CXOX OSCILLATOR
1 MHz to 160 MHz
®
Ultra-Miniature Surface Mount
High Frequency Crystal Oscillator
Actual Size
Top View
Side View
DESCRIPTION
Statek’s ultra miniature and ultra low profile CXOX oscillator
consists of a CMOS/TTL compatible hybrid circuit and a
state-of-the-art, miniature, fundamental-mode crystal.
DIMENSIONS
FEATURES
A
4
TOP
Designed for surface mount applications
CMOS and TTL compatible
Low power consumption
Full military testing available
High shock resistance
Optional Output Enable/Disable with Tri-State
Low EMI emission
Hermetically sealed ceramic package
Designed and manufactured in the USA
TYPICAL
DIM
A
B
inches
0.126
0.099
1
3
C
3
D
4
BOTTOM
E
B
2
2
1
MAXIMUM
inches
0.136
0.107
0.043
0.048
0.041
0.031
mm
3.40
2.70
1.09
1.21
1.10
0.85
mm
3.20
2.50
1.00
1.12
1.00
0.75
APPLICATIONS
0.039
C
(SM1)
C
(SM3/SM5)
0.044
D
E
0.040
0.030
Military & Aerospace
Long range missiles
Projectile electronics
Smart munitions
Communications
Navigation
GPS
Industrial, Computer & Communications
Miniature clock oscillator
Handheld instrumentation
PDA
Transponder/Animal migration
Medical
Test & diagnostic equipment
Handheld devices
PIN CONNECTIONS
1. Output Enable/Disable (E) or no connection (N)
2. Ground
3. Output
4. V
DD
SUGGESTED LAND PATTERN
0.141 (3.6)
0.110 (2.9)
0.031 (0.8)
0.039 (1.05)
0.051
(1.3)
0.039
(1.0)
10168 Rev A
S
YS
C
ERT
I
F
I
C
TEM
AT
inches (mm)
Distribution:
RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany
Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de
www.rsg-electronic.de
■
■
■
■
■
N
IO
Änderungen vorbehalten / subject to change without notice
01
Pb
IS
O
90
SPECIFICATIONS
ABSOLUTE MAXIMUM RATINGS
Specifications below are examples. Specifications are subject
to change without notice. Tighter specifications available.
Please contact factory.
Frequency Range
1
Supply Voltage
Calibration Tolerance
2
Frequency Stability
Over Temperature
3
+
_
100 ppm for Military
Supply Current (Typical)
24 MHz
32 MHz
50 MHz
130 MHz
Output Load (CMOS)
4
Start-up Time
Rise/Fall Time
Duty Cycle
5
Aging, first year
Shock, survival
6
Supply Voltage V
DD
-0.5 V to 7.0 V
Storage Temperature
-55
O
C to 125
O
C
Maximum Process Temperature 260
O
C for 20 seconds
1 MHz to 160 MHz
_
1.8 V to 5.0 V
+
10%
+
_
+
_
100 ppm
ENABLE/DISABLE OPTIONS (E/N)
50 ppm for Commercial
+
_
100 ppm for Industrial
1.8 V
1.5 mA
2.0 mA
3.0 mA
12.0 mA
15 pF
5 ms MAX
6 ns MAX
40% MIN 60% MAX
10 ppm MAX
5,000 g, 0.3 ms,
1
/
2
3.3 V
3.0 mA
5.0 mA
6.0 mA
23.0 mA
5.0 V
8.0 mA
10.0 mA
13.0 mA
39.0 mA
Statek offers two enable/disable options: E and N. The
E-version has a Tri-State output and stops oscillating
internally when the output is put into the high Z state.
The N-version does not have PIN 1 connected internally
and so has no enable/disable capability. The following
table describes the Enable/Disable option E.
ENABLE/DISABLE OPTION E
FUNCTION TABLE
Enable (Pin 1 High*) Disable (Pin 1 Low)
Output
Oscillator
Frequency Output
Oscillates
Normal
High Z State
Stops
Very Low
sine
Current
Vibration, survival
7
20 g, 10-2,000 Hz swept sine
*
When PIN 1 is allowed to float, it is held high by an internal pull-up resistor.
Operating Temp. Range -10
O
C to 70
O
C (Commerical)
-40
O
C to 85
O
C (Industrial)
-55
O
C to 125
O
C (Military)
PACKAGING OPTIONS
1.
2.
3.
4.
5.
6.
7.
Not all frequencies available at all voltages. Contact factory.
Other tolerances available.
Does not include calibration tolerances. Other tolerances available.
Higher CMOS loads and TTL loads available. Contact factory.
45/55 available upon request in most cases.
Higher shock levels available. Contact factory.
Per MIL-STD-202G, Method 204D, Condition D. Random vibration testing also
available.
Note: All parameters are measured at ambient temperature with a 10 MΩ, 15 pF load.
CXOX - Tray Pack
- 12 mm tape, 7” or 13” reels
Per EIA 481 (see Tape and Reel data sheet 10109)
HOW TO ORDER CXOX SURFACE MOUNT CRYSTAL OSCILLATORS
CXOX
4
Supply Voltage
1 = 1.8 V
2 = 2.5 V
3 = 3.0 V
4 = 3.3 V
5 = 5.0 V
S
“S” if special or
custom design.
Blank if Std.
N
Enable/Disable
Option
E or N
SM3
Terminations
Blank = SM1
= Gold Plated
(Lead Free)
SM3 = Solder Dipped
SM5 = Solder Dipped
(Lead Free)
40.0M ,
Frequency
K = kHz
M = MHz
100
Calibration
Tolerance
@ 25
0
C
(in ppm)
/
100
Frequency
Stability over
Temp.Range
(in ppm)
/
/
I
Temp. Range:
C = -10
O
C to +70
O
C
I
= -40
O
C to +85
O
C
M = -55
O
C to +125
O
C
S = Customer Specified
OR
/
/
200
Total
Frequency
Tolerance
(in ppm)
/
I
Temp. Range:
C = -10
O
C to +70
O
C
I
= -40
O
C to +85
O
C
M = -55
O
C to +125
O
C
S = Customer Specified
Distribution:
RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany
Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de
www.rsg-electronic.de
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
■
■
■
■
■
