3-1419128-3

Description
POWER/SIGNAL RELAY, SPST, MOMENTARY, 0.05A (COIL), 9VDC (COIL), 450mW (COIL), 5A (CONTACT), 28VDC (CONTACT), THROUGH HOLE-STRAIGHT MOUNT, ROHS COMPLIANT
CategoryMechanical and electronic products    relay
File Size140KB，2 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric Compare View All

3-1419128-3 Overview

POWER/SIGNAL RELAY, SPST, MOMENTARY, 0.05A (COIL), 9VDC (COIL), 450mW (COIL), 5A (CONTACT), 28VDC (CONTACT), THROUGH HOLE-STRAIGHT MOUNT, ROHS COMPLIANT

3-1419128-3 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerTE Connectivity
package instructionROHS COMPLIANT
Reach Compliance Codecompliant
ECCN codeEAR99
Samacsys DescriptionOJE-SS-109DM,000
body width10.2 mm
body height14.7 mm
Body length or diameter18.2 mm
Maximum coil current (DC)0.05 A
Coil operating voltage (DC)6.3 V
Coil power450 mW
Coil release voltage (DC)0.45 V
Coil resistance180 Ω
Maximum coil voltage (DC)9 V
Coil/Input Power TypeDC
Contact (AC) maximum rated R load5A@250VAC
Maximum contact current (AC)5 A
Maximum contact current (DC)5 A
Contact (DC) maximum rated R load5A@28VDC
Maximum contact voltage (AC)250 V
Maximum contact voltage (DC)28 V
Contact/Output Power TypeAC/DC
Electrical life100000 Cycle(s)
Installation featuresTHROUGH HOLE-STRAIGHT MOUNT
operating hours10 ms
Maximum operating temperature60 °C
Minimum operating temperature-30 °C
physical size18.2mm x 10.2mm x 14.7mm
GuidelineCSA; TUV; UL; VDE
Relay actionMOMENTARY
Relay functionSPST
Relay typePOWER/SIGNAL RELAY
release time4 ms
surface mountNO
Termination typeSOLDER

Preview

Download Datasheet
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Relays > Product Feature Selector > Product Details
OJE­SS­109DM,000 Product Details
Industrial Relays (General Purpose)

Always EU RoHS compliant but not ELV Compliant
 (
Statement of
Compliance
)
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
OJE­SS­109DM,000
(3­1419128­3)
TE Internal Number: 3­1419128­3
Product Highlights:
OJ/OJE Series
Contact ­ Current Class = 2A to 5A Class, Less Than
16A
Contact ­ Rated Current = 5 A
Terminal Type = PCB­THT
Contact ­ Arrangement = 1 Form A (NO)
View all Features
 Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
OJE­SS­DM CUSTOMER DRAWING (PDF, English)
RELAY, OEG, OJE SERIES (PDF, Japanese)
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Additional Information:
Product Line Information
Additional Product Images:
Schematic
Wiring Diagram
PCB Layout (Bottom Surface)
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Electrical Characteristics:
Contact ­ Current Class = 2A to 5A Class, Less Than 16A
Contact ­ Rated Current (A) = 5
Contact ­ Limiting Continuous Current (A) = 5
Contact ­ Limiting Making Current (A) = 5
Contact ­ Limiting Breaking Current (A) = 5
Insulation ­ Initial Dielectric Between Coil/Contact Class = 2500V to
3000V Class
Insulation ­ Initial Dielectric Between Open Contacts (V rms) = 750
Insulation ­ Initial Dielectric Between Contacts and Coil (V rms) =
3000
Contact ­ Rated Voltage (VAC) = 277
Contact ­ Rated Voltage (VDC) = 30
Contact ­ Switching Voltage Max. (VAC) = 277
Contact ­ Switching Voltage Max. (VDC) = 30
Contact ­ Limiting Short­Time Current (A) = 5
Contact ­ Switching Recommended Load, Min. = 100mA at 5V
Coil ­ Rated Voltage (VDC) = 9
Coil ­ Resistance (Ω) = 180
Coil ­ Rated Power, DC (mW) = 450
Coil ­ Rated Power Class = 400mW to 500mW Class
Insulation ­ Creepage Class = 3mm to 5.5mm Class
Insulation ­ Clearance Class = 0 to 2.5mm Class
Insulation ­ Special Features = Tracking Index of Relay Base PTI250
Dimensions:
Mechanical ­ Length Class = 16mm to 20mm Class
Length (mm [in]) = 18.20 [0.717]
Mechanical ­ Width Class = 10mm to 12mm Class
Body Features:
Mount Type = PCB
Weight (g [oz]) = 9.00 [0.318]
Contact Features:
Terminal Type = PCB­THT
Contact Material = Ag
Contact ­ Number of Poles = 1
Configuration Features:
Contact ­ Arrangement = 1 Form A (NO)
Coil ­ Magnetic System = Monostable, DC
Coil ­ Special Features = UL Coil Insulation Class B
Industry Standards:
RoHS/ELV Compliance = RoHS/Not ELV Compliant
Lead Free Solder Processes = Wave solder capable to 240°C, Wave
solder capable to 260°C, Wave solder capable to 265°C
RoHS/ELV Compliance History = Always was RoHS not ELV compliant
Approved/Registered Standards = CQC, cULus, TUEV, VDE
Environmental:
Environmental ­ Category of Protection = RTII
Environmental ­ Ambient Temperature, Max. (°C [°F]) = 85 [185]
Environmental ­ Ambient Temperature Class = 70°C to 85°C Class
Packaging Features:
Packaging Method = Tray
Other:

3-1419128-3 Related Products

3-1419128-3 OJE-SS-109DM.000
Description POWER/SIGNAL RELAY, SPST, MOMENTARY, 0.05A (COIL), 9VDC (COIL), 450mW (COIL), 5A (CONTACT), 28VDC (CONTACT), THROUGH HOLE-STRAIGHT MOUNT, ROHS COMPLIANT POWER/SIGNAL RELAY, SPST, MOMENTARY, 0.05A (COIL), 9VDC (COIL), 450mW (COIL), 5A (CONTACT), 30VDC (CONTACT), THROUGH HOLE-STRAIGHT MOUNT
Maker TE Connectivity TE Connectivity
Reach Compliance Code compliant unknown
ECCN code EAR99 EAR99
body width 10.2 mm 10.2 mm
body height 14.7 mm 14.7 mm
Body length or diameter 18.2 mm 18.2 mm
Maximum coil current (DC) 0.05 A 0.05 A
Coil operating voltage (DC) 6.3 V 6.3 V
Coil power 450 mW 450 mW
Coil release voltage (DC) 0.45 V 0.45 V
Coil resistance 180 Ω 180 Ω
Maximum coil voltage (DC) 9 V 9 V
Coil/Input Power Type DC DC
Contact (AC) maximum rated R load 5A@250VAC 5A@265VAC
Maximum contact current (AC) 5 A 5 A
Maximum contact current (DC) 5 A 5 A
Contact (DC) maximum rated R load 5A@28VDC 5A@30VDC
Maximum contact voltage (AC) 250 V 265 V
Maximum contact voltage (DC) 28 V 30 V
Contact/Output Power Type AC/DC AC/DC
Electrical life 100000 Cycle(s) 100000 Cycle(s)
Installation features THROUGH HOLE-STRAIGHT MOUNT THROUGH HOLE-STRAIGHT MOUNT
operating hours 10 ms 10 ms
Maximum operating temperature 60 °C 60 °C
Minimum operating temperature -30 °C -30 °C
physical size 18.2mm x 10.2mm x 14.7mm 18.2mm x 10.2mm x 14.7mm
Guideline CSA; TUV; UL; VDE CSA; TUV; UL; VDE
Relay action MOMENTARY MOMENTARY
Relay function SPST SPST
Relay type POWER/SIGNAL RELAY POWER/SIGNAL RELAY
release time 4 ms 4 ms
surface mount NO NO
Termination type SOLDER SOLDER
