DTA36 Series
Rev. B
20 ~ 30 Watts
Single Output
AC/DC Desktop Power Supply
FEATURES
●
Single Output
●
Energy Star Compliant
●
Short Circuit Protected
●
Output Current from 1.5 ~ 4A
●
Output Voltages from 5 ~ 24VDC
●
AC Inlet: IEC-320-C6 or IEC-320-C8
DESCRIPTION
The DTA36 Series has output power that ranges from 20~36 watts. These supplies have single outputs and are
short circuit protected. Output voltages are available from 5VDC to 24VDC. This series also comes with the option
of either an IEC-320-C8 or IEC-320-C6 AC inlet connector. All supplies are Energy Star compliant. Contact our
sales department for further information.
SPECIFICATIONS:
DTA36 Series
All specifications apply @ ±25°C ambient unless otherwise noted
INPUT SPECIFICATIONS
Input Range .............................................................. 100-240VAC
Input Frequency ............................................................... 47-63Hz
Inrush Current ..............................................30A max. @ 115VAC
Leakage Current ....................................................... 0.25mA max
GENERAL SPECIFICATIONS
Isolation Resistance.....................................10M ohms @ 500VDC
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature .................................................. 0 ~ +40°C
Storage Temperature................................................... -25 ~ +95°C
OUTPUT SPECIFICATIONS
Output Current ................................................................ see table
Line Regulation ...................................................................... ±1%
Load Regulation ..................................................................... ±5%
Ripple/Noise (20 MHz BW) ...................................................... 1%
Hold Up Time ..................................................... 10ms @ 115VAC
PHYSICAL SPECIFICATIONS
Weight .................................................................................... 205g
Dimensions (L x W x H) ...........................4.33 x 1.97 x 1.18 inches
110 x 50 x 30 mm
AC Inlet .................................... IEC-320-C8 (Y) or IEC-320-C6 (M)
SAFETY
EMI Conduction ..................... FCC part 15J Class B and CISPR22
(EN55022) Class B
Safety Approvals.........UL/CUL, TUV/GS, CE, PSE, LPS, LVD, CB
PROTECTION
Short Circuit Protection ............................................... Continuous
Over Voltage Protection ...................................................... Option
Due to advances in technology, specifications subject to change without notice
Wall Industries, Inc. 5 Watson Brook Road Exeter, NH 03833
603-778-2300 www.wallindustries.com Fax 603-778-9797
DTA36 Series
Rev. B
20 ~ 30 Watts
Single Output
AC/DC Desktop Power Supply
OUTPUT VOLTAGE / CURRENT RATING CHART
Model
DTAF3605-X
DTAF3606-X
DTAF3607-X
DTAF3675-X
DTAG3609-X
DTAG3610-X
DTAG3611-X
DTAH3612-X
DTAH3613-X
DTAH3614-X
DTAH3615-X
DTAJ3616-X
DTAJ3617-X
DTAJ3618-X
DTAJ3619-X
DTAK3624-X
Output Voltage
5V
6V
7V
7.5V
9V
10V
11V
12V
13V
14V
15V
16V
17V
18V
19V
24V
Output Current
0 ~ 4.0A
0 ~ 4.0A
0 ~ 3.5A
0 ~ 3.5A
0 ~ 4 .0A
0 ~ 3.6A
0 ~ 3.3A
0 ~ 3.0A
0 ~ 2.7A
0 ~ 2.5A
0 ~ 2.4A
0 ~ 2.2A
0 ~ 2.1A
0 ~ 2.0A
0 ~ 1.8A
0 ~ 1.5A
Ripple & Noise
50mV
60mV
70mV
75mV
90mV
100mV
110mV
120mV
130mV
140mV
150mV
160mV
170mV
180mV
190mV
240mV
Line Regulation
± 1%
± 1%
± 1%
± 1%
± 1%
± 1%
± 1%
± 1%
± 1%
± 1%
± 1%
± 1%
± 1%
± 1%
± 1%
± 1%
Load Regulation
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
± 5%
NOTES
1. The DTA36 Series is designated as DTAz36y-x where
z
represents the different output voltage sections: F (5-8V), G (9-11V),
H (12-15V), J (16-19V), or K (24V).
Y
represents the output voltage and
x
determines the type of AC inlet connector, which
can either be
Y
(IEC-320-C8) or
M
(IEC-320-C6).
2. Powered by an ENERGY STAR
®
qualified adaptor for a better environment.
MECHANICAL DRAWING
Unit: inches [mm]
Wall Industries, Inc. 5 Watson Brook Road Exeter, NH 03833
603-778-2300 www.wallindustries.com Fax 603-778-9797
