CPZ48X-1N4099 THRU
CPZ48X-1N4135
w w w. c e n t r a l s e m i .
c o m
Zener Diode Die
250mW, 6.8 THRU 100 VOLT
The CPZ48X-1N4099 thru CPZ48X-1N4135 are silicon Zener diodes ideal for all types of commercial,
industrial, entertainment, and computer applications.
MECHANICAL SPECIFICATIONS:
Die Size
Die Thickness
Anode Bonding Pad Size
Top Side Metalization
Back Side Metalization
Scribe Alley Width
Wafer Diameter
Gross Die Per Wafer
MAXIMUM RATINGS:
Operating and Storage Junction Temperature
SYMBOL
TJ, Tstg
13 x 13 MILS
5.5 MILS
7.0 x 7.0 MILS
Ti/Al – 13,000Å
Au-As – 9,000Å
1.97 MILS
5 INCHES
101,184
UNITS
°C
-65 to +150
ELECTRICAL CHARACTERISTICS:
(TA=25°C) VF=1.1V MAX @ IF=200mA (for all types)
Zener
Voltage
Type
MIN
V
CPZ48X-1N4099
CPZ48X-1N4100
CPZ48X-1N4101
CPZ48X-1N4102
CPZ48X-1N4103
CPZ48X-1N4104
CPZ48X-1N4105
CPZ48X-1N4106
CPZ48X-1N4107
CPZ48X-1N4108
CPZ48X-1N4109
CPZ48X-1N4110
CPZ48X-1N4111
CPZ48X-1N4112
CPZ48X-1N4113
CPZ48X-1N4114
CPZ48X-1N4115
CPZ48X-1N4116
CPZ48X-1N4117
CPZ48X-1N4118
6.460
7.125
7.790
8.265
8.645
9.50
10.45
11.40
12.35
13.30
14.25
15.20
16.15
17.10
18.05
19.00
20.90
22.80
23.75
25.65
VZ @ IZT
NOM
V
6.8
7.5
8.2
8.7
9.1
10
11
12
13
14
15
16
17
18
19
20
22
24
25
27
MAX
V
7.140
7.875
8.610
9.135
9.555
10.50
11.55
12.60
13.65
14.70
15.75
16.80
17.85
18.90
19.95
21.00
23.10
25.20
26.25
28.35
Test
Current
IZT
μA
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
Maximum
Zener
Impedance
ZZT @ IZT
Ω
200
200
200
200
200
200
200
200
200
200
100
100
100
100
150
150
150
150
150
150
Maximum
Reverse
Current
IR
μA
10
10
1.0
1.0
1.0
1.0
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.01
0.01
0.01
0.01
0.01
@ VR
V
5.2
5.7
6.3
6.7
7.0
7.6
8.5
9.2
9.9
10.7
11.4
12.2
13.0
13.7
14.5
15.2
16.8
18.3
19.0
20.5
Maximum
Zener
Current
IZM
mA
35.0
31.8
29.0
27.4
26.2
24.8
21.6
20.4
19.0
17.5
16.3
15.4
14.5
13.2
12.5
11.9
10.8
9.9
9.5
8.8
Maximum
Noise
Density
ND @ 250μA
μV/ Hz
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
R0 (29-April 2019)
