Destruction: 10 to 55 to 10 Hz, 0.75-mm single amplitude
Destruction: 1,000 m/s
2
Operating: –30°C to 80°C (with no icing)
Storage: –30°C to 100°C (with no icing)
45% to 85%
G3H: UL508, CSA C22.2 No. 14, EN60947-4-3
G3HD: UL508, CSA C22.2 No. 14, EN60950-1
Emission: EN55011 Group 1 Class B
Immunity: EN61000-6-2
Approx. 50 g
1,500 VAC, 50/60 Hz for 1 min
Engineering Data
Load Current vs.
Ambient Temperature
Characteristics
G3H-203SN-VD/203S-VD/203SLN-VD/
203SL-VD
G3HD-X03SN-VD/X03S-VD
G3HD-202SN-VD
Load current (A)
4
G3H-203SN-VD, G3H-203S-VD
G3H-203SLN-VD, G3H-203SL-VD
G3HD-X03SN-VD, G3HD-X03S-VD
3
2.5
2
G3HD-202SN-VD
1.5
1
10
20
One Cycle Surge Current: Non-repetitive
Non-repetitive (Keep the inrush current to half the rated value if it occurs repetitively.)
G3H-203SN-VD/203S-VD/203SLN-VD/
G3H-203SL-VD
G3HD-X03SN-VD/X03S-VD
G3HD-202SN-VD
Inrush current (A, Peak)
50
Inrush current (A)
30
28
26
24
22
20
18
16
14
12
10
8
6
4
2
0
10
G3HD-X03SN-VD
G3HD-X03S-VD
G3HD-202SN-VD
40
30
0
−30 −
20
0
20
40
60
80
100
0
10
30 50 100 200
500 1,000
5,000
20 30
50 70 100
200 300 500 1,000 2,000
Energized time (ms)
Ambient temperature (°C)
Energized time (ms)
3
G3H/G3HD
Dimensions
Note:
All units are in millimeters unless otherwise indicated.
Terminal Arrangement/
Internal Connections
(Bottom View)
1
28 max.
3
5
21.5 max.
36.5 max.
42.5 max.
−
7
−
Input voltage
Load
2
4(+)
6(−)
8
+
+
Load
Load power
supply
(+)
(
(−)
)
Input
Note:
1. The plus and minus symbols
shown in the parentheses
are for DC loads.
2. The coil has no polarity.
Safety Precautions
■
Precautions for Correct Use
Please observe the following precautions to prevent failure to
operate, malfunction, or undesirable effect on product performance.
EMC Directive Compliance
1.
AC-switching models comply with EMC Directives under the
following conditions ("-VD" models only).
Less than 3 m
Load
Input
G3H-VD
Output
Connection
The SSR for DC switching use can connect to a load regardless of
the polarity of the positive and negative output terminals.
Varistor: 470 V, 0.6 W
Film capacitor: 1
µF,
250 VAC
Varistor
Film Capacitor
Close Mounting of Multiple Relays
If multiple Relays are mounted side by side, be aware that the outer
wall of each SSR works as a heat sink.
The SSR casing serves to dissipate heat. Install the Relays so that
they are adequately ventilated. If poor ventilation is unavoidable,
reduce the load current by half.
•
Connect a varistor between the output terminals.
•
Connect a film capacitor to the load power supply.
•
The input cable must be less than 3 m.
2.
DC-switching models comply with EMC Directives under the
following conditions ("-VD" models only).
Less than 10 m
Load
Input
G3HD-VD
Output
Protective Terminal
No overvoltage absorption element is built in. (The G3HD-202SN
has a built-in varistor.) Be sure to connect an overvoltage absorption
element when using the G3H or G3HD with an inductive load.
•
The input cable must be less than 10 m.
ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.
To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527.
In the interest of product improvement, specifications are subject to change without notice.
4
