VER:03
1 / 2
•
1 WATT UNREGULATED OUTPUT POWER
•
SINGLE-IN-LINE PACKAGE (SIP)
•
HIGH EFFICIENCY FOR LOW POWER APPLICATION
•
UL 94-V0 NON-CONDUCTED CASE
•
INTERNAL INPUT & OUTPUT FILTER
•
INPUT / OUTPUT ISOLATION UP TO 3KVDC
•
SUFFIX-N ISOLATION LEVEL REINFORCE
The DU1P0 series are the standard building blocks for on-board distributed power
UL E193009
TUV R50025187
CB JPTUV-006003
CE MARK
systems. They are ideally suited to providing single and dual supplies on primarily
digital boards with added benefit of galvanic isolation to reduce switching noise. All of
the rated power may be drawn from a single pin provided the total load does not
exceed 1 watt.
T E C H N I C A L S P E C I F I C AT I O N
OUTPUT SPECIFICATIONS
Output power
Voltage accuracy
Minimum load (Note 1)
Line regulation
Load regulation
Ripple and noise
Temperature coefficient
Short circuit protection
LL to HL at Full Load
20% to 100% FL
20MHz bandwidth
5V output
others
Full load and nominal Vin
All specifications are typical at nominal input, full load and 25ºC otherwise noted
GENERAL SPECIFICATIONS
1 Watt max
± 5%
10% of FL
1.3% / 1% of Vin
± 10%
± 8%
100mVp-p
±0.1% / ºC, max
Short term
Efficiency
Isolation voltage
Isolation resistance
Isolation capacitance
Switching frequency
Approvals and standard
Case material
Base material
Potting material
Input to Output
Standard
Suffix-N
See table
1000VDC, min
3000VDC, min
10 ohms, min
30pF, max
60KHz, min
IEC60950, UL60950, EN60950
Non-conductive black plastic
None
Epoxy (UL94-V0)
0.77 X 0.24 X 0.40 Inch
(19.6 X 6.0 X 10.2 mm)
2.0g (0.071oz)
1.471 x 10 hrs
7
9
INPUT SPECIFICATIONS
Input voltage range
5V nominal input
12V nominal input
15V nominal input
24V nominal input
4.5 – 5.5VDC
10.8 – 13.2VDC
13.5 – 16.5VDC
21.6 – 26.4VDC
Capacitor
Dimensions
Weight
MTBF (Note 2)
Input filter
ENVIRONMENTAL SPECIFICATIONS
Operating temperature range
Storage temperature range
Thermal shock
Vibration
Relative humidity
-25ºC ~ +85ºC (with derating)
-55ºC ~ +105ºC
MIL-STD-810D
10~55Hz, 10G, 30minutes along X,Y and Z
5% to 95% RH
ELECTRONIC COMPONENTS
RSG
■
RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany
Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de
www.rsg-electronic.de
■
■
■
■
■
Änderungen vorbehalten / subject to change without notice
VER:03
Model
Number
DU1P0-05S05
DU1P0-05S12
DU1P0-05S15
DU1P0-05D05
DU1P0-05D12
DU1P0-05D15
DU1P0-12S05
DU1P0-12S12
DU1P0-12S15
DU1P0-12D05
DU1P0-12D12
DU1P0-12D15
DU1P0-15S05
DU1P0-15S12
DU1P0-15S15
DU1P0-15D05
DU1P0-15D12
DU1P0-15D15
DU1P0-24S05
DU1P0-24S12
DU1P0-24S15
DU1P0-24D05
DU1P0-24D12
DU1P0-24D15
2 / 2
Capacitor
Load max
(5)
6.2uF
6.2uF
6.2uF
3.0uF
3.0uF
3.0uF
6.2uF
6.2uF
6.2uF
3.0uF
3.0uF
3.0uF
6.2uF
6.2uF
6.2uF
3.0uF
3.0uF
3.0uF
6.2uF
6.2uF
6.2uF
3.0uF
3.0uF
3.0uF
Input
Range
4.5 – 5.5 VDC
4.5 – 5.5 VDC
4.5 – 5.5 VDC
4.5 – 5.5 VDC
4.5 – 5.5 VDC
4.5 – 5.5 VDC
10.8 – 13.2 VDC
10.8 – 13.2 VDC
10.8 – 13.2 VDC
10.8 – 13.2 VDC
10.8 – 13.2 VDC
10.8 – 13.2 VDC
13.5 – 16.5 VDC
13.5 – 16.5 VDC
13.5 – 16.5 VDC
13.5 – 16.5 VDC
13.5 – 16.5 VDC
13.5 – 16.5 VDC
21.6 – 26.4 VDC
21.6 – 26.4 VDC
21.6 – 26.4 VDC
21.6 – 26.4 VDC
21.6 – 26.4 VDC
21.6 – 26.4 VDC
Output
Voltage
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
Output
Current
200mA
83mA
67mA
± 100mA
± 42mA
± 33mA
200mA
83mA
67mA
± 100mA
± 42mA
± 33mA
200mA
83mA
67mA
± 100mA
± 42mA
± 33mA
200mA
83mA
67mA
± 100mA
± 42mA
± 33mA
Input
Current
(3)
274mA
255mA
261mA
270mA
258mA
257mA
114mA
106mA
112mA
114mA
109mA
106mA
97mA
89mA
88mA
94mA
88mA
87mA
61mA
56mA
57mA
59mA
57mA
55mA
Eff
(4)
(%)
77
82
81
78
82
81
77
82
79
77
81
82
73
79
80
75
80
80
72
78
78
75
78
79
0.77(19.6)
Note
1.
The DU1P0 series required a minimum 10% loading on the output to
maintain specified regulation. Operation under no-load condition will
not damage these devices, however they may not meet all listed
specification
BELLCORE TR-NWT-000332. Case 1: 50% Stress, Temperature at
40ºC. (Ground fixed and controlled environment).
Maximum value at nominal input voltage and full load of standard type.
Typical value at nominal input voltage and full load.
Test by minimum Vin and constant resistive load.
0.016(0.4)
FRONT VIEW
0.14(3.6)
0.40(10.2)
0.01x 0.02
( 0.25 x 0.5) Rectangular Pin
0.10(2.54)
0.20(5.08)
BOTTOM VIEW
2
4 5 6 7
2.
3.
4.
5.
0.085(2.16)
0.24(6.1)
1
0.053(1.35)
OUTPUT POWER (%)
DU1P0-24S05 Derating Curve
100
75
50
25
0
-40 -25 -10 0
50 60 70 80 90 100
All dimensions in inches(mm)
Tolerance : x.xx±0.02(x.x±0.5)
x.xxx±0.01(x.xx±0.25)
Pin pitch tolerance ±0.014(0.35)
STANDARD
PIN
1
2
4
5
6
SINGLE
+ INPUT
- INPUT
- OUTPUT
NC
+ OUTPUT
DUAL
+ INPUT
- INPUT
- OUTPUT
COMMON
+ OUTPUT
PIN
1
2
5
6
7
“N” Models
SINGLE
+ INPUT
- INPUT
DUAL
+ INPUT
- INPUT
Nature convection
AMBIENT TEMPERATURE (ºC)
- OUTPUT - OUTPUT
NC
COMMON
+ OUTPUT + OUTPUT
ELECTRONIC COMPONENTS
RSG
■
RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany
Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de
www.rsg-electronic.de
■
■
■
■
■
Änderungen vorbehalten / subject to change without notice
