MELF
MELF
Resistors
Resistors
WRM Series
WRM Series
High reliability
High reliability handling capability
Predictable pulse
Predictabledown to 0.1% capability
Tolerances pulse handling
Tolerances to 5 ppm/°C
TCR down down to 0.1%
TCR down to 5 ppm/°C
Welwyn Components
·
·
·
·
Electrical Data
WRM 0102
Power rating at 70°C
Resistance range
Limiting element voltage
TCR
Resistance tolerance
Standard values
Thermal impedance
Ambient temperature range
Insulation resistance
k/W
°C
ohms
250
watts
ohms
volts
ppm/°C
%
0.125
4R7 - 110K
150
50
1
WRM 0204
0.25
R22 – 5M1
200
5,10,15, 25, 50, 100
E24 & E96
200
-55 to +125
>10
10
140
WRM 0207
0.4
R16 – 10 M
250
15, 25, 50, 100
0.1, 0.25, 0.5, 1.0, 2, 5
Physical Data
Dimensions (mm) and weight (g)
Type
WRM 0102
WRM 0204
WRM 0207
L
max
2.2
3.7
6.1
D
max
1.35
1.55
2.4
D
1
max
1.3
1.55
2.4
K
min
0.3
0.5
0.5
Weight
0.01
0.02
0.08
L
D
1
L
1
K
D
Construction
A metal film is deposited onto a high dissipation ceramic
former to which tin plated teminating caps are fitted.
The resistor is adjusted to value by a helical cut in the film
and the body is protected by a lacquer coating.
Terminations
Material
Plated steel cap.
Solderability
The pure tin finish produces ageing free
contacts on which low melting solders can
be used. Dipped area shall be covered with
a smooth and bright solder coating after
3 seconds immersion at 215°C.
Marking
Resistance values are colour coded with four bands,
three indicating value and one indicating the multiplier.
(Note this describes standard marking, but certain values
may still be supplied with the addition of a tolerance band
following the multiplier.)
Solvent Resistance
The body protection and marking are resistant to all normal
industrial cleaning solvents suitable for printed circuit boards.
General Note
General Note
Welwyn Components reserves to right changes changes in product specification without liability.
TT electronics reserves the right themake to make in product specification without notice or notice or liability.
All information is subject to Welwyn’s own data and is considered accurate at at time of going to print.
All information is subject to TT electronics’ own data and is considered accuratetime of going to print.
