Broandband Sideband Mixer (Modulator) 1 to 18GHz
The content of this specification may change without notification 7/01/09
Mixers
Coaxial
Broadband Sideband Mixer(Modulator)
Operating Freq.
P/N
JXWBHP-SM124/C
JXWBHP-SM243/C
JXWBHP-SM483/C
JXWBHP-SM8123/C
JXWBHP-SM12183/C
JXWBHP-SM482/C
JXWBHP-SM8122/C
JXWBHP-SM12182/C
JXWBHP-SM6182/C
JXWBHP-SM144/C
JXWBHP-SM283/C
JXWBHP-SM618/C
JXWBHP-SM37
JXWBHP-SM6182
(GHz)
1-2
2-4
4-8
8-12
12-18
4-8
8-12
12-18
6-18
1-4
2-8
6-18
3-7
6-18
Middle Freq.
(MHz)
0-500
0-500
0-500
0-500
0-500
0-500
0-500
0-500
0-500
0-500
0-300
0-500
0-300
0-500
Conversion
Loss
(dB)
6
6
6
6
6
6
6.5
6.5
7
7
8
8
6
7
1 to 18GHz
Sideband
Suppression
(dBc)
20
20
20
20
20
30
30
25
25
20
20
20
30
30
Carrier
Suppression
(dBc)
25
25
25
25
25
25
25
25
25
25
25
25
45
45
Input
VSWR
2
2
2
2
2
2
2
2
2.5
2
2.5
2.5
2
2.5
2
nd
Cross
Suppression
Modulation
(dB)
30
30
30
30
30
40
40
40
40
30
40
40
35
35
3
rd
Cross
Suppression
Modulation
(dB)
30
30
30
30
30
40
35
35
35
30
35
35
30
30
Case
A4-C
A3-C
A3-C
A3-C
A3-C
A2,A2-C
A2,A2-C
A2,A2-C
A2,A2-C
A4,A4-C
A3-C
A3-C
B
C
Notes:
1. Operating Temperature : -55
O
C to +85
O
C. Storage Temperature : -65
O
C to +100
O
C.
