KBPC8 SERIES
SINGLE-PHASE SILICON BRIDGE
CHENG- YI
ELECTRONIC
VOLTAGE RANGE
50 TO 1000 VOLTS
CURRENT
8.0 Amperes
FEATURES
Surge overload rating-125 amperese peak
Low forward voltage drop
Small size, simple installation
Silver plated copper leads
Mounting position:Any
Plastic material has UL flammability
classification 94V-0
UL recognized file # E149311
Lead solderable per MIL-STD-202
method 208
Electrically isolated base 1800Volts
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
0
C ambient temperature unless otherwise specified.
For capacitive load, derate current by 20%.
KBPC8005
KBPC801
KBPC802
KBPC804
KBPC806
KBPC808
KBPC810
UNITS
V
V
V
A
A
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Bridge Input Voltage
Maximum DC Blocking Voltage
Maximum Average Forward
Output Current
Peak Forward Surge Current
8.3 ms single half sine-wave
superimposed on rated load
Maximum DC Forward Voltage
drop per element at 3.0A DC
Maximum DC Reverse Current at rated
@ TA=25 C
DC Blocking Voltage Per Element
@ TA=100 C
0
0
V
RRM
V
RMS
V
DC
50
35
60
100
70
100
200
140
200
400
280
400
8.0
6.0
600
420
600
800
560
800
1000
700
1000
@
TA=50 C*
@
TA=50 C**
0
0
V
(AV)
I
FSM
150
A
V
F
I
R
I
2
t
R
JC
T
J
T
STG
1.1
10
1
64
6
0
V
A
mA
AS
C/W
0
2
I
2
t Rating for fusing(t<8.3ms)
Typical Thermal Resistance
Operating Temperature Range
Storage Temperature Range
-55 to +125
-55 to +150
C
C
0
KBPC8 SERIES
SINGLE-PHASE SILICON BRIDGE
CHENG- YI
ELECTRONIC
RATING AND CHARACTERISTICS CURVES
KBPC8 SERIES
Fig.1
-
MAXIMUM FORWARD SURGE CURRENT
250
Fig.2
-
DERATING CURVE FOR
OUTPUT RECTIFIED CURRENT
AVERAGE FORWARD OUTPUT CURRENT
AMPERES
PEAK FORWARD SURGE CURRENT
AMPERES
10
200
8
150
HEAT-SINK
MOUNTING TC
6
100
4
50
2
0
1
10
100
0
50
100
150
NUMBER OF CYCLES AT 60 Hz
TEMPERATURE,
0
C
Fig.3 - TYPICAL FORWARD
CHARACTERISTICS
Fig.4
-
TYPICAL REVERSE
100
CHARACTERISTICS
10
INSTANTANEOUS FORWARD CURRENT. AMPERES
INSTANTANEOUS REVERSE
CURRENT, MICROAMPERES
10
1.0
1.0
0.1
.1
.01
0
.01
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
20
40
60
80
100
120
140
PERCENT OF RATED PEAK
REVERSE VOLTAGE
INSTANTANEOUS FORWARD VOLT
AGE, VOLTS
