SPU130 SERIES
130W Desk Top Switching Power Supplies For I.T.E.
Description:
The SPU130 series of AC/DC switching mode power
supplies provide 130 Watts of continuous output power. All
supplies are UL 94V-0 compliant, include IEC-320-C14
input for worldwide applications. All models meet FCC class
B and CISPR class B emission Limits and are designed to
comply with UL, C-UL and CE requirements. All units are
100% burned in and tested.
Features:
+
Wide Input Voltage 90 to 264 VAC,47 to 63 Hz
+
IEC-320-C14 Input Inlet
+
Output Voltage Available From 3 VDC Thru 55 VDC
+
Optional Output Connectors (See appendix)
+
Single and Dual Output
+
Input Surge Current, Over Voltage and Over Load
protection
+
One year warranty
Safety Approvals :
CB
Electrical Characteristics:
Sym.
Vin
Fin
Wo
Vo
Io
Iil
Iih
Irl
Irh
Eff
Parameter
Input Voltage
Input Frequency
Output Power Range
Output Voltage Range
Output Current Range
Input Current (Low Line)
Input Current (High Li ne)
Low Line Inrush Current
High Line Inrush Current
Efficiency
Test Conditions
Min. Typ. Max.
90
47
264
63
130
Unit
VAC
Hz
W
V
A
A
A
A
A
%
Vin=90 to 264VAC
0
See rating chart
See rating chart
Io=Full load, Vin=11 5VAC
Io=Full load, Vin=23 0 VAC
Io=Full load, 25°c ,Cool start,
Vin=115VAC
Io=Full load, 25°c, Cool start,
Vin=230VAC
Io=Full Load, Vin=23 0VAC
Io=Full Load
Vin=230VAC
112
110
Io=Full Load to Half Load, Vin=100VAC
Io=Full Load, Vin=10 0VAC
Io=Full Load, Vin=10 0VAC
Full Load, Vin=90VAC
Io=Full Load, Vin=24 0VAC
All output
Optional
-0.04
0.3
16
0.3
1
0.5
0.5
2
1
0.75
0.04
0.99
15
30
80
0.5
3
1
5
132
150
4
3.2
1.7
30
60
REG-i Line Regulation
REG-o Load Regulation
OVP
OCP
Ttr
Ts
Vrn
Ilk
Tc
PFC
Over Voltage Protection
Over Current Protection
Transient Response
Start Up Time
Ripple & Noise (Peak to Peak)
Safety Ground Leakage Current
Temperature Coefficient
Power Factor Correction
%
%
%
%
mS
mS
S
%
mA
%/°c
Thold Hold-Up Time
Environmental :
Sym.
Toper
Tstg
Hr
Pd
Parameter
Operating Temperature
Storage Temperature
Relative Humidity
Test Conditions
Min. Typ. Max.
0
-40
5
70
85
95
Unit
°c
°c
%
Derated From 100% at +50°c Linearly to 50% at 70
°c
SPU130 SERIES
130W Desk Top Switching Power Supplies For I.T.E.
Safety Specifications:
Sym.
Vps
Parameter
Test Conditions
Primary to secondary
Primary to ground
Test Voltage = 500VDC
Vin=220VAC
Vin=110VAC
Min. Typ. Max.
4242
2121
50
B
B
Unit
VDC
VDC
MW
CLASS
CLASS
Dielectric Withstanding Voltage
for Primary to secondary
Dielectric Withstanding
Vpg
Voltagefor Primary to ground
Isolation Resistance
Ri
CISPR
EMI requirements for CISPR-22
EMI requirements for FCC
FCC
PART-15
Output Voltage And Current Rating Chart ( Single Output ) :
Model Number
SPU130-101
SPU130-102
SPU130-103
SPU130-104
SPU130-105
SPU130-106
SPU130-107
SPU130-108
SPU130-109
SPU130-110
SPU130-111
SPU130-112
Output Voltage
03
05
06
08
11
13
16
21
27
33
40
50
~
~
~
~
~
~
~
~
~
~
~
~
05
06
08
11
13
16
21
27
33
40
50
55
VDC
VDC
VDC
VDC
VDC
VDC
VDC
VDC
VDC
VDC
VDC
VDC
Output Current
30.00
23.00
21.60
16.25
11.80
10.00
08.12
06.19
04.81
03.93
03.25
03.25
~
~
~
~
~
~
~
~
~
~
~
~
18.00
19.16
16.25
11.80
10.00
08.12
06.19
04.81
03.93
03.25
02.60
02.36
A
A
A
A
A
A
A
A
A
A
A
A
Total Regulation
7%
7%
7%
5%
5%
5%
5%
5%
5%
5%
5%
5%
Maximum
Output Power
90W
115W
130W
130W
130W
130W
130W
130W
130W
130W
130W
130W
Output Voltage And Current Rating Chart ( Multi Output ) :
Model
Number
SPU130-201
SPU130-202
SPU130-203
Output #1
20A
20A
20A
20A
5%
5%
5%
5%
+12V
+12V
+15V
+24V
Output #2
0.2A
0.2A
0.2A
0.1A
2.0A
2.0A
2.0A
2.0A
5%
5%
6%
5%
Output #3
Maximum
90W
120W
120W
120W
Vonom Iomin Iomax Regmax Vonom Iomin Iomax Regmax Vonom Iomin Iomax Regmax
Output Power
SPU130-200 +3.3V 0.5A
+5V
+5V
+5V
0.5A
0.5A
0.5A
Mechanical Specifications :
Note:
1. Dimensions are shown in mm.
2. Weight: 860gs approx.
3. Optional output connectors:
See page Appendix.
