5mm Round Yellow & Yellow Green
LED
OSYGHC5B31A
■
Features
●
■
Outline
5.0
Dimension
High Luminous LEDs
5mm Round Standard Directivity
●
●
●
Water Clear Type
0.5+0.1
24.5MIN
20.5MIN
■
Applications
●
Toys
Games
Audio
Other Lighting
1.0
●
UV Resistant Epoxy
5.9
3
1.5MIN
8.7
Superior Weather-resistance
●
2
1
●
2.Common Cathode
1,3.Anode
Unit:mm
Tolerance:+0.3mm
●
2.54 2.54
3
2
1
■
Absolute
Maximum Rating
Item
Symbol
I
F
I
FP
V
R
P
D
Topr
Tstg
Tsol
(Ta=25℃)
Value
Yellow
30
100
5
78
-30~ +85
-40 ~ +100
260
℃
/5sec
■
Directivity
YG
30
100
5
78
Unit
mA
mA
V
mW
90°
1
0
30°
30°
DC Forward Current
Pulse Forward Current*
Reverse Voltage
Power Dissipation
Operating Temperature
Storage Temperature
Lead Soldering Temperature
*Pulse width Max.10ms
■
Electrical
60°
60°
0.5
0
0.5
1
90°
℃
℃
-
Duty ratio max 1/10
-Optical Characteristics
Symbol
V
F
(Yellow)
V
F
(YG)
I
R
λ
D
(Yellow)
λ
D
(YG)
(Ta=25℃)
Min.
1.8
1.8
-
585
565
1120
750
-
Item
DC Forward Voltage
DC Forward Voltage
DC Reverse Current
Domi. Wavelength*
Condition
I
F
=20mA
I
F
=20mA
V
R
=5V
I
F
=20mA
I
F
=20mA
I
F
=20mA
I
F
=20mA
I
F
=20mA
Typ.
2.1
2.1
-
590
570
1560
1100
30
Max.
2.6
2.6
10
595
575
Unit
V
V
µA
nm
nm
mcd
Luminous Intensity*
50% Power Angle
Iv
(Yellow)
Iv
(YG)
2θ
1/2
-
-
mcd
deg
*
1
Tolerance of dominant wavelength is +1nm
*
2
Tolerance of luminous intensity is +15%
