CrystaLatch
TM
1x8 Fiberoptic Switch
(Protected by U.S. patents 7224860，6757101，6577430 and pending patents)
Product Description
The CL Series 1x8 fiber optical switch connects optical channels by
redirecting an incoming optical signal into a selected output fiber.
This is achieved using patented non-mechanical configurations and
activated via an electrical control signal. Latching operation
preserves the selected optical path after the drive signal has been
removed. The all solid sate CL 1x8 fiberoptic switch features low
insertion loss, high extinction ratio, high channel isolation, and
extremely high reliability and repeatability. It is designed to meet
the most demanding switching requirements of continuous operation
without failure, longevity, operation under shock/vibration
environment and large temperature variations, and fast response
time.
The switch also has build-in Circulator
and isolator functions. Electronic driver
is available for this series of switches.
Features
•
High Speed
•
Non-Mechanical
•
High Reliability
•
Fail-Safe Latching
•
Low Insertion Loss
•
Rugged
•
Compact
•
Cost Effective
•
Direct Low Voltage Drive
Performance Specifications
CL Series 1x8 Switch
Operation Wavelength
2
1
Min
1520
1295
36
Typical
1550
1310
1.3
0.7
50
50
0.15
Max
1580
1325
2.5
1.0
200
5K
0.4
0.2
Unit
nm
nm
dB
dB
dB
µs
Hz
dB
ps
dB
V
o
C
mW
o
C
mm
Applications
•
•
•
•
•
•
Optical Signal Routing
Network Protection
Burst Switching
Configurable Add/Drop
Signal Monitoring
Instrumentation
Insertion Loss
Uniformity
Cross Talk
Switch Speed (Rise, Fall)
Repetition Rate
Polarization Dependent Loss
Polarization Mode Dispersion
Return Loss
2
Drive Voltage
Operating Temperature
3
Optical Power Handling
Storage Temperature
Switch type
Fiber Type
Package Dimension
1.
2.
3.
3
65
300
500
-40
85
Solid-State Latching
Corning SMF28
82.8L x 37.3W x 8.5H
50
2.5
-5
Agiltron can achieve same SPEC at L band
Exclude connectors
-40
o
C version is also available
15 Cabot Road, Woburn, MA 01801 Tel: (781) 9351200 Fax: (781) 935-2040
LASER COMPONENTS GmbH
www.agiltron.com
Werner-von-Siemens-Str. 15, 82140 Olching, Germany, Phone: +49 8142 2864 0, Fax: +49 8142 2864 11, info@lasercomponents.com
CrystaLatch
TM
1x8 Fiberoptic Switch
Electrical Driving Information
Each switching point is actuated by applying a voltage pulse. Applying one polarity pulse, one
light path will be connected and latched to the position. Applying a reversed polarity pulse,
another light path will be connected and latched to the position after pulse removed.
Parameter
Switch Voltage
Resistance
Pulse Duration
Minimum
2.5
15
0.1
Typical
18
1
Maximum
3
22
10
Unit
V
Ω
ms
Driving kit with RS232 and TTL interfaces and Windows
TM
GUI is available.
Mechanical Footprint Dimensions (Unit:mm)
Package Type 1
Ordering Information
Electric Driving Table
15 Cabot Road, Woburn, MA 01801 Tel: (781) 9351200 Fax: (781) 935-2040
Revision: 060-14
LASER COMPONENTS GmbH
www.agiltron.com
11-11-08
Werner-von-Siemens-Str. 15, 82140 Olching, Germany, Phone: +49 8142 2864 0, Fax: +49 8142 2864 11, info@lasercomponents.com
CrystaLatch
TM
1x8 Fiberoptic Switch
Mechanical Footprint Dimensions (Unit:mm)
Package Type 2
Ordering Information
CLSW-
Type
1x8=18
8x1=81
Wavelength
1310=3
1550=5
Special=0
Switch
Single stage=1
Dual Stage=2
Package
Package 1=1
Package 2=2
Fiber Type
SMF-28 =1
Special=0
Bare fiber=1
900
µ
m loose tube=3
Special=0
Fiber Length Connector
0.25m=1
0.5m=2
1.0m=3
Special=0
None=1
FC/PC=2
FC/APC=3
SC/PC=4
SC/APC=5
ST/PC=6
LC=7
Duplex LC=8
Special=0
0 /0 / V1 /
/
/
.pdf
15 Cabot Road, Woburn, MA 01801 Tel: (781) 9351200 Fax: (781) 935-2040
www.lasercomponents.com
www.agiltron.com
LASER COMPONENTS GmbH
Werner-von-Siemens-Str. 15, 82140 Olching, Germany, Phone: +49 8142 2864 0, Fax: +49 8142 2864 11, info@lasercomponents.com
