WIMA MKP 4
Metallized Polypropylene (PP) Capacitors
PCM 7.5 mm to 52.5 mm
D
Special Features
˜
˜
˜
˜
High volume/capacitance ratio
Self-healing
Very low dissipation factor
Negative capacitance change
versus temperature
˜
Very low dielectric absorption
˜
According to RoHS 2011/65/EU
Electrical Data
Capacitance range:
0.01
mF
to 150
mF
(E12-values on request)
Rated voltages:
100 VDC, 250 VDC, 400 VDC,
630 VDC, 1000 VDC
Capacitance tolerances:
± 20%, ± 10%, ± 5%
Operating temperature range:
–55+ C to +100+ C
Climatic test category:
55/100/56 in accordance with IEC
Insulation resistance
at +20+ C:
C
T
0.33
m
F:
U
1 x 10
5
M
¸
(mean value: 5 x 10
5
M
¸
)
C
Q
0.33
m
F:
U
30 000 sec (M
¸
x
m
F)
(mean value: 100 000 sec)
Measuring voltage: 100 V/1 min.
Dissipation factors
at + 20) C:
tan
d
T
10 x 10
-4
at 1 kHz (C
T
50
mF)
tan
d
T
15 x 10
-4
at 1 kHz (C > 50
mF)
Maximum pulse rise time:
Capacitance
mF
0.01 ... 0.022
0.033 ... 0.068
0.1 ... 0.22
0.33 ... 0.68
1.0 ... 2.2
3.3 ... 4.7
6.8 ... 10
15
... 33
47 ... 150
100 VDC
450
250
150
100
75
60
40
35
10
Test specifications:
In accordance with IEC 60384-16
Test voltage:
1.6 U
r
, 2 sec.
Dielectric absorption:
0.05 %
Voltage derating:
A voltage derating factor of 1.35 % per K
must be applied from +85+ C for DC
voltages and from +75+ C for AC
voltages.
Reliability:
Operational life
Q
300 000 hours
Failure rate
2 fit (0.5 x U
r
and 40) C)
Specific dissipation:
Box size*
Specific dissipation in Watts per K
W x H x L in mm above the ambient temperature
35 x 50 x 57
0.132
45 x 55 x 57
0.164
45 x 65 x 57
0.184
* other box sizes see page 10.
Typical Applications
For high frequency applications e.g.
˜
Sample and hold
˜
Timing
˜
Oscillating circuits
˜
High frequency coupling and
decoupling
Construction
Dielectric:
Polypropylene (PP) film
Capacitor electrodes:
Vacuum-deposited
Internal construction:
MKP 4: 63 VAC, 160 VAC, 200 VAC, 280 VAC
Plastic film
Vacuum-deposited
electrode
Metal contact layer
(schoopage)
Terminating wire
max. pulse rise time V/msec at T
A
< 40) C
250 VDC
400 VDC
630 VDC
1000 VDC
450
250
150
100
100
100
50
50
13
450
300
200
150
100
100
60
18
–
500
350
250
200
150
120
85
36
–
550
400
300
200
150
140
100
–
–
MKP 4: 400 VAC
Plastic film
Vacuum-deposited
electrode
Metal contact layer
(schoopage)
Terminating wire
for pulses equal to the rated voltage
Mechanical Tests
Pull test on pins:
d
T
0.8
l
: 10 N in direction of pins
d > 0.8
l
: 20 N in direction of pins
according to IEC 60068-2-21
Vibration:
6 hours at 10 ... 2000 Hz and 0.75 mm
displacement amplitude or 10 g in
accordance with IEC 60068-2-6
Low air density:
1kPa = 10 mbar in accordance with
IEC 60068-2-13
Bump test:
4000 bumps at 390 m/sec
2
in accordance with IEC 60068-2-29
Packing
Available taped and reeled up to and
including case size 15 x 26 x 31.5 /
PCM 27.5 mm.
Detailed taping information and graphs
at the end of the catalogue.
Encapsulation:
Solvent-resistant, flame-retardant plastic
case with epoxy resin seal, UL 94 V-0
Terminations:
Tinned wire.
Marking:
Colour: Red. Marking: Black.
Epoxy resin seal: Red
For further details and graphs please
refer to Technical Information.
02.14
51
WIMA MKP 4
Continuation
D
General Data
Capacitance
0.01
0.015
0.022
0.033
m
F
„
„
„
0.047 „
0.068 „
0.1
m
F
0.15 „
0.22 „
0.33 „
0.47 „
0.68 „
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
m
F
„
„
„
„
„
m
F
„
„
„
„
„
m
F
„
W
3
3
3
3
4
4
4
4
4
4.5
4
5
5
6
5
6
7
8
6
7
10.5
11
11
13
13
15
13
17
19
20
24
35
40
35
45
45
H
8.5
8.5
8.5
8.5
9
9
9
9
9
9.5
9
10.5
11
12
11
12.5
14
15
15
16.5
19
21
21
24
24
26
24
29
32
39.5
45.5
50
55
50
55
65
100 VDC/63 VAC*
Part number
L PCM**
7.5
MKP4D021002B_ _ _ _ _ _
10
7.5
MKP4D021502B_ _ _ _ _ _
10
7.5
MKP4D022202B_ _ _ _ _ _
10
7.5
MKP4D023302B_ _ _ _ _ _
10
13
10
MKP4D023303C_ _ _ _ _ _
7.5
MKP4D024702C_ _ _ _ _ _
10
13
10
MKP4D024703C_ _ _ _ _ _
7.5
MKP4D026802C_ _ _ _ _ _
10
13
10
MKP4D026803C_ _ _ _ _ _
7.5
MKP4D031002D_ _ _ _ _ _
10.3
13
10
MKP4D031003C_ _ _ _ _ _
7.5
MKP4D031502E_ _ _ _ _ _
10.3
13
10
MKP4D031503F_ _ _ _ _ _
13
10
MKP4D032203G_ _ _ _ _ _
18
15
MKP4D032204B_ _ _ _ _ _
18
15
MKP4D033304C_ _ _ _ _ _
18
15
MKP4D034704D_ _ _ _ _ _
18
15
MKP4D036804F_ _ _ _ _ _
26.5 22.5 MKP4D036805B_ _ _ _ _ _
26.5 22.5 MKP4D041005D_ _ _ _ _ _
26.5 22.5 MKP4D041505G_ _ _ _ _ _
26.5 22.5 MKP4D042205I_ _ _ _ _ _
31.5 27.5 MKP4D042206B_ _ _ _ _ _
31.5 27.5 MKP4D043306D_ _ _ _ _ _
31.5 27.5 MKP4D044706D_ _ _ _ _ _
31.5 27.5 MKP4D046806F_ _ _ _ _ _
41.5 37.5 MKP4D046807C_ _ _ _ _ _
41.5 37.5 MKP4D051007E_ _ _ _ _ _
41.5 37.5 MKP4D051507F_ _ _ _ _ _
41.5 37.5 MKP4D052207G_ _ _ _ _ _
41.5 37.5 MKP4D053307H_ _ _ _ _ _
41.5 37.5 MKP4D054707J_ _ _ _ _ _
41.5 37.5 MKP4D056807K_ _ _ _ _ _
57
52.5 MKP4D056809F_ _ _ _ _ _
57
52.5 MKP4D061009H_ _ _ _ _ _
57
52.5 MKP4D061509J_ _ _ _ _ _
W
3
3
3
3
4
4
4
4
4
4.5
4
5
5
6
5
6
7
8
6
7
10.5
11
11
13
15
17
15
19
20
24
35
35
45
H
8.5
8.5
8.5
8.5
9
9
9
9
9
9.5
9
10.5
11
12
11
12.5
14
15
15
16.5
19
21
21
24
26
29
26
32
39.5
45.5
50
50
65
250 VDC/160 VAC*
L PCM**
Part number
7.5
MKP4F021002B_ _ _ _ _ _
10
7.5
MKP4F021502B_ _ _ _ _ _
10
7.5
MKP4F022202B_ _ _ _ _ _
10
7.5
MKP4F023302B_ _ _ _ _ _
10
13
10
MKP4F023303C_ _ _ _ _ _
7.5
MKP4F024702C_ _ _ _ _ _
10
13
10
MKP4F024703C_ _ _ _ _ _
7.5
MKP4F026802C_ _ _ _ _ _
10
13
10
MKP4F026803C_ _ _ _ _ _
7.5
MKP4F031002D_ _ _ _ _ _
10.3
13
10
MKP4F031003C_ _ _ _ _ _
7.5
MKP4F031502E_ _ _ _ _ _
10.3
13
10
MKP4F031503F_ _ _ _ _ _
13
10
MKP4F032203G_ _ _ _ _ _
18
15
MKP4F032204B_ _ _ _ _ _
18
15
MKP4F033304C_ _ _ _ _ _
18
15
MKP4F034704D_ _ _ _ _ _
18
15
MKP4F036804F_ _ _ _ _ _
26.5 22.5 MKP4F036805B_ _ _ _ _ _
26.5 22.5 MKP4F041005D_ _ _ _ _ _
26.5 22.5 MKP4F041505G_ _ _ _ _ _
26.5 22.5 MKP4F042205I_ _ _ _ _ _
31.5 27.5 MKP4F042206B_ _ _ _ _ _
31.5 27.5 MKP4F043306D_ _ _ _ _ _
31.5 27.5 MKP4F044706F_ _ _ _ _ _
31.5 27.5 MKP4F046806G_ _ _ _ _ _
41.5 37.5 MKP4F046807D_ _ _ _ _ _
41.5 37.5 MKP4F051007F_ _ _ _ _ _
41.5 37.5 MKP4F051507G_ _ _ _ _ _
41.5 37.5 MKP4F052207H_ _ _ _ _ _
41.5 37.5 MKP4F053307J_ _ _ _ _ _
57
52.5 MKP4F054709F_ _ _ _ _ _
57
52.5 MKP4F056809J_ _ _ _ _ _
* AC voltage:
f
T
400 Hz; 1.4
x
U
rms
+ URC
T
U
r
New values
** PCM = Printed circuit module = pin spacing
Dims. in mm.
Packing:
Pin length:
Part number completion:
Version code:
Tolerance:
2-pin
4-pin
20 %
10 %
5%
bulk
6-2
=
=
=
=
=
=
=
00
D4
M
K
J
S
SD
Taped version see page 128.
Rights reserved to amend design data without prior notification.
Continuation page 53
02.14
52
WIMA MKP 4
WIMA FKP 4
Continuation
D
General Data
Capacitance
0.01
m
F
0.015 „
0.022 „
0.033 „
0.047 „
0.068 „
0.1
m
F
W
3
4
4
4.5
4
5
4
5
5
5.7
5
6
5
6
7
8
6
7
8.5
11
11
11
15
17
17
19
20
24
31
40
35
45
H
8.5
9
9
9.5
9
10.5
9
10.5
11
12.5
11
12
11
12.5
14
15
15
16.5
18.5
21
21
21
26
29
29
32
39.5
45.5
46
55
50
65
400 VDC/220 VAC*
Part number
L PCM**
7.5
MKP4G021002B_ _ _ _ _ _
10
10
13
10.3
13
10.3
13
10.3
13
10.3
13
13
18
18
18
18
26.5
26.5
26.5
26.5
31.5
31.5
31.5
31.5
41.5
41.5
41.5
41.5
41.5
41.5
57
57
7.5
10
7.5
10
7.5
10
7.5
10
7.5
10
10
15
15
15
15
22.5
22.5
22.5
22.5
27.5
27.5
27.5
27.5
37.5
37.5
37.5
37.5
37.5
37.5
52.5
52.5
MKP4G021502C_ _ _ _ _ _
MKP4G021503C_ _ _ _ _ _
MKP4G022202D_ _ _ _ _ _
MKP4G022203C_ _ _ _ _ _
MKP4G023302E_ _ _ _ _ _
MKP4G023303C_ _ _ _ _ _
MKP4G024702E_ _ _ _ _ _
MKP4G024703F_ _ _ _ _ _
MKP4G026802F_ _ _ _ _ _
MKP4G026803F_ _ _ _ _ _
MKP4G031003G_ _ _ _ _ _
MKP4G031004B_ _ _ _ _ _
MKP4G031504C_ _ _ _ _ _
MKP4G032204D_ _ _ _ _ _
MKP4G033304F_ _ _ _ _ _
MKP4G033305B_ _ _ _ _ _
MKP4G034705D_ _ _ _ _ _
MKP4G036805F_ _ _ _ _ _
MKP4G041005I_ _ _ _ _ _
MKP4G041006B_ _ _ _ _ _
MKP4G041506B_ _ _ _ _ _
MKP4G042206F_ _ _ _ _ _
MKP4G043306G_ _ _ _ _ _
MKP4G043307E_ _ _ _ _ _
MKP4G044707F_ _ _ _ _ _
MKP4G046807G_ _ _ _ _ _
MKP4G051007H_ _ _ _ _ _
MKP4G051507I_ _ _ _ _ _
MKP4G052207K_ _ _ _ _ _
MKP4G052209F_ _ _ _ _ _
MKP4G053309J_ _ _ _ _ _
W
3
4
4
4
4.5
4
5
4
5.7
5
6
6
7
8
6
9
7
8.5
10.5
11
11
13
15
17
19
20
24
35
35
45
H
8.5
9
9
9
9.5
9
10.5
9
12.5
11
12
12.5
14
15
15
16
16.5
18.5
19
21
21
24
26
29
32
39.5
45.5
50
50
65
630 VDC/280 VAC*
L PCM**
Part number
7.5
MKP4J021002B_ _ _ _ _ _
10
13
10
MKP4J021003C_ _ _ _ _ _
7.5
MKP4J021502C_ _ _ _ _ _
10
13
10
MKP4J021503C_ _ _ _ _ _
7.5
MKP4J022202D_ _ _ _ _ _
10.3
13
10
MKP4J022203C_ _ _ _ _ _
7.5
MKP4J023302E_ _ _ _ _ _
10.3
13
10
MKP4J023303C_ _ _ _ _ _
7.5
MKP4J024702F_ _ _ _ _ _
10.3
13
10
MKP4J024703F_ _ _ _ _ _
13
10
MKP4J026803G_ _ _ _ _ _
18
15
MKP4J026804C_ _ _ _ _ _
18
15
MKP4J031004D_ _ _ _ _ _
18
26.5
18
26.5
26.5
26.5
31.5
31.5
31.5
31.5
41.5
41.5
41.5
41.5
41.5
57
57
15
22.5
15
22.5
22.5
22.5
27.5
27.5
27.5
27.5
37.5
37.5
37.5
37.5
37.5
52.5
52.5
MKP4J031504F_ _ _ _ _ _
MKP4J031505B_ _ _ _ _ _
MKP4J032204J_ _ _ _ _ _
MKP4J032205D_ _ _ _ _ _
MKP4J033305F_ _ _ _ _ _
MKP4J034705G_ _ _ _ _ _
MKP4J034706B_ _ _ _ _ _
MKP4J036806B_ _ _ _ _ _
MKP4J041006D_ _ _ _ _ _
MKP4J041506F_ _ _ _ _ _
MKP4J042207E_ _ _ _ _ _
MKP4J043307F_ _ _ _ _ _
MKP4J044707G_ _ _ _ _ _
MKP4J046807H_ _ _ _ _ _
MKP4J051007J_ _ _ _ _ _
MKP4J051509F_ _ _ _ _ _
MKP4J052209J_ _ _ _ _ _
0.15 „
0.22 „
0.33 „
0.47 „
0.68 „
1.0
m
F
1.5
2.2
3.3
4.7
6.8
10
15
22
33
„
„
„
„
„
m
F
„
„
„
* AC voltage:
f
T
400 Hz; 1.4 x U
rms
+ UDC
T
U
r
New values
** PCM = Printed circuit module = pin spacing
Dims. in mm.
Packing:
Pin length:
Part number completion:
Version code:
Tolerance:
2-pin
4-pin
20 %
10 %
5%
bulk
6-2
=
=
=
=
=
=
=
00
D4
M
K
J
S
SD
Taped version see page 128.
Rights reserved to amend design data without prior notification.
Continuation page 54
02.14
53
WIMA MKP
4
WIMA FKP
4
Continuation
D
General Data
Capacitance
0.01
m
F
0.015 „
0.022
0.033
0.047
0.068
0.1
„
„
„
„
m
F
0.15 „
0.22 „
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
„
„
„
m
F
„
„
„
„
„
m
F
W
5.7
5
5
5
5
6
7
8
6
9
7
8.5
11
11
11
13
17
17
20
24
31
35
35
45
H
12.5
11
11
11
11
12.5
14
15
15
16
16.5
18.5
21
21
21
24
29
29
39.5
45.5
46
50
50
65
1000 VDC/400 VAC
*
Part number
L PCM**
7.5
MKP4O121002F_ _ _ _ _ _
10,3
13
10
MKP4O121003F_ _ _ _ _ _
13
10
MKP4O121503F_ _ _ _ _ _
18
15
MKP4O121504B_ _ _ _ _ _
18
15
MKP4O122204B_ _ _ _ _ _
18
15
MKP4O123304C_ _ _ _ _ _
18
15
MKP4O124704D_ _ _ _ _ _
18
15
MKP4O126804F_ _ _ _ _ _
26.5 22.5 MKP4O126805B_ _ _ _ _ _
18
15
MKP4O131004J_ _ _ _ _ _
26.5 22.5 MKP4O131005D_ _ _ _ _ _
26.5 22.5 MKP4O131505F_ _ _ _ _ _
26.5 22.5 MKP4O132205I_ _ _ _ _ _
31.5 27.5 MKP4O132206B_ _ _ _ _ _
31.5 27.5 MKP4O133306B_ _ _ _ _ _
31.5 27.5 MKP4O134706D_ _ _ _ _ _
31.5 27.5 MKP4O136806G_ _ _ _ _ _
41.5 37.5 MKP4O141007E_ _ _ _ _ _
41.5 37.5 MKP4O141507G_ _ _ _ _ _
41.5 37.5 MKP4O142207H_ _ _ _ _ _
41.5 37.5 MKP4O143307I_ _ _ _ _ _
41.5 37.5 MKP4O144707J_ _ _ _ _ _
57
52.5 MKP4O146809F_ _ _ _ _ _
57
52.5 MKP4O151009J_ _ _ _ _ _
* AC voltage:
f
T
400 Hz; 1.4
x
U
rms
+ UDC
T
U
r
New values
** PCM = Printed circuit module = pin spacing
Dims. in mm.
Part number completion:
Version code:
Tolerance:
Packing:
Pin length:
2-pin
4-pin
20 %
10 %
5%
bulk
6-2
=
=
=
=
=
=
=
00
D4
M
K
J
S
SD
Taped version see page 128.
W PCM
17
19
20
24
31
35
40
35
45
c
b
10
10
12.5
12.5
20
20
20
20
20
P
d c
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.2
1.2
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.8
0.8
P
d
0.5
0.6
0.6
0.8
1.0
pin
PCM
W
7.5
T
3
7.5
U
4
10
15 - 27.5
37.5
pin
Rights reserved to amend design data without prior notification.
c
pin
37.5
37.5
37.5
37.5
37.5
37.5
37.5
52.5
52.5
Permissible AC voltage
in relation to frequency
at 10) C internal temperature rise
(general guide).
54
02.14
D
Recommendation for Processing
and Application of
Through-Hole Capacitors
Soldering Process
Internal temperature of the capacitor must
be kept as follows:
Polyester:
preheating: T
max.
T
125° C
soldering: T
max.
T
135° C
Polypropylene: preheating: T
max.
T
100° C
soldering: T
max.
T
110° C
Single wave soldering
Soldering bath temperature: T
260 ° C
Dwell time:
t
5 sec
Double wave soldering
Soldering bath temperature: T
260 ° C
Dwell time:
St
5 sec
Due to different soldering processes and
heat requirements the graphs are to be
regarded as a recommendation only.
WIMA Quality and Environmental Philosophy
ISO 9001:2008 Certification
ISO 9001:2008 is an international basic
standard of quality assurance systems for
all branches of industry. The approval
according to ISO 9001:2008 of our
factories by the VDE inspectorate certifies
that organisation, equipment and moni-
toring of quality assurance in our factories
correspond to internationally recognized
standards.
WIMA Environmental Policy
All WIMA capacitors, irrespective of
whether through-hole devices or SMD,
are made of environmentally friendly
materials. Neither during manufacture
nor in the product itself any toxic
substances are used, e.g.
–
–
–
–
–
Lead
PCB
CFC
Hydrocarbon chloride
Chromium 6+
–
–
–
–
–
PBB/PBDE
Arsenic
Cadmium
Mercury
etc.
RoHS Compliance
According to the RoHS Directive 2011/65/EU
certain hazardous substances like e.g. lead,
cadmium, mercury must not be used any
longer in electronic equipment as of July 1st,
2006. For the sake of the environment WIMA
has refraind from using such substances since
years already.
WIMA WPCS
The WIMA Process Control System (WPCS)
is a quality surveillance and optimization
system developed by WIMA. WPCS is a
major part of the quality-oriented WIMA
production. Points of application of WPCS
during production process:
”
”
”
”
”
”
”
incoming material inspection
metallization
film inspection
schoopage
pre-healing
pin attachment
cast resin preparation/
encapsulation
”
100% final inspection
”
AQL check
We merely use pure, recyclable materials
for packing our components, such as:
”
”
”
”
carton
cardboard
adhesive tape made of paper
polystyrene
WIMA Kondensatoren sind bleifrei
konform RoHS 2011/65/EU
WIMA capacitors are lead free
in accordance with RoHS 2011/65/EU
Tape for lead-free WIMA capacitors
We almost completely refrain from using
packing materials such as:
”
foamed polystyrene (Styropor®)
”
adhesive tapes made of plastic
”
metal clips
DIN EN ISO 14001:2004
WIMA’s environmental management has
been established in accordance with the
guidelines of DIN EN ISO 14001:2004 to
optimize the production processes with
regard to energy and resources.
14
02.14
京公网安备 11010802033920号
EEWORLD
