Part Number:
RevConnect 10GX Flex Plug
RevConnect 10GX Flex Plug, CAT6A, Single Packaging (incl. 1 core),
Bonded-Pair, 4 Pair, 23 AWG Solid, T568A/B-T568A/B
Product Description
RevConnect 10GX Flex Plug, CAT6A, Single Packaging (incl. 1 core), Bonded-Pair, 4 Pair, 23 AWG Solid, T568A/B-T568A/B
Technical Specifications
Product Overview
Suitable Applications:
10GX System, TIA Category 6A, ISO Class EA, 10G Base-T
Physical Characteristics (Overall)
Conductor
AWG Stranding
23
Solid
Material
No. of Pairs
Bare Copper 4
Insulation
Material
PO - Polyolefin
Outer Jacket Material
Material
PVC - Polyvinyl Chloride
Overall Nominal Diameter:
Wiring Scheme:
Packaging:
Weight:
0.23 in.
T568A/B-T568A/B
Individually packaged in a clear plastic bag.
0.060 lbs
Connectors
Materials
Description
Cable End 1, Plug
Polycarbonate
Material
Type
RJ45
Cable End 1, Connection Phosphor Bronze with 50u inch Gold over Nickel Plating RJ45 Blades
Cable End 2, Connection 50uin Gold plated contacts
REVConnect
Electrical Characteristics
Dielectric Strength:
Current Rating:
Insulation Resistance:
Max Contact Resistance:
High Freq
Frequency [MHz] Min. NEXT [dB] Min. RL (Return Loss) [dB]
1 MHz
4 MHz
8 MHz
10 MHz
16 MHz
20 MHz
65 dB
65 dB
65 dB
65 dB
63 dB
61 dB
19.8 dB
21.6 dB
22.5 dB
22.8 dB
23.4 dB
23.7 dB
1,000 V RMS @ 60 Hz
1.500 A
500 M-Ohm Minimum
20 mOhm
25 MHz
31.25 MHz
62.5 MHz
100 MHz
200 MHz
250 MHz
300 MHz
400 MHz
500 MHz
625 MHz
59.2 dB
57.3 dB
51.3 dB
47.3 dB
41.4 dB
39.5 dB
37.2 dB
33.7 dB
30.9 dB
28.3 dB
24 dB
23 dB
20 dB
18 dB
15 dB
14 dB
12.8 dB
10.9 dB
9.5 dB
8 dB
Temperature Range
Installation Temp Range:
Storage Temp Range:
Operating Temp Range:
-10°C To +60°C
-40°C To +70°C
-10°C To +60°C
Mechanical Characteristics
Min Bend Radius (Overall Cable):
Plug /Jack Compatibility:
Termination Interface
Termination
Cable End 1 - RJ45
Connection
Durabilities
1.040 in.
RJ45, REVConnect Core
Mated Connection 750 Cycles
Cable End 2 - RevConnect Mated Connection 20 Cycles
Standards
UL Rating:
Telecommunications Standards:
IEEE Specification:
Other Specification:
Other Standards:
UL94 V-0, UL1863, UL2043
Category 6A - TIA 568.C.2, ISO/IEC 11801:2002 Ed.2
Power Over Ethernet (PoE) IEEE 802.3at type 1 and 2 (up to 30W), IEEE802.3bt/D1.7 type 3 and 4 (up to 100W), CISCO UPOE (up to 60W), Power over
HDBaseTTM (up to 100W)
IEC 60603-7, FCC PART 68, SUB PART F
FCC Part 68, Subpart F, IEC 60603-7
Applicable Environmental and Other Programs
EU Directive 2002/95/EC (RoHS):
EU RoHS Compliance Date
(yyyy-mm-dd):
MII Order #39 (China RoHS):
Yes
2006-07-01
EUP 50
Suitability
Suitability - Indoor:
Yes
Flammability, LS0H, Toxicity Testing
Safety Listing:
c(UL)us Listed
Part Number
Related Parts:
Variants
Item #
RVAFFPUBK18-S1
Color
Black
REVConnect
RVAFFPUEW18-S1 Electric White
© 2018 Belden, Inc
All Rights Reserved.
Although Belden makes every reasonable effort to ensure their accuracy at the time of this publication, information and specifications described here in are subject to error or omission and to change without
notice, and the listing of such information and specifications does not ensure product availability.
Belden provides the information and specifications herein on an "ASIS" basis, with no representations or warranties, whether express, statutory or implied. In no event will Belden be liable for any damages
(including consequential, indirect, incidental, special, punitive, or exemplary damages) whatsoever, even if Belden has been advised of the possibility of such damages, whether in an action under contract,
negligence or any other theory, arising out of or in connection with the use, or inability to use, the information or specifications described herein.
All sales of Belden products are subject to Belden's standard terms and conditions of sale.
Belden believes this product to be in compliance with all applicable environmental programs as listed in the data sheet. The information provided is correct to the best of Belden's knowledge, information and belief
at the date of its publication. This information is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or the one that it becomes a part of. The Product
Disclosure is not to be considered a warranty or quality specification. Regulatory information is for guidance purposes only. Product users are responsible for determining the applicability of legislation and
regulations based on their individual usage of the product.
