51118526 Product Details
AMPLATCH Ribbon Cable Connectors
Always EU RoHS/ELV Compliant
(
Statement of Compliance
)
Product Highlights:
AMPLATCH Product Line
WiretoBoard
Applies To Printed Circuit Board
Connector Assembly
Connector Style = Plug
View all Features
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
51118526
TE Internal Number: 51118526
Superseded
Search for Replacement Parts
View 3D PDF
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files: (CAD Format & Compression Information)
2D Drawing (DXF, Version B)
3D Model (IGES, Version B)
3D Model (STEP, Version B)
Additional Information:
Product Line Information
Related Products:
Tooling
Add to My Part List
Request Sample
Find Similar Products
Buy Product
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Line = AMPLATCH
Connector Type = Connector Assembly
PCB Mounting Orientation = Vertical
PCB Mount Retention = With
PCB Mount Retention Type = Kinked Leg(s)
PCB Mount Alignment = Without
CSA File Number = LR 7189
Electrical Characteristics:
Contact Rated Current (A) = 1
Operating Voltage Reference = AC
Operating Voltage (VAC) = 250
UL Voltage Rating (VAC) = 250
Termination Features:
Wire/Cable Size (AWG) = 26 – 30
Wire/Cable Size (mm²) = 0.051 – 0.15
Wire/Cable Size (CMA) = 101 – 296
Termination Method to PC Board = Through Hole Solder
Termination Method to Wire/Cable = Insulation Displacement Crimp
(IDC)
Dimensions:
Tail Length (mm [in]) = 2.79 [0.109]
PCB Thickness, Recommended (mm [in]) = 1.57 [0.062]
Length (XAxis) (mm [in]) = 37.59 [1.4799]
Housing Features:
Connector Style = Plug
Centerline (mm [in]) = 2.54 [0.100]
Housing Color = Black
Configuration Features:
Number of Positions = 26
Number of Rows = 2
Tail Orientation = Inline
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Wave solder capable to 260°C, Wave
solder capable to 240°C, Wave solder capable to 265°C
RoHS/ELV Compliance History = Always was RoHS compliant
Agency/Standard = UL, CSA
UL Rating = Recognized
UL File Number = E28476
UL Flammability Rating = UL 94V0
Environmental:
Operating Temperature (°C [°F]) = 65 – +105 [85 – +221]
Conditions for Usage:
Applies To = Printed Circuit Board
Accepts Wire Insulation Diameter, Range (mm [in]) = 0.81 – 1.07
[0.032 – 0.042]
Width (ZAxis) (mm [in]) = 7.06 [0.278]
Profile Height (YAxis) (mm [in]) = 6.43 [0.253]
Body Features:
RowtoRow Spacing (mm [in]) = 2.54 [0.100]
Operation/Application:
Application Use = WiretoBoard
Contact Transmits (Typical Application) = Signal (Data)
Packaging Features:
Packaging Method = Tube
Contact Features:
Contact Type = Pin
Other:
Contact Base Material = Phosphor Bronze
Series = AMPLATCH DIP Plug
Contact Plating, Mating Area, Material = Gold or Palladium Nickel or
Brand = AMP
Performance Based
Contact Plating, Mating Area, Thickness (µm [μin]) = 2.54 [100]
Contact Plating, Termination Area, Material = Tin
Contact Plating, Termination Area, Thickness (µm [μin]) = 2.54 [100]
