Flame Retardant Wrap and Fill Axial Leaded Capacitors
Type 150
Axial Leaded Metallized Polyester
The Type 150 series axial lead metallized polyester
capacitors are available in bulk or on tape and reel for
automatic insertion. The tape wrap and fill construction
is non inductive and the flame retardant polyester outer
wrap meets UL510 requirements. Type 150 is a general
purpose capacitor for use in blocking, bypass, decou-
pling, smoothing and some timing applications.
Highlights
•
•
•
•
•
Available on tape and reel or bulk
Epoxy end fill meets UL94V-0
Non inductively wound
Flame retardant outer wrap meets UL510
Non polar
Specifications
Capacitance Range:
Voltage Range:
Capacitance Tolerance:
Operating Termpeature Range:
Dielectric Withstand Voltage:
Dissipation Factor (DF):
0.001 µF to 10.0 µF
63 to 1000 Vdc (40 to 250 Vac @ 60 Hz)
±5%, ±10%, ±20%
–55 ºC to +125 ºC (
derate linearly to 50% rated
voltage at 125 ºC)
1.6 x rated voltage for 2 s @ +25 ºC ±5 ºC
tgδ x 10
–4
at +25 ºC ±5 ºC
kHz
1
10
100
C
≤0.1
µF
80
150
250
0.1 µF <C ≤1 µF
80
150
—
C >1 µF
100
—
—
Insulation Resistance:
Self Inductance:
Life Test:
Damp Heat Test:
Soldering:
Long Term Storage Stability:
Maximum Pulse Rise Time dv/dt and Pulse:
Characteristic (Wo):
30,000 MΩ x µF, 100,000 MΩ Min.
1 nH max. per 1 mm lead and body length
1000 hrs @ 85 ºC 1.25 x Vn
95% RH @ +45 ºC for 21 days
260 ºC ±5 ºC for 10 s ±1 s
ΔC/C ≤ ±3% after 2 years
V/n
50 - 63
100
250
400
630
L Max
16.5
4
504
5
1,000
10
5,000
13.5
10,800
20
25,200
19 - 20.5 26.5 - 5.28 31.5 - 33
2
252
3
600
7
3,500
10
8,000
15
18,900
1.5
189
2
400
4
2,000
6.5
5,200
10
12,600
1
126
1
300
2.5
1,250
4
3,200
6
7,500
dV/dt (V/µsec)
W
O
(V
2
/µsec)
CDE
Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.cde.com
Type 150
Axial Leaded Metallized Polyester
Tape and Reel Specifications
L Max
(Body Lengty)
Inches
≤.433
≥1.03
mm
≤11
≥26
Lead Spacing
Inches
2.06
2.5
2.87
mm
52.4
63.6
73
Distance Between
Reel Flanges
Inches
3
3.4
3.7
mm
75
86
95
1
2
3
Class
Outline Drawing
.551 - .808 14 - 20.5
Ød ±.002
±0.05 mm)
1.58 ±0.2
(40 ±5 mm)
L
Max
1.58 ±0.2
(40 ±5 mm)
D
Max
^Add class number (1, 2, or 3) to catalog number to indicate tape and reel
Diameter
Inches
0.197
.236 thru .256
0.276
.315 thru .346
.354 thru .413
.433 thru .512
.551 thru .571
>.571
mm
5
6.0 trhu 6.5
7
8 thru 8.5
9 thru 10.5
11 thru 13
14 thru 14.5
>14.5
Quantity per Reel
3,000
1,200
1,100
800
500
300
200
Not available
Ratings
Catalog
Part Number
150154*63AA^
150184*63AA^
150224*63BB^
150274*63BB^
150334*63BB^
150394*63CB^
150474*63DB^
150564*63DB^
150684*63DC^
150824*63EC^
150105*63EC^
150155*63HC^
150225*63HE^
150335*63KE^
150475*63ME^
150685*63QF^
150106*63TF^
150683*100AA^
150823*100AA^
150104*100AA^
150124*100BB^
150154*100BB^
150184*100CB^
150224*100CB^
150274*100CB^
150334*100EB^
150394*100EB^
150474*100DC^
150564*100EC^
150684*100FC^
150824*100HC^
150105*100IC^
Cap
(µF)
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.5
2.2
3.3
4.7
6.8
10
D
Inches Max
L
Ød
63 Vdc/40 Vac
0.197 0.433 0.024
0.197 0.433 0.024
0.236 0.650 0.024
0.236 0.650 0.024
0.236 0.650 0.024
0.256 0.650 0.024
0.276 0.650 0.024
0.276 0.650 0.024
0.276 0.807 0.024
0.315 0.807 0.031
0.315 0.807 0.031
0.374 0.807 0.031
0.374 1.102 0.031
5.0
5.0
6.0
6.0
6.0
6.5
7.0
7.0
7.0
8.0
8.0
9.5
9.5
11.0
11.0
16.5
16.5
16.5
16.5
16.5
16.5
20.5
20.5
20.5
20.5
28.0
28.0
28.0
33.0
33.0
11.0
11.0
11.0
16.5
16.5
16.5
16.5
16.5
16.5
16.5
20.5
20.5
20.5
20.5
20.5
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
Millimeters Max
D
L
Ød
