CURRENT SENSE RESISTORS
The content of this specification may change without notification 06/08/07
CTL05/CTL16/CTL10/CTL18/CTL12/CTL01 Series Chip Resistor
Custom solutions are available.
HOW TO ORDER
CTL
10
R015
F
J
M
Packaging
M = 7” Reel (10” Reel for 2512)
V = 13” Reel
TCR (ppm/°C)
J = +75
K = +100
N = +350
P = +500
Tolerance (%)
F =
±
1.0
G =
±
2.0
EIA Resistance Code
Three significant digits and # of zeros
FEATURES
Resistance as low as 0.001 ohms
Ultra Precision type with high reliability, stability
and quality
RoHS Compliant
L = +200
J =
±
5.0
Extremely Low TCR, as low as + 75 ppm
Wrap Around Terminal for Flow Soldering
Anti-Leaching Nickel Barrier Terminations
ISO 9002 Quality Certified
Size
05 = 0402
16 = 0603
10 = 0805
18 = 1206
12 = 2010
01 = 2512
Applicable Specifications: EIA575, IEC 60115-1,
JISC5201-1, CECC 40401, MIL-R-55342D
SCHEMATIC
Series
Precision Current Sense Resistor
DIMENSIONS (mm)
Series
CTL05
CTL16
CTL10
CTL18
CTL12
CTL01
Size
0402
0603
0805
1206
2010
2512
L
1.00 + 0.10
1.60 + 0.10
2.00 + 0.20
3.20 + 0.20
5.00 + 0.20
6.40 + 0.20
W
0.50 + 0.10
0.80 + 0.10
1.25 + 0.20
1.60 + 0.15
2.50 + 0.20
3.20 + 0.20
c
0.20 + 0.10
0.20 + 0.10
0.60 + 0.15
1.00 + 0.15
1.70 + 0.15
2.00 + 0.15
t
0.35 + 0.10
0.45 + 0.10
0.50 + 0.15
0.50 + 0.15
0.50 + 0.15
0.50 + 0.15
ELECTRICAL CHARACTERISTICS
Size
0402
Rated
Power
.125W
Max TCR (ppm/°C)
Tol
2%
5%
1%
0603
.125W
2%
5%
1%
0805
.250W
2%
5%
.5%
1206
.50W
1%
2%
.5%
2010
.75W
1%
2%
.5%
2512
1.0W
1%
0.100 ~ 0.500
0.100 ~ 0.500
0.056 ~ 0.470
0.056 ~ 0.470
0.056 ~ 0.470
0.056 ~ 0.470
0.001 ~ 0.0649
0.001 ~ 0.0649
0.001 ~ 0.0649
0.001 ~ 0.0649
0.001 ~ 0.0649
0.027
0.018 ~ 0.027
0.018 ~ 0.027
0.027
0.018 ~ 0.027
0.01 ~ 0.015
Rated Voltage =
√
P*R
200V
400V
0.01 ~ 0.015
200V
400V
0.100 ~ 0.500
0.068 ~ 0.470
0.056 ~ 0.470
0.056 ~ 0.470
0.100 ~ 0.500
±75ppm
±100ppm
±200ppm
0.100 ~ 4.70
0.100 ~ 4.70
0.100 ~ 0.680
0.100 ~ 0.680
0.100 ~ 0.680
0.022 ~ 0.080
0.022 ~ 0.080
0.022 ~ 0.080
0.033 ~ 0.047
0.033 ~ 0.047
0.033 ~ 0.047
0.01 ~ 0.039
0.01 ~ 0.039
0.022 ~ 0.068
0.018 ~ 0.027
0.027
0.018 ~ 0.027
0.01 ~ 0.015
200V
400V
150V
300V
50V
100V
±350ppm
±500ppm
Max
Working
Voltage
25V
Max
Overload
Voltage
50V
0.056 ~ 0.470
2%
NOTE: The temperature range is -55
°
C ~ +150
°
C
American Accurate Components, Inc.
188 Technology Drive, Unit H, Irvine, CA 92618
TEL: 949-453-9888 FAX: 949-453-8889
1
CURRENT SENSE RESISTORS
The content of this specification may change without notification 06/08/07
CTL05/CTL16/CTL10/CTL18/CTL12/CTL01 Series Chip Resistor
PERFORMANCE
Test Item
Short Time Overload
Load Life
Maximum
∆ Ω
F
± 0.1%
± 0.25%
G, J
± 0.5%
± 0.5%
Condition
2.5 times of the rated voltage shall be applied for 5 seconds
The resistor shall be subjected to rated voltage for 90 min. followed by a pause of 30
min. at a temperature of 70±3ºC. This constitutes 1 cycle. Cycles shall be repeated for
1000 hours.
The resistor subjected to rated voltage for 90 min followed by a pause for 30 min at a
temperature of 60±2ºC with relative humidity of 90% to 95%. This constitutes 1 cycles.
Cycles shall be repeated for 1000 hours.
[-55ºC 30 min
→
+125ºC 30 min
→
R.T. 3 min] The resistor shall be subjected to 5
continuous cycles
The resistor shall withstand dipped into solder for 10±1 sec. At 260±5ºC
Distance between fulcrums: 90mm; Bending width: 3 mm
1000 Meg
Ω
or over
A new uniform coating of solder shall cover minimum of 95% of surface being immersed
The resistor shall be dipped into the solder of 215±5ºC for 3±0.5 seconds
Moisture Load Life
Temperature Cycle
Resistance to Solder
Heat
Terminal Strength
Insulation Resistance
Solderability
± 0.25%
± 0.1%
± 0.1%
± 0.1%
± 0.5%
± 0.5%
± 0.5%
± 0.5%
DC 500V for 1 min.
PACKAGE QUANTITY
Package Type
M
CTL05
10,000
CTL16
5,000
CTL10
5,000
CTL18
5,000
CTL12
5,000
CTL01
5,000
CTL1S
2,000
TAPE SCHEMATIC
REEL SCHEMATIC
TAPE DIMENSIONS (mm)
CTL05
CTL16
CTL10
CTL18
CTL12
CTL01
CTL1S
A
0.65±0.1
1.1±0.2
1.65±0.2
2.0±0.15
2.9±0.1
3.4±0.1
3.4±0.1
B
1.15±0.1
1.9±0.2
2.4±0.2
3.6±0.15
5.3±0.1
6.6±0.1
6.6±0.1
W
8.0±0.2
8.0±0.2
8.0±0.2
8.0±0.2
12.0±0.2
12.0±0.2
12.0±0.2
E
1.75±0.10
1.75±0.1
1.75±0.1
1.75±0.1
1.75±0.1
1.75±0.1
1.75±0.1
F
3.5±0.05
3.5±0.05
3.5±0.05
3.5±0.05
5.5±0.05
5.5±0.05
5.5±0.05
P
1
2.0±0.05
4.0±0.1
4.0±0.1
4.0±0.1
4.0±0.1
4.0±0.1
4.0±0.1
T
0.55±0.1
0.70±0.1
0.85±0.1
0.85±0.1
1.0±0.1
1.0±0.1
1.0±0.1
T
p
0.20±0.05
0.20±0.05
0.20±0.05
0.20±0.05
0.25±0.1
0.25±0.1
0.25±0.1
REEL DIMENSIONS (mm)
Reel
7”
10”
13”
M
180
±
3.0
H
1.20
C
13.0
±
0.2
G
9.0
±
0.3
E
60
±
1.0
F
11.4
±
1.0
LABEL DESCRIPTION
One side surface of a reel is marked with a label
with the following items of information.
1.
2.
3.
4.
5.
6.
Chip Resistor
Part Number
Tolerance
Quantity
Lot # for production month/year/suffix L*
Manufacturer’s name or symbol
* The suffix “L” indicates that this item is lead free. As of September 2004, all new
production items of this are lead free and in compliance with Lead Free/RoHS.
American Accurate Components, Inc.
188 Technology Drive, Unit H, Irvine, CA 92618
TEL: 949-453-9888 FAX: 949-453-8889
2
