TECHNICAL CHARACTERISTICS
5
24.99±0.2
MATERIAL
INSULATOR: ABS
FLAMABILITY RATING: UL94-HB
COLOR: BLACK
SCREW: UNC 4-40
ENVIRONMENTAL
COMPLIANCE: LEAD FREE AND ROHS
A
Ø
8.
2
30.8±0.30
2.6
8.0±0.2
10.4
44.0±0.3
31.0
3.5
16.0±0.2
16.5
PACKAGING: BAG
NOTE : TO NOT BE PLUG WITH 618 0xx 221 923
39.2±0.25
Ø9.8±0.2
20.2±0.25
Ø4.2
B
C
RoHS Compliant
PROJECTION:
GENERAL TOLERANCE
.X = +/- 0.2
.XX = +/- 0.15
APPROVAL: NPr
G
REV
17-NOV-14
DATE
PACKAGING
FILE
AS
BY
UNIT: MM
SCALE:
SHEET: 1/3
DRAW: AS
WERI PART NO: 618 009 214 622
DESCRIPTION: WR-DSUB - PLASTIC HOOD SMALL TOP ENTRY 4640 SCREW
SIZE
A4
D
1
2
3
4
5
Cautions and Warnings:
This electronic component is designed and developed with the intention for use
in general electronics equipments.
Before incorporating the components into any equipments in the field such as aerospace, aviation,
nuclear control, submarine, transportation, (automotive control, train control, ship control),
transportation signal, disaster prevention, medical, public information network etc. where higher safety
and reliability are especially required or if there is possibility of direct damage or injury to human body,
Wurth Elektronik must be asked for a written approval.
In addition, even electronic component in general electronic equipments, when used in electrical circuits
that require high safety, reliability functions or performance, the sufficient reliability evaluation-check
for the safety must be performed before by the user before usage.
