OeD4204-10.00M
TCVCXO Oscillator
November 2010
• Pletronics’ OeD4 is from the OeXO™ Series of
temperature compensated voltage controlled
crystal oscillator with a CMOS output.
• Cut Tape -or- Tape and Reel packaging
• 3.2 x 5 mm LCC Ceramic Package
• Supply Voltage: 3.3V
Pletronics Inc. certifies this device is in accordance with the
RoHS 6/6 (2002/95/EC) and WEEE (2002/96/EC) directives.
Pletronics Inc. guarantees the device does not contain the following:
Cadmium, Hexavalent Chromium, Lead, Mercury, PBB’s, PBDE’s
Weight of the Device: 0.10 grams
Moisture Sensitivity Level: 1 As defined in J-STD-020D.1
Second Level Interconnect code: e4
Absolute Maximum Ratings:
Parameter
V
CC
Supply Voltage
Vi
Vo
Input Voltage
Output Voltage
Unit
-0.5V to +6.5V
-0.5V to V
CC
+ 0.5V
-0.5V to V
CC
+ 0.5V
Thermal Characteristics
The maximum die or junction temperature is 155
o
C
The thermal resistance junction to board is 30 to 50
o
C/Watt depending on the solder pads, ground plane
and construction of the PCB.
ESD Rating
Model
Human Body Model
Charged Device Model
Minimum Voltage
1500
1000
Conditions
MIL-STD-883 Method 3115
JESD 22-C101
Product information is current as of publication date. The product conforms
to specifications per the terms of the Pletronics standard warranty. Production
processsing does not necessarily include testing of all parameters.
Copyright © 2010, Pletronics Inc.
OeD4204-10.00M
TCVCXO Oscillator
November 2010
Part Marking:
2000.yww
C
PLExYWWz
2000
yww
PLE
X
YWW
Z
=
=
=
=
=
=
20.00MHz, the crystal frequency
Year and Week of the crystal manufacture
Pletronics
Model number, normally a “B”
Year and Week of assembly of the TCXO
internal factory code
The actual part number is OED4204-10.00M where the model number “204” is the specification number
the part is made to. This is not included in the part marking. This is included on the label on the Tape and
Reel.
Note that the crystal frequency is 2 times the specified frequency of 10.00MHz. The TCVCXO IC used
divides the crystal frequency be 2 resulting in a 10.00MHz output
Package Labeling
Label is 1" x 2.6" (25.4mm x 66.7mm)
Font is Courier New
Bar code is 39-Full ASCII
The bar code will show the actual Part Number
(OED4204-10.00M)
Label is 1" x 2.6" (25.4mm x 66.7mm)
Font is Arial
Reliability
: Environmental Compliance
Parameter
Mechanical Shock
Vibration
Solderability
Thermal Shock
Condition
MIL-STD-883 Method 2002, Condition B
MIL-STD-883 Method 2007, Condition A
MIL-STD-883 Method 2003
MIL-STD-883 Method 1011, Condition A
www.pletronics.com
425-776-1880
2
OeD4204-10.00M
TCVCXO Oscillator
November 2010
Electrical Specification for specified Vcc= 3.3V ±5% over the specified
temperature range.
Item
Frequency Stability
over temperature
Min
-50
TYP
-
Max
50
Unit
ppb
Condition
Over 0 C to 70 C
o
o
at fixed supply voltage
+ load (reference to
midpoint min/max
frequency)
Holdover
Frequency Calibration
Supply voltage stability
Load sensitivity
Warm Up
Aging rate following reflow
-50
-40
-2.0
-10
-5
-
-
-
-
-1000
-1500
-4600
0
0
-
0
-
0.4
±10
±3
±1
-
-
-
50
40
2.0
10
5
3.0
-
-
-
1000
1500
4600
CMOS
ppb
ppb
ppm
ppb
ppb
S
ppb/day
Over 0
o
C to 70
o
C for 24 hours
Over +5
o
C change for 24 hours
_
Frequency offset at 25
o
C,
60 minutes after reflow.
+ 2% variation in supply voltage
_
10K ohm +5% || 10 pF +10%
_
_
Time to reach specified frequency
1 day after reflow
7 days after reflow
30 days after reflow
after 1 year
after 5 years
after 15 years
Long term stability (Aging)
ppb
Output Waveform
Output V
HIGH
Output V
LOW
T
RISE
and T
FALL
Duty Cycle
Phase Noise
1 Hz
10 Hz
100 Hz
1 KHz
10 KHz
100 KHz
90
-
-
40
-
-
-
-
-
-
-
V
CC
I
CC
3.13
-
0.5
5
-
0
-
-
-
50
-71
-93
-117
-138
-152
-155
-
3.30
-
-
-
0.05
-
-
10
6.5
60
-
-
-
-
-
-
0.6
3.47
3.0
2.50
10
2.0
+70
%Vs
%Vs
nS
%
Load: 10K ohm +5% || 10 pF +10%
_
_
Vth: T
R
and T
F
10% and 90% of amplitude
Vth: D.C. 50% of amplitude
at 25
o
C
dBc/Hz
Jitter
V Supply Range
1
Supply Current
Vcontrol Range
Frequency Pullability
Linearity
Operating Temperature
pS
Volts
mA
Volts
±ppm
%
o
Frequency offset from carrier 12kHz to 20MHz
1.50 volts nominal
Slope positive
In accordance with MIL-PRF-55310
Widest range allowed
C
o
Storage Temperature
-55
-
+95
C
1
Note: For correct operation a 10nF supply de-coupling capacitor should be placed next to the device.
www.pletronics.com
425-776-1880
3
OeD4204-10.00M
TCVCXO Oscillator
November 2010
Mechanical:
Inches
4
1
mm
5.00 +0.20
_
3.20 +0.20
_
1.50 max
1.40
0.80
1.10
2.60
0.50C
0.20R
A
B
C
D
1
E
1
0.197 +0.008
_
0.126 +0.008
_
0.059 max
0.0.55
0.031
0.043
0.102
0.013C
0.008
3
2
F
1
G
1
H
1
Not to Scale
Contacts:
Gold 11.8 to 39.4 µinches (0.3 to1.0 µm)
over
Nickel 50 to 350 µinches (1.27 to 8.89 µm)
1
Typical dimensions
J
1
Pad
1
2
3
4
-
Function
Vcontrol Input
Ground (GND)
Output
Supply Voltage (V
CC
)
N. C.
Note
If this function is not specified, recommend connecting this pad to ground.
CMOS
Connect an appropriate power supply bypass capacitors as close as possible.
All other pads on the bottom shall not be connected. These are internally
connected and were for the TCXO compensation process
Layout and application information
All connection points in the designated region have solder mask
cover to avoid any electrical connections
For Optimum Stability and Jitter Performance, Pletronics
recommends:
•
•
•
•
•
a ground plane under the device
no large transient signals (both current and voltage) should be routed under the device
do not layout near a large magnetic field such as a high frequency switching power supply
do not place near piezoelectric buzzers or mechanical fans.
minimize air flow across the device
www.pletronics.com
425-776-1880
4
OeD4204-10.00M
TCVCXO Oscillator
November 2010
Reflow Cycle (typical for lead free processing)
Temperature (°C)
250
200
150
100
175°C±10°C
260°C Maximum
10 Seconds Maximum
215°C±10°C
120 to 160 Seconds
Approximately 50 Seconds
Allowed rate of temperature change
Maximum 4°C per second
The part may be reflowed 2 times without degradation.
Tape and Reel: available for quantities of 250 to 1000 per reel, cut tape for < 250
Constant Dimensions Table 1
Tape
Size
8mm
12mm
16mm
24mm
1.5
+0.1
-0.0
D1
Min
1.0
1.5
1.5
1.5
1.75
_0.1
+
4.0
0.6
_0.1
+
2.0
_0.1
+
0.6
0.1
S1
Min
T
Max
T1
Max
D0
E1
P0
P2
2.0
_
+0.05
Variable Dimensions Table 2
Tape
Size
16 mm
B1
Max
12.1
E2 Min
F
P1
T2
Max
8.0
W
Max
16.3
Ao, Bo &
Ko
Note 1
Not to scale
14.25
7.5 _0.1
+
8.0 +0.1
_
Note 1: Embossed cavity to conform to EIA-481-B
Dimensions in mm
REEL DIMENSIONS
A
inches
mm
B
inches
mm
C
D
mm
mm
16.4
+2.0
-0.0
7.0
177.8
2.50
63.5
10.0
254.0
4.00
101.6
13.0 +0.5 / -0.2
16.4
+2.0
-0.0
16.4
+2.0
-0.0
16.0
13.0
330.2
3.75
95.3
Tape
Width
Reel dimensions may vary
from the above
www.pletronics.com
425-776-1880
5
