5150500303 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> 5150500303

5150500303: DescriptionRESISTOR, POTENTIOMETER, CARBON FILM, 1 TURN(S), 0.2W, 470ohm, ROHS COMPLIANT; CategoryPassive components The resistor; File Size113KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

5150500303 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	5150500303	-	-	View	Buy Now

5150500303 Overview

RESISTOR, POTENTIOMETER, CARBON FILM, 1 TURN(S), 0.2W, 470ohm, ROHS COMPLIANT

5150500303 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	TE Connectivity
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
Actuator direction	VERTICAL
Actuator type	THUMB WHEEL
gang number	1
Installation features	THROUGH HOLE MOUNT
Number of terminals	3
number of turns	1
Package shape	RECTANGULAR PACKAGE
Rated power dissipation(P)	0.2 W
resistance	470 Ω
resistance law	LINEAR
Resistor type	POTENTIOMETER
surface mount	NO
technology	CARBON FILM
Terminal shape	FLAT
Tolerance	20%

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Resistors

Product Feature Selector

> Product Details

5150500303 Product Details

Live Product Chat

Variable Resistors

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

5150500303

(1624191-2)

T E I nternal N umber: 1 6 2 4 1 9 1 - 2

Product Highlights:

Variable Resistor

Resistor Type = Potentiometer

Resistance Selection = <1K ?

Resistance = 470 ?

Power Rating = .20 W

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

Spindle Operated Potentiometers - Type 51 Series - T...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = Variable Resistor

Resistor Type

= Potentiometer

Resistance (?)

= 470

Element

= C arbon

Sealed

= No

Mount Angle

= Horizontal

Termination Type

= PC B Terminations

C omment = Suited for Plugin Accessory

Electrical Characteristics:

Resistance Selection (?) = <1K

Power Rating (W)

= 0.20

Tolerance (%)

= 20

Termination Related Features:

Termination Post Orientation

= In Line

Body Related Features:

Series

= 51

Package, C omponent Size

= 12.5 x 15.8

Configuration Related Features:

Sections

= Single

Adjustment Location

= Top

Adjustment Style

= Spindle (Sold Separately)

Operating Function

= Single Turn

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Conditions for Usage:

Temperature C oefficient (ppm/?C )

= 500

Other:

Brand = C itec

Additional Information:

Product Line Information
