Laser Diode Incorporated
High Power CW Laser
Diodes
0.5 - 7 Watts
High Efficiency Devices
Multiple Package Options
High reliability/Long Life
Applications:
Diode based medical systems
Diode pumped solid state
lasers
Analytical equipment
Illuminators
Reprographics
Laser initiated ordnance
Laser Diode Inc’s series of High Power CW products is offered with an output range from 0.5 Watts to 7.0
Watts. These devices have a standard wavelength of 805nm +/- 5nm with a spectral width of 2.5 nm FWHM.
Specifications and Limits @ 25
o
C
Common Characteristics
Peak Wavelength
Peak Wavelength Tolerance
Spectral Width (50% Points)
Rise/Fall Times
Far Field Beam Divergence
Efficiency at I
f
Operating Temperature
Storage Temperature
*Note: Other wavelength tolerances are available
Unit
nm
nm
nm
ns
deg
%
o
o
Min
Typ
805
+/-5
2.5
1.0
12 x 40
40
Max
C
C
-20
-40
+30
+85
Single Diode Lasers: Laser Characteristics
Laser Characteristics
Power
(watts)
CW
CW
CW
CW
CW
0500 Series
1000 Series
2000 Series
5000 Series
7000 Series
0.5
1.0
2.0
5.0
7.0
Source Size
(μm)
50
100
200
460
460
Typical Ith
(amps)
0.27
0.47
0.82
1.8
1.8
Max Current
(amps)
0.75
1.5
3.0
6.5
7.7
Typical V
f
(volts)
2.0
2.0
2.0
2.0
2.0
LDI Document #10-4400-0014 Rev. D 11/24/08
Package Drawings
Other package options available.
Products can be ordered directly from Laser Diode Incorporated or its representatives. When ordering, refer to the
information below. For a complete listing of representatives, visit our website at
www.laserdiode.com
CW
OUTPUT POWER
0500 = .5 Watt
1000 = 1 Watt
2000 = 2 Watt
5000 = 5 Watt
7000 = 7 Watt
CM =
HH =
HF =
90 =
PACKAGE**
C-Mount
High Heat Load
Pigtailed High Heat Load
9.0mm
XXXX -
XX -
XX
R
RoHS Indicator
OPTIONS *
OO = None
DO = Monitor Detector Only
TO = TEC Only
DT = TEC and Monitor Detector
*Connectorization Available
**Custom Packaging Available
NOTE:
Not all options are available for all packages. Please contact your Sales Representative.
Safety:
Caution: Laser light emitted
from any diode laser may be
harmful to the human eye.
Avoid looking directly into
the diode laser aperture when
the device is in operation.
Class 4 laser
ESD Caution:
Handle diode lasers with
extreme care to prevent
electrostatic discharge.
Follow ESD precautions
When handling devices.
Warranty:
Please refer to your product
purchase agreement for
complete details or check
with your Laser Diode sales
representative.
Notice:
Laser Diode Inc. reserves
the right to make changes
to the products or information
contained herein without notice.
Liability is assumed as a result
of their use or application.
LDI Document #10-4400-0014 Rev. D 11/24/08
