X1G003901010413 datasheet, PDF

X1G003901010413: DescriptionClipped Sine Output Oscillator,; CategoryPassive components oscillator; File Size503KB，8 Pages; ManufacturerSeiko Epson Corporation

Download Datasheet Parametric Compare View All

X1G003901010413 Overview

Clipped Sine Output Oscillator,

Parameter Name	Attribute value
Maker	Seiko Epson Corporation
Reach Compliance Code	unknown
Other features	TR, 10 INCH
Ageing	0.5 PPM/FIRST YEAR
Frequency Adjustment - Mechanical	NO
frequency stability	0.28%
Installation features	SURFACE MOUNT
Nominal operating frequency	19.44 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Oscillator type	CLIPPED SINE
Output impedance	11000 Ω
Output level	0.8 V
physical size	7.0mm x 5.0mm x 1.5mm
Maximum supply voltage	3.465 V
Minimum supply voltage	3.135 V
Nominal supply voltage	3.3 V
surface mount	YES

Temperature Compensated Crystal Oscillator (TCXO)

Data sheet

MODEL

：

TG-5501CA-A4N 19.440000 MHz

Product. No.

：

X1G0039010104xx

Please refer to the 10.Packing information about xx (last 2 digits)

SEIKO EPSON CORPORATION

Pb free.

Complies with EU RoHS directive.

*About the products without the Pb-free mark.

Contains Pb in products exempted by EU RoHS directive.

(Contains Pb in sealing glass, high melting temperature type solder or other.)

INTRODUCTION

1. Any part of this material may not be reproduced or duplicated in any form or any means without the

written permission of Seiko Epson.

2. This sheet is not intended to guarantee or provide an approval of implementation of industrial patents.

	X1G003901010413	X1G003901010411
Description	Clipped Sine Output Oscillator,	Clipped Sine Output Oscillator,
Maker	Seiko Epson Corporation	Seiko Epson Corporation
Reach Compliance Code	unknown	unknown
Other features	TR, 10 INCH	TR, 10 INCH
Ageing	0.5 PPM/FIRST YEAR	0.5 PPM/FIRST YEAR
Frequency Adjustment - Mechanical	NO	NO
frequency stability	0.28%	0.28%
Installation features	SURFACE MOUNT	SURFACE MOUNT
Nominal operating frequency	19.44 MHz	19.44 MHz
Maximum operating temperature	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C
Oscillator type	CLIPPED SINE	CLIPPED SINE
Output impedance	11000 Ω	11000 Ω
Output level	0.8 V	0.8 V
physical size	7.0mm x 5.0mm x 1.5mm	7.0mm x 5.0mm x 1.5mm
Maximum supply voltage	3.465 V	3.465 V
Minimum supply voltage	3.135 V	3.135 V
Nominal supply voltage	3.3 V	3.3 V
surface mount	YES	YES
