5x5x1.3mm Tops H Power Blue
LED
OSB5XATHC1E
■
Features
●
■
Outline
Dimension
Highest luminous flux
Super energy efficiency
Very long operating life (up to 100K hours)
Superior ESD protection
(2.5)
5.8
7.4
●
●
1
1.3
Anode(+)
●
●
■
Applications
●
Read lights (car, bus, aircraft)
Portable (flashlight, bicycle)
Bollards / Security / Garden
Traffic signaling / Beacons
In door / Out door Commercial lights
Automotive Ext
5
7.4
4.2
5
No UV
●
●
2.2
4.2
3°
3°
(2.9)
0~+0.07 Max
Back View
Cathode(-)
●
1.3
●
●
Unite:mm
Tolerance:±0.20
■
Absolute
Maximum Rating
Item
Symbol
I
F
I
FP
V
R
P
D
Topr
Tstg
Tsol
(Ta=25℃)
Value
200
250
5
800
-30 ~ +85
-40~ +100
260
℃
/5sec
■
Directivity
Unit
mA
mA
V
mW
0
DC Forward Current
Pulse Forward Current*
Reverse Voltage
Power Dissipation
Operating Temperature
Storage Temperature
Lead Soldering Temperature
0
℃
℃
-
*Pulse width Max.10ms Duty ratio max 1/10
■
Electrical
-Optical Characteristics
Symbol
V
F
I
R
λ
D
Φv
2θ
1/2
(Ta=25℃)
Min.
3.0
-
465
-
-
■
Forward
Operating Current (DC)
Item
DC Forward Voltage
DC Reverse Current
Domi. Wavelength
Luminous Flux
50% Power Angle
Condition
I
F
=150mA
V
R
=5V
I
F
=150mA
I
F
=150mA
I
F
=150mA
Typ.
3.3
-
470
6
120
Max.
4.0
10
475
10
-
Unit
Forward Current, I
F
(mA)
200
175
150
125
100
75
50
25
0
0
25
50
75
100
125
R
J-A
=70
℃
/W
R
J-A
=90
℃/
W
R
J-A
=110
℃
/W
V
µA
nm
lm
deg
Ambient Temperature, T
A
(
℃
)
Note: Don’t drive at rated current more than 5s without heat sink for Tops H emitter series.
LED & Application Technologies
VER A.0
