MKBPC10/15/25/35/50AW SERIES
SILICON BRIDGE RECTIFIERS
REVERSE VOLTAGE
- 50
to
1000Volts
FORWARD CURRENT
- 10/15/25/35/50
Amperes
MKBPC-W
.335(8.5)
.295(7.5)
FEATURES
●
Surge overload -240~500 Amperes peak
●
Low forward voltage drop
●
Mounting Position : Any
●
Electrically isolated base -2000 Volts
●
Solderable 0.25" FASTON terminals
●
Materials used carries U/L recognition
1.200
(30.5)MIN
.042(1.07)
.038(0.97)
Hole for
No.8 screw
193"(4.9)diam
1.133(28.8)
1.114(28.3)
1.133(28.8)
1.114(28.3)
.732(18.6)
.693(17.6)
.469(11.9)
.429(10.9)
Dimensions in inches and (milimeters)
.732(18.6)
.693(17.6)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating at 25℃ ambient temperature unless otherwise specified.
Resistive or inductive load 60Hz.
For capacitive load current by 20%
MKBPC
-W
10005
MKBPC
-W
1001
1501
2501
3501
5001
100
70
10
240
M
KBPC
15W
MKBPC
-W
1002
1502
2502
3502
5002
200
140
15
300
MKBPC
-W
1004
1504
2504
3504
5004
400
280
M
KBPC
25W
25
400
MKBPC
-W
1006
1506
2506
3506
5006
600
420
M
KBPC
35W
MKBPC
-W
1008
1508
2508
3508
5008
800
560
35
400
M
KBPC
50W
MKBPC
-W
1010
1510
2510
3510
5010
1000
700
50
500
V
V
A
UNIT
CHARACTERISTICS
SYMBOL
15005
25005
35005
50005
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Bridge Input Voltage
Maximum Average Forward
Rectified Output Current @T
C
=55℃
Peak Forward Surage Current
8.3ms Single Half Sine-Wave
Super Imposed on Rated Load
Maximum Forward Voltage Drop
Per Element at 5.0/7.5/12.5/17.5/25.0A Peak
Maximum Reverse Current at Rated
DC Blocking Voltage Per Element
Operating Temperature Range
Storage Temperature Range
@T
A
=25℃
V
RRM
V
RMS
I
(AV)
50
35
M
KBPC
10W
I
FSM
A
V
F
I
R
T
J
T
STG
1.1
10
-55 to +125
-55 to +125
V
μA
℃
℃
~
~
RATING AND CHARACTERISTIC CURVES
MKBPC10/15/25/35/50A W SERIES
FIG.1-MAXIMUM FORWARD SURGE CURRENT
AVERAGE FORWARD OUTPUT CURRENT ,
AMPERES
600
PEAK FORWARD SURGE CURRENT ,
AMPERES
MKBPC50W
FIG.2- DERATING CURVE
OUTPUT RECTIFIED CURRENT
500
MKBPC25/35W
50
MKBPC50W
400
MKBPC15W
40
MKBPC35W
300
200
100
MKBPC10W
30
MKBPC25W
20
MKBPC15W
10
MKBPC10W
0
1
10
NUMBER OF CYCLES AT 60Hz
100
0
50
100
150
CASE TEMPERATURE,°C
FIG.3-TYPICAL FORWARD
CHARACTERISTICS
MKBPC35/50W
100
MKBPC15W
MKBPC25W
MKBPC10W
FIG.4-TYPICAL REVERSE
CHARACTERISTICS
10
INSTANTANEOUS FORWARD CURRENT ,
AMPERES
10
INSTANTANEOUS REVERSE CURRENT ,
MICROAMPERES
1.0
1.0
T
J
=25°C
0.1
0.1
0.01
0.4
0.01
0
20
40
60
80
100
120
140
0.6
0.8
1.0
1.2
1.4
1.6
PERCENT OF RATED PEAK REVERSE VOLTAGE
INSTANTANEOUS FORWARD VOLTAGE,VOLTS
~
~
