LIGITEK ELECTRONICS CO.,LTD.
Property of Ligitek Only
SQUARE WITH 4LEADS TYPE LED LAMPS
Pb
Lead-Free Parts
LUR9653H-30D-WJ
DATA SHEET
DOC. NO : QW0905-LUR9653H-30D-WJ
REV.
DATE
:
:
D
13 - Oct. - 2006
LIGITEK ELECTRONICS CO.,LTD.
Property of Ligitek Only
PART NO. LUR9653H-30D-WJ
Page 1/6
Package Dimensions
C1.25
R0.7
CATHODE
7.62
±
0.5
ANODE
7.62
±
0.5
ψ
3.0
1.5
2.5
±
0.5
4.7
±
0.5
0.5
0.4
1.55
3.5
±
0.5
5.08
±
0.3
5.08
Note : 1.All dimension are in millimeter tolerance is
±
0.25mm unless otherwise noted.
2.Specifications are subject to change without notice.
Directivity Radiation
0
°
-30
°
30
°
-60
°
60
°
100% 75% 50%
25%
0
25%
50% 75% 100%
LIGITEK ELECTRONICS CO.,LTD.
Property of Ligitek Only
PART NO. LUR9653H-30D-WJ
Page 2/6
Absolute Maximum Ratings at Ta=25
℃
Ratings
Parameter
Symbol
UR(H)
Forward Current
Peak Forward Current
Duty 1/10@10KHz
Power Dissipation
Reverse Current @5V
Electrostatic Discharge( * )
Operating Temperature
Storage Temperature
I
F
I
FP
PD
Ir
ESD
T
opr
Tstg
70
100
130
10
2000
-40 ~ +85
-40 ~ +100
mA
mA
mW
UNIT
μ
A
V
℃
℃
Static Electricity or power surge will
the
Use of
anti-electrosatic
*
glove is recommended when handingdamageLED.LED.devices, a conductive wrist band or must be properly
these
All
equipment and machinery
grounded.
Typical Electrical & Optical Characteristics (Ta=25
℃
)
COLOR
PART NO
MATERIAL
Emitted
LUR9653H-30D-WJ
AlGaInP/GaP
Red
Forward
Dominant
Spectral
voltage
wave
halfwidth
length
△λ
nm
@70mA(V)
λ
Dnm
Luminous
Flux
@70mA(lm)
Viewing
angle
2
θ
1/2
(deg)
Lens
Water Clear
Min. Max. Min. Typ.
630
20
2.3
3.2
3.5
5.8
84
Note : 1.The forward voltage data did not including
±
0.1V testing tolerance.
2. The luminous intensity data did not including
±
15% testing tolerance.
LIGITEK ELECTRONICS CO.,LTD.
Property of Ligitek Only
PART NO. LUR9653H-30D-WJ
Page 3/6
Initial Electrical/Optical Characteristics(at 70mA)
Luminous Flux Ranks
Item
Rank F12
Luminous
Flux
Rank F13
Rank F14
Rank F15
* Luminous Flux Measurement allowance is
±10%
Min.
2.9
3.8
4.9
6.3
Max.
3.8
4.9
6.3
8.2
Unit
lm
LIGITEK ELECTRONICS CO.,LTD.
Property of Ligitek Only
PART NO. LUR9653H-30D-WJ
Page 4/6
Typical Electro-Optical Characteristics Curve
UR(H) CHIP
Fig.1 Forward current vs. Forward Voltage
1000
Fig.2 Relative Intensity vs. Forward Current
3.5
Forward Current(mA)
100
10
Relative Intensity
Normalize @20mA
3.0
2.5
2.0
1.5
1.0
0.5
0.0
1
01
1.0
1.5
2.0
2.5
3.0
1
10
100
1000
Forward Voltage(V)
Fig.3 Forward Voltage vs. Temperature
1.2
Forward Current(mA)
Fig.4 Relative Intensity vs. Temperature
Forward Voltage@20mA
Normalize @25
℃
Relative Intensity@20mA
Normalize @25
℃
-40
-20
0
20
40
60
80
100
3.0
2.5
2.0
1.5
1.0
0.5
0.0
-40
-20
0
20
40
60
80
100
1.1
1.0
0.9
0.8
Ambient Temperature(
℃
)
Ambient Temperature(
℃
)
Fig.5 Relative Intensity vs. Wavelength
Relative Intensity@20mA
1.0
0.5
0.0
550
600
650
700
Wavelength (nm)
