1N4750A datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> 1N4750A

1N4750A: DescriptionZener Diode, 27V V(Z), 5%, 1W, Silicon, Unidirectional, DO-41,; CategoryDiscrete semiconductor diode; File Size366KB，4 Pages; ManufacturerCentral Semiconductor

Download Datasheet Parametric Compare View All

1N4750A Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1N4750A	-	-	View	Buy Now

1N4750A Overview

Zener Diode, 27V V(Z), 5%, 1W, Silicon, Unidirectional, DO-41,

1N4750A Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Central Semiconductor
Reach Compliance Code	not_compliant
ECCN code	EAR99
Other features	INDUSTRY STANDARD
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
Maximum dynamic impedance	35 Ω
JEDEC-95 code	DO-41
JESD-30 code	O-XALF-W2
JESD-609 code	e0
Number of components	1
Number of terminals	2
Maximum operating temperature	200 °C
Package body material	UNSPECIFIED
Package shape	ROUND
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	UNIDIRECTIONAL
Maximum power dissipation	1 W
Certification status	Not Qualified
Nominal reference voltage	27 V
surface mount	NO
technology	ZENER
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum voltage tolerance	5%
Working test current	9.5 mA
