CURRENT SHUNT RESISTORS
The content of this specification may change without notification 11/03/08
Custom solutions are available.
SR Series - Current Shunt Resistors
Custom solutions are available. Call us with your specification requirements.
HOW TO ORDER
SR 1- 04 60 F Z M
Packaging
TCR (ppm/°C)
Z =
±100ppm
Resistance Tolerance
F =
±1%
Rated Voltage
60mV = 60
100mV = 100
Rated Current
100A = 01
400A = 04
200A = 02
600A = 06
300A = 03
1000A = 10
1200A = 12
1500A = 15
2000A = 20
FEATURES
Current shunt resistors are low resistance precision resistors
used to measure AC or DC electrical currents by the voltage
drop those currents create across the resistance. Sometimes
called an ammeter shunt, it is a type of current sensor.
2 or 4 ports available
Tight Tolerance of
±1%
and Tight TCR of
±100ppm
APPLICATIONS
Current Measurement of AC or DC electrical currents
RV battery monitor and battery chargers
Marine battery monitor and battery chargers
Golf Cart, Wheelchair, Electric Bike batteries & chargers
Digital panel meter Ammeter
Solar Power, Wind Power generators batteries & chargers
Electroplating and metal plating Amp Hour measurement
Hand Radio & Amateur Radio base station equipment,
battery monitoring and chargers
Body Style
(refer to schematic table)
1, 2, or 3
Current Shunt Resistor Series
ELECTRICAL CHARACTERISTICS
Item
SR1-03
Rated Current
300A
60/100mV
Rated Output
0.20/0.333
Ω
Milliohm
Heat Resistance
-
Weight (Kg)
-
Tolerance
TCR (ppm/°C)
Operating & Storage Temp
SR1-04
400A
60/100mV
0.15/0.25
-
-
SR1-06
600A
60/100mV
0.10/0.167
-
-
SR1-10
1,000A
60/100mV
0.06/0.10
-
-
SR2-12
1,200A
60/100mV
0.05/0.083
-
-
SR2-15
1,500A
60/100mV
0.04/0.067
-
-
SR2-20
2,000A
60/100mV
0.03/0.05
-
-
SR3-01
100A
60/100mV
0.60/1.00
1.5
0.24
SR3-04
400A
60/100mV
0.30/0.50
0.55
0.24
SR3-06
600A
6/1000mV
0.15/0.25
0.42
0.24
SR3-10
1000A
60/100mV
0.06/0.10
0.23
0.56
±1%
±100
-55°C ~ +125°C
SCHEMATIC
SR1
SR2
SR3
Construction Materials
Terminal: Cu plated Ni
Resistance: Manganin
Junction: Weld
DIMENSIONS (±0.2 mm)
Series
SR1-03
SR1-04
SR1-06
SR1-10
SR2-12
SR2-15
SR2-20
SR3-01
SR3-04
SR3-06
SR3-10
A
155
155
175
175
185
185
215
100
100
100
100
B
45
45
45
45
70
70
80
30
30
30
70
C
20
20
30
30
40
40
45
10
10
10
20
D
115
115
135
135
140
140
160
15
15
15
15
E
60
60
60
60
67
67
70
22
22
22
22
F
15
15
15
15
22
22
25
8
8
8
8
G
10
10
15
15
20
20
20
10
10
10
10
H
-
-
-
-
35
35
40
13
26
26
65
J
2-M5
2-M5
2-M5
2-M5
2-M5
2-M5
2-M5
2-M4
2-M4
2-M4
2-M4
K
2-M12-50
2-M12-50
2-M12-50
2-M12-50
2-M12-50
2-M12-50
2-M12-50
2-M12
2-M12
2-M12
2-M12
American Accurate Components, Inc.
188 Technology Drive, Unit H Irvine, CA 92618
TEL: 949-453-9888 FAX: 949-453-8889
1
