Global Connector Technology Ltd. - BC030: 1.0mm PITCH PIN HEADER, SINGLE ROW, THROUGH HOLE, HORIZONTAL
A
5
6
7
8
DIMENSIONS
CONTACTS
A
B
A
B
B
C
C
D
D
E
Ordering Grid
E
BC030
No. of Contacts
02 to 40
XX
X
XXXX
XXXX
XXXX
L
X
Packing Options
G = Plastic Box (Standard)
D = Tube
E = Tube with Cap
Insulator Material
L = LCP (Standard)
SPECIFICATIONS
规格
:
F
CURRENT RATING
电流额定值：
1 AMP
INSULATOR RESISTANCE
绝缘电阻值
: 1000 MEGOHMS MIN.
DIELECTRIC WITHSTANDING
耐电压：
AC 300 V
CONTACT RESISTANCE
接触电阻值：
20m
Ω
Max.
OPERATING TEMPERATURE
工½温度：
-40°C TO +105°C
CONTACT MATERIAL
端子物料：
COPPER ALLOY
Dimension C (1/100mm)
INSULATOR MATERIAL
绝缘½物料
:
G
STANDARD
标准物料
: POLYESTER
聚酯
, LCP, UL 94-V0
(Post Height)
Standard - 2.00mm = 0200
SOLDERING PROCESS
可焊性
:
or specify Dimension C
LCP (STANDARD
标准物料
) -
e.g. 2.50mm = 0250
IR REFLOW
回流焊
: 260°C for 10 sec.
Tol +/- 0.2mm
WAVE
波峰焊
: 250°C for 5-10 sec
MANUAL SOLDER
人工焊接
: 350°C for 3-5 sec
MATES WITH
配套之母座
(SUBJECT TO PIN LENGTH
在端子长度适合的条件下
):
BC065
BC070
BC075
H
By
DETAIL
REV
DATE
ASE
DRAWING
RELEASE
A
20/05/08
GG
SA
CHANGE TO SOLDER AMENDMENT TO
TEMP. INFORMATION PLATING OPTIONS
C
B
21/12/09
23/07/09
Contact Plating
A = Gold Flash All Over
C = Tin All Over
Standard = Gold Flash All Over
F
Dimension D (1/100mm)
(Top of Insulator to Pin Bend)
Standard - 1.40mm = 0140
or specify Dimension D
e.g. 2.50mm = 0250
Tol +/- 0.2mm
Dimension E (1/100mm)
(Tail Length)
Standard - 2.50mm = 0250
or specify Dimension E
e.g. 4.50mm = 0450
Tol +/- 0.2mm
G
Tolerances
(Except as noted)
Part Number:-
Date:-
Dimensions in mm
X.°± 5°
.X°± 3°
X.X ± 0.25
.XX°± 2°
X.XX ± 0.15
X.XXX ± 0.10 .XXX°± 1°
X. ± 0.30
Third Angle Projection
BC030
Description:-
20 MAY 08
1.0mm PITCH PIN HEADER, SINGLE ROW,
THROUGH HOLE, HORIZONTAL
GC
Scale
NTS
H
www.gct.co
Drawn by
ASE
E & OE
C
THIS DRAWING IS CONFIDENTIAL AND MUST NOT BE
COPIED OR DISCLOSED WITHOUT WRITTEN CONSENT
Revision
C
Material
See Note
Sheet No.
1/1
1
2
3
4
5
6
7
8
