DTMPU30 Series
30 Watts
Single, Dual, and Triple Outputs
AC/DC Medical Desktop Power Supply
FEATURES
●
Splash Proof
●
3 Year Warranty
●
Class I Insulation
●
IEC-320-C14 Input Inlet
●
Optional Output Connectors
●
Single, Dual, and Triple Outputs
●
Wide Input Voltage 90 to 264VAC, 47~63Hz
●
Output Voltage Protection (Crowbar Design)
●
Output Voltage Available from 3VDC thru 40VDC
●
Input Surge Current, Over Voltage, and Over Load Protection
SPECIFICATIONS:
DTMPU30 Series
All specifications are based on 25
o
C, Nominal Input Voltage, and Maximum Output Current unless otherwise noted.
We reserve the right to change specifications based on technological advances.
SPECIFICATION
TEST CONDITIONS
Min
Nom
Max
INPUT (V
in
)
Operating Voltage Range
Input Frequency
Input Current (Low Line)
Input Current (High Line)
Inrush Current (Low Line)
Inrush Current (High Line)
Safety Ground Leakage Current
Start-Up Time
OUTPUT (V
o
)
Output Voltage Range
Load Regulation
Line Regulation
Output Power Range
Output Current Range
*Ripple
& Noise (peak to peak)
Transient Response
Hold-Up Time
Temperature Coefficient
PROTECTION
Over Voltage Protection
Over Current Protection
GENERAL
Efficiency
Dielectric Withstanding Voltage
For Primary to Secondary
Dielectric Withstanding Voltage
For Primary to Ground
Isolation Resistance
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Relative Humidity
PHYSICAL
Weight
Dimensions
Warranty
SAFETY
EMI Requirements for CISPR-11
EMI Requirements for FCC PART-18
90
47
Io = Full Load, Vin = 115VAC
Io = Full Load, Vin = 230VAC
Io = Full Load, 25°C, Cool Start, Vin = 115VAC
Io = Full Load, 25°C, Cool Start, Vin = 230VAC
Io = Full Load, Vin = 240VAC
Io = Full Load, Vin = 100VAC
Vin = 230VAC
Io = Full Load
Vin = 90 to 264VAC
Full Load, Vin = 90VAC
Io = Full Load to Half Load, Vin = 100VAC
Io = Full Load, Vin = 110VAC
All Outputs
12
26
0.3
1.5
264
63
0.9
0.34
15
30
0.1
2
Unit
VAC
Hz
A
A
A
A
mA
s
VDC
%
%
W
A
%
ms
ms
%/°C
%
%
%
VDC
VDC
MΩ
See Rating Chart
3
10
0.5
1
0
30
See Rating Chart
0.5
1
4
12
-0.04
+0.04
112
110
132
150
83
85
Io = Full Load, Vin = 230VAC
Primary to Secondary
Primary to Ground
Test Voltage = 2100VDC
Derate linearly from 100% Load at 50°C to 50% load at 70°C
70
5600
2800
50
0
-40
5
70
85
95
°C
°C
%
grams
inches
years
Class
Class
Approximately 400 ~ 460
4.65 x 2.56 x 1.54
3
Vin = 220VAC
Vin = 110VAC
B
B
*Note: The Ripple & Noise for output voltages under 3.3VDC is 2% max.
Wall Industries, Inc. 5 Watson Brook Road Exeter, NH 03833
603-778-2300 www.wallindustries.com Fax 603-778-9797
Rev. B
DTMPU30 Series
30 Watts
Single, Dual, and Triple Outputs
AC/DC Medical Desktop Power Supply
OUTPUT VOLTAGE / CURRENT RATING CHARTS
SINGLE OUTPUT MODELS
Model Number
DTMPU30-101
DTMPU30-102
DTMPU30-103
DTMPU30-104
DTMPU30-105
DTMPU30-106
DTMPU30-107
DTMPU30-108
DTMPU30-109
DTMPU30-110
Preset Voltage
5 VDC
6 VDC
8 VDC
11 VDC
13 VDC
16 VDC
21 VDC
27 VDC
33 VDC
40 VDC
Output Voltage Range
3 ~ 5 VDC
5 ~ 6 VDC
6 ~ 8 VDC
8 ~ 11 VDC
11 ~ 13 VDC
13 ~ 16 VDC
16 ~ 21 VDC
21 ~ 27 VDC
27 ~ 33 VDC
33 ~ 40 VDC
Max. Output Current
6.66 ~ 4.00 A
5.00 ~ 4.16 A
4.16 ~ 3.12 A
3.75 ~ 2.72 A
2.72 ~ 2.30 A
2.30 ~ 1.87 A
1.87 ~ 1.42 A
1.42 ~ 1.11 A
1.11 ~ 0.91 A
0.90 ~ 0.75 A
Total Regulation
5%
5%
5%
4%
3%
3%
3%
2%
2%
2%
Max. Output Power
20W
25W
25W
30W
30W
30W
30W
30W
30W
30W
DUAL OUTPUT MODELS
Model Number
Output 1
DTMPU30-200
Output 2
Output 1
DTMPU30-201
Output 2
Output 1
DTMPU30-202
Output 2
Output 1
DTMPU30-203
Output 2
Output 1
DTMPU30-204
Output 2
Output 1
DTMPU30-209
Output 3
Output 1
DTMPU30-210
Output 3
Output 1
DTMPU30-215
Output 3
Output Voltage
+3.3 VDC
+12.0 VDC
+5.0 VDC
+12.0 VDC
+5.0 VDC
+15.0 VDC
+5.0 VDC
+24.0 VDC
+3.3 VDC
+5.0 VDC
+12 VDC
-12VDC
+15 VDC
-15 VDC
+5.0 VDC
-24.0 VDC
Min. Output Current
0.3A
0.13A
0.3A
0.13A
0.3A
0.1A
0.3A
0.07A
0.3A
0.16A
0.2A
0A
0.15A
0A
0.25A
0A
Max. Output Current
3A
1.3A
3A
1.3A
3A
1.0A
3A
0.7A
3A
1.6A
2A
0.5A
1.5A
0.5A
2.5A
1.0A
Max. Regulation
7%
5%
5%
5%
5%
5%
5%
5%
7%
5%
5%
10%
5%
10%
5%
10%
Max. Output Power
25W
30W
30W
30W
17.9W
30W
30W
30W
TRIPLE OUTPUT MODELS
Model Number
Output 1
DTMPU30-301
Output 2
Output 3
Output 1
DTMPU30-302
Output 2
Output 3
Output 1
DTMPU30-303
Output 2
Output 3
Output 1
DTMPU30-304
Output 2
Output 3
Output 1
DTMPU30-305
Output 2
Output 3
Output 1
DTMPU30-306
Output 2
Output 3
Output Voltage
+5.0 VDC
+12.0 VDC
-5.0 VDC
+5.0 VDC
+12.0 VDC
-12.0 VDC
+5.0 VDC
+15.0 VDC
-15.0 VDC
+5.0 VDC
+24.0 VDC
-24.0 VDC
+5.0 VDC
+24.0 VDC
-12.0 VDC
+3.3 VDC
+12 VDC
-5 VDC
Min. Output Current
0.25A
0.13A
0A
0.25A
0.1A
0A
0.25A
0.1A
0A
0.3A
0.1A
0A
0.3A
0.1A
0A
0.25A
0.11A
0A
Max. Output Current
2.5A
1.3A
0.5A
2.5A
1.0A
0.5A
2.5A
1.0A
0.5A
3.0A
1.0A
0.5A
2.5A
1.0A
0.5A
2.5A
1.1A
0.5A
Max. Regulation
5%
5%
10%
5%
5%
10%
5%
5%
10%
5%
5%
10%
5%
5%
10%
7%
5%
10%
Max. Output Power
25W
30W
30W
30W
30W
25W
NOTES
1. For single output models the output voltage is specified as a range (Ex: 33 ~ 40VDC); the preset voltage will be set as standard models if
nothing different is requested. Please contact factory for ordering details.
2. Optional output connectors are available (see “DC Output Plug Selector List” link located at the bottom of the “Desktop” category page).
Wall Industries, Inc. 5 Watson Brook Road Exeter, NH 03833
603-778-2300 www.wallindustries.com Fax 603-778-9797
