SURFACE MOUNT TRANSFORMERS
TLF Series: Line Filter
(Common Mode Choke)
FEATURES
•Miniature surface mount component
•For EMI countermeasures at
•High performance ferrite with superior signal lines of microcomputer,
frequency characteristics
peripheral devices, etc.
SCHEMATIC DIAGRAMS
Type A
1
3
ELECTRICAL CHARACTERISTICS
DC
Rated
Insulation
Inductance (uH)
Resistance Current
Resistance
0.1V, 1KHZ
Part Number
Style
L
L1 - L2
(One Line)
( mW )
ONE LINE L3 - L4
( mA ) (mW) /100VDC
L1, L2
L1 - L2
TLF0602-820Y
82±50%
4 max
200 max.
300
10 max.
A
TLF0602-181Y
180±50% 8 max
250 max
300
10 max.
A
TLF0602-331Y
330±50% 10 max 300 max.
300
10 max.
A
Hi-Pot test (N1-N2): 250VAC / 60Hz, 3mA, 1 minute
TLF0905-100Y
10±30%
1 max
90 max
1500
10 max.
A
TLF0905-470Y
47±30%
3 max
255 max
940
10 max
A
+50%
TLF0905-251Y
250
-30%
30 max 110 max
1430
10 max.
A
+50%
TLF0905-501Y
500
-30%
30 max 150 max
1200
10 max.
A
+50%
TLF0905-102Y
1000
-30%
35 max 300 max
850
10 max.
A
+50%
TLF0905-202Y
2000
-30%
55 max 470 max
680
10 max
A
Hi-Pot test (N1-N2): 700VAC / 60Hz, 3mA, 1 minute
TLF1306 - 350Y*
35.0±35% 4.0 max
35 max
2700
10 max.
B
TLF1306 - 600Y*
60.0±35% 5.0 max
65 max
2000
10 max.
B
TLF1306 - 101Y** 100±35% 15 max.
100 max.
700
10 max.
C
TLF1306 - 251Y** 250±35% 25 max.
150 max.
600
10 max.
C
TLF1306 - 501Y** 500±35% 35 max.
200 max.
500
10 max.
C
TLF1306 - 102Y** 1000±35% 45 max.
300 max.
400
10 max.
C
TLF1306 - 332Y** 3300±35% 85 max.
510 max.
300
10 max.
B
Hi-Pot Test: 700 Vac/60 Hz, 3mA, 1 minute
Note: L, L1, L2: Inductance rating of each winding
L1-L2, L3-L4 Max difference between windings.
* Temperature Rise: 45°C max. at rated current
** Temperature Rise: 20°C max at rated current.
N1
2
N2
4
“•”: Polarity
Type B
1
4
N1
8
N2
5
“•”: Polarity
Type C
1
2
3
4
N1
8
N2 N1
7
6
N2
5
“•”: Polarity
DIMENSIONS
(mm)
TLF0602 Size
3.75
max
1.8
max
6.5
max
1.25
±0.1
2.5
±0.2
0.8
max
PC Board Pattern
3.4
REF
3
3
2
2
1
1
4
4
.7
max
2.5
1.25
0.85
1.0
1.5
6.6
5
5
TLF0905 Size
9.5
max
5.0
±0.3
0.8
±0.2
1.4min
5.7
Ref
1.8
max
2.54
±0.2
1.0
±0.1
PC Board Pattern
6.5
max
1.2
2.54
2.0
2.0
mm
9.5
TLF1306 Size
13.5 max
5.75
±0.3
11.1±0.3
0.7
±0.1
2.5
±0.2
9.5±0.3
PC Board Pattern
4
5
10.5
max
2.5
2.2
1.0
10.3
1
3.0
8
14.7
RFE International
• Tel:(949) 833-1988 • Fax:(949) 833-1788 • E-Mail Sales@rfeinc.com
C4D01
REV 2001
