCTOR CABLE, HALOGEN FREE INSULATION, SHIELDED AND HALOGEN FREE JACKETED,
750/1300 VOLT AC, 105°C
The complete requirements for procuring the wire described herein shall consist of this document.
Shield -
Tin Coated Copper, Optimised
Component wire -
100G0111
Jacket - Black
®
Zerohal
Part
Description
Nominal
Shield
Cross Equivalent Size
Sectional AWG
(mm)
Area
Size
(mm²)
0.15
0.25
0.40
0.50
0.60
0.75
1.00
1.20
1.50
2.00
2.50
3.00
4.00
26
24
22
-
20
-
18
16
15
14
13
12
-
0.10
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
0.13
Jacket Thickness Overall Diameter Maximum
(mm)
(mm)
Weight
(kg/ km)
Min.
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
0.22
Nom.
0.30
0.30
0.30
0.30
0.30
0.30
0.30
0.30
0.30
0.30
0.30
0.30
0.30
Nom.
3.26
3.60
4.04
4.23
4.40
4.70
4.93
5.25
5.65
6.26
6.70
7.15
7.83
Max.
3.39
3.77
4.20
4.38
4.55
4.86
5.09
5.41
5.85
6.53
6.85
7.31
7.98
20.0
26.9
34.0
39.5
43.6
49.3
56.2
67.4
76.5
95.4
111
131
173
100G1131-0.15-*/*/*-*
100G1131-0.25-*/*/*-*
100G1131-0.40-*/*/*-*
100G1131-0.50-*/*/*-*
100G1131-0.60-*/*/*-*
100G1131-0.75-*/*/*-*
100G1131-1.00-*/*/*-*
100G1131-1.20-*/*/*-*
100G1131-1.50-*/*/*-*
100G1131-2.00-*/*/*-*
100G1131-2.50-*/*/*-*
100G1131-3.00-*/*/*-*
100G1131-4.00-*/*/*-*
'Zerohal' is a registered trademark of Tyco Electronics Corporation
COLOUR CODE:
The '*' in the part description shall be replaced by a standard colour code designator
in accordance with Mil Std 681.
e.g. 100G1131-1.00-2/6/9-0, cores red, blue and white, jacket black.
PERFORMANCE
REQUIREMENTS
To be tested to and meet the requirements of the issue in effect of TE Specification WCD2015,
except that the minimum jacket elongation at break shall be 125%.
This product will have components available in the full colour range and may be marked
or unmarked in accordance with the order.
Standard outer jacket black but other colours available on request.
APPROVAL:
Tyco Electronics UK Ltd
Faraday Road
Dorcan
SWINDON
SN3 5HH
Tel: +44 (0)1793 528171
Fax: +44 (0)1793 572516
Electronic sign off - no signatures will appear.
