AC-DC Medical
MSC SERIES
KEY FEATURES
Switching Power Modules for PCB Mounting
Fully Encapsulated Plastic Case
Universal Input Range 90-264VAC, 47-440 Hz
Regulated Output
Low Ripple and Noise
Isolation Class II
CE, CB, UL, cUL, TUV Approvals
3-Years Product Warranty
40
Watts
ELECTRICAL SPECIFICATIONS
Model No.
( Single Output )
(W)
Voltage (V.DC.)
Current (mA) max
Voltage set accuracy
Output
Line regulation (Typ.)
Load regulation (1-100%) (Typ.)
Minimum load
Efficiency (Typ)
MSC-3.3S
26.4W
3.3V
8000
±2%
0.5%
1%
1%
75%
MSC-5S
40W
5V
8000
±2%
0.5%
1%
1%
79%
MSC-9S
40W
9V
4444
±2%
0.5%
1%
1%
82%
MSC-12S
40W
12V
3333
±2%
0.5%
1%
1%
83%
MSC-15S
40W
15V
2666
±2%
0.5%
1%
1%
83%
MSC-24S
40W
24V
1667
±2%
0.5%
1%
1%
83%
Max output wattage
Model No.
( Dual Output )
(W)
40W
Output 1
Voltage (V.DC.)
Current (mA) max
Voltage set accuracy
+5V
4000
±2%
0.5%
MSC-5D
40W
Output 2
-5V
4000
Output 1
+12V
1666
±2%
0.5%
MSC-12D
40W
Output 2
-12V
1666
Output 1
+15V
1333
±2%
0.5%
MSC-15D
Output 2
-15V
1333
Max output wattage
Output
Line regulation (Typ.)
Load regulation (10-100%) (Typ.)
Cross regulation (Typ.)
Minimum load
Efficiency (Typ)
1% (symmetric load)
5%
10%
79%
1% (symmetric load)
5%
10%
83%
1% (symmetric load)
5%
10%
83%
Model No.
( Dual Output )
(W)
Output 1
Voltage (V.DC.)
Current (mA) max
Voltage set accuracy
5V
5000
±3%
0.5%
MSC-5S12S
40W
Output 2
12V
1250
±5%
5%
6% (symmetric load)
7%
25%
80%
Output 1
5V
5000
±3%
0.5%
MSC-5S24S
40W
Output 2
24V
625
±5%
5%
6% (symmetric load)
7%
25%
80%
Max output wattage
Output
Line regulation (Typ.)
Load regulation (10-100%) (Typ.)
Cross regulation (Typ.)
Minimum load
Efficiency (Typ)
2% (symmetric load)
1%
2% (symmetric load)
1%
http://www.archcorp.com.tw
TEL: +886-2-26989508 FAX: +886-2-26981319
-1-
VER :
B_6
update :
98.04.09
AC-DC Medical
MSC SERIES
Model No.
( Triple Output )
(W)
Output
2
Voltage (V.DC.)
Current (mA) max
Voltage set accuracy
Output
Line regulation (Typ.)
Load regulation (25-100%) (Typ.)
(symmetric load)
Cross regulation (Typ.)
Minimum load
Efficiency (Typ)
+12
600
±5%
5%
7%
7%
25%
80%
MSC-5S12D
40W
Output
3
-12
600
Output
1
5
5000
±3%
0.5%
3%
3%
MSC-5S15D
40W
Output
2
+15
500
±5%
5%
7%
7%
25%
80%
Output
3
-15
500
40
Watts
Max output wattage
Voltage
Frequency (Hz)
Input
Current (Full load)
Inrush current (<2ms)
Leakage Current
External fuse (recommend)
Maximum capacitive load
Ripple & Noise
Hold-up time
Switching frequency
Over current protection
Protection
Over voltage protection
Short circuit protection
OTP
Input-Output (V.AC)
Operating temperature
Storage temperature
Environment
Temperature coefficient
Humidity
MTBF
Dimension (L x W x H)
Physical
Case Material
Weight
Cooling method
Class II
approval
EMI
/ PFI conducted
EMC Standards
Safety & EMC
ESD Susceptibility
Radiated Susceptibility
EFT / Burst
Surge
Conducted Susceptibility
Safety Approvals
90-264 VAC or 100-375 VDC
47-440 Hz
860 mA max. (115 VAC) / 460 mA max. (230 VAC)
10 A max. (115 VAC) / 20 A max. (230 VAC)
0.1 mA max. (115 VAC) / 0.2 mA max. (230 VAC)
3.15 A slow blow type
470-23,000µF depending on model
3.3V：50mV of Vout
18 ms min.
132 kHz
Above 105% rated output power
Zener diode clamp
Hiccup mode, indefinite (automatic recovery)
100°C
4000V
-25°C…+70°C (Case Temperature max. +95°C)
-40°C…+100°C
0.01%/°C
95% RH
200,000 h~400,000 h @ 25°C
3.5 x 2.5 x 1.06 Inches
280 g
Free air convection
To IEC / EN 60536
cUL / UL / CB
EN 55011 class B
EN60601-1-2
EN60601-1-2
EN60601-1-2
EN60601-1-2
EN60601-1-2
EN60601-1-2
EN60601-1
All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.
Output
5V~24V：1% of Vout
Isolation
( 89.0 x 63.5 x 27.0 mm ) Tolerance
±0.5
mm
Plastic resin + Fiberglass (flammability to UL 94V-0)
http://www.archcorp.com.tw
TEL: +886-2-26989508 FAX: +886-2-26981319
-2-
