CYStech Electronics Corp.
N-CHANNEL MOSFET
Spec. No. : C403A3
Issued Date : 2006.07.14
Revised Date :
Page No. : 1/6
MTN7000ZA3
Description
The MTN7000ZA3 is a N-channel enhancement-mode MOSFET.
Features
• Low on-resistance
• High ESD
• High speed switching
• Low-voltage drive(4V)
• Easily designed drive circuits
• Easy to use in parallel
• Pb-free package
Symbol
MTN7000ZA3
D
Outline
TO-92
G
S
G：Gate
S：Source
D：Drain
SGD
MTN7000ZA3
CYStek Product Specification
CYStech Electronics Corp.
Absolute Maximum Ratings
(Ta=25°C)
Parameter
Drain-Source Voltage
Gate-Source Voltage
Drain Current
Drain Reverse Current
Continuous
Pulsed
Continuous
Pulsed
Spec. No. : C403A3
Issued Date : 2006.07.14
Revised Date :
Page No. : 2/6
Symbol
V
DSS
V
GSS
I
D
I
DP
I
DR
I
DRP
P
D
R
th,JA
T
CH
T
stg
ESD susceptibility
Total Power Dissipation
Thermal Resistance, Junction to Ambient
Channel Temperature
Storage Temperature
Note : *1. Pulse Width
≤
300µs, Duty cycle
≤2%
*2. Human body model, 1.5kΩ in series with 100pF
Limits
60
±20
300
700
300
700
2000
400
312.5
+150
-55~+150
*1
*1
*2
Unit
V
V
mA
mA
mA
mA
V
mW
°C/W
°C
°C
Electrical Characteristics
(Ta=25°C)
Symbol
Min.
Typ.
Max.
BV
DSS*
60
-
-
V
GS(th)
1
-
2.5
I
GSS
-
-
±10
I
DSS
-
-
1
-
1.8
2.3
R
DS(ON)*
-
1.25
1.7
G
FS
200
-
-
V
SD
-
-
1.4
C
iss
-
60
-
C
oss
-
25
-
C
rss
-
22
-
Unit
V
V
µA
µA
Ω
mS
V
pF
Test Conditions
V
GS
=0, I
D
=10µA
V
DS
=V
GS
, I
D
=1mA
V
GS
=±20V, V
DS
=0
V
DS
=60V, V
GS
=0
I
D
=300mA, V
GS
=4V
I
D
=300mA, V
GS
=10V
V
DS
=10V, I
D
=300mA
I
SD
=115mA, V
GS
=0
V
DS
=25V, V
GS
=0, f=1MHz
*Pulse Test : Pulse Width
≤380µs,
Duty Cycle≤2%
Ordering Information
Device
MTN7000ZA3
Package
TO-92
(Pb-free)
Shipping
2000 pcs / Tape & Reel
Marking
N7000
MTN7000ZA3
CYStek Product Specification
CYStech Electronics Corp.
Characteristic Curves
Typical Output Characteristics
1.2
1
Drain Current - ID(A)
0.8
0.6
0.4
3V
6V
4V
Spec. No. : C403A3
Issued Date : 2006.07.14
Revised Date :
Page No. : 3/6
Typical Transfer Characteristics
0.7
0.6
Drain Current -ID(A)
0.5
0.4
0.3
0.2
0.1
VGS=2.2V
VDS=10V
3.5V
0.2
0
0
1
2
3
Drain-Source Voltage -VDS(V)
4
0
0
1
2
3
Gate-Source Voltage-VGS(V)
4
Static Drain-Source On-State resistance vs Drain Current
Static Drain-Source On-State resistance vs Drain Current
10
Static Drain-Source On-State
Resistance-RDS(on)(Ω)
Static Drain-Source On-State
Resistance-RDS(on)(Ω)
VGS=4V
10
1
1
VGS=4V
VGS=10V
0.1
0.01
0.1
Drain Current-ID(A)
1
0.1
0.01
0.1
Drain Current-ID(A)
Reverse Drain Current vs Source-Drain Voltage
10
1
Static Drain-Source On-State Resistance vs Gate-Source
Voltage
7
Static Drain-Source On-State
Resistance-RDS(ON)(Ω)
6
5
4
3
2
1
0
0
5
10
15
20
Gate-Source Voltage-VGS(V)
25
150mA
ID=300mA
Reverse Drain Current -IDR(A)
1
0.1
0.01
VGS=0V
0.001
0
0.2
0.4
0.6
0.8
Source-Drain Voltage-VSD(V)
1
MTN7000ZA3
CYStek Product Specification
CYStech Electronics Corp.
Characteristic Curves(Cont.)
Reverse Drain Current vs Source-Drain Voltage
10
Spec. No. : C403A3
Issued Date : 2006.07.14
Revised Date :
Page No. : 4/6
Power Derating Curve
500
Reverse Drain Current -IDR(A)
1
VGS=0V
Power Dissipation---PD(mW)
400
300
200
100
0
0.1
VGS=10V
0.01
0.001
0
0.2
0.4
0.6
0.8
Source-Drain Voltage-VSD(V)
1
0
50
100
150
Ambient Temperature---TA(℃)
200
MTN7000ZA3
CYStek Product Specification
CYStech Electronics Corp.
TO-92 Taping Outline
Spec. No. : C403A3
Issued Date : 2006.07.14
Revised Date :
Page No. : 5/6
DIM
A
D
D1
D2
E
F1,F2
F1,F2
H
H1
H2
H2A
H3
H4
L
L1
P
P1
P2
T
T1
T2
W
W1
-
Item
Component body height
Tape Feed Diameter
Lead Diameter
Component Body Diameter
Component Lead Pitch
F1-F2
Height Of Seating Plane
Feed Hole Location
Front To Rear Deflection
Deflection Left Or Right
Component Height
Feed Hole To Bottom Of Component
Lead Length After Component Removal
Lead Wire Enclosure
Feed Hole Pitch
Center Of Seating Plane Location
4 Feed Hole Pitch
Over All Tape Thickness
Total Taped Package Thickness
Carrier Tape Thickness
Tape Width
Adhesive Tape Width
20 pcs Pitch
Millimeters
Min.
4.33
3.80
0.36
4.33
1.5
2.40
-
15.50
8.50
-
-
-
-
-
2.50
12.50
5.95
50.30
-
-
0.36
17.50
5.00
253
Max.
4.83
4.20
0.53
4.83
2.0
2.90
±0.3
16.50
9.50
1
1
27
21
11
-
12.90
6.75
51.30
0.55
1.42
0.68
19.00
7.00
255
MTN7000ZA3
CYStek Product Specification
