NON-POLAR NETWORK (1kHz)
Tecate Group
TYPE RN/TN
FEATURES
• Designed for audio applications with three standard levels of dissipation factor.
• Excellent stability for temperature and frequency fluctuation.
PART NUMBERING
Part Number Example: RN-050/100M10X15F
RN
Type
-
050
Rated DC Voltage
/
100
Capacitance Code
(µF)*
M
Tolerance Code
10X15
Size
F
RoHs Compliant
* Capacitance Code: First two digits represent significant figures, third digit represents multiplier (number of zeros).
SPECIFICATIONS
Operating Temperature Range
Voltage Range
Capacitance Range
Capacitance Tolerance (20°C, 1kHz)
Maximum Dissipation Factor (20°C,
1kHz)
Maximum Leakage Current* (after 5
minutes)
Applicable Standards
Performance Characteristics
-40°C ~ +85°C.
50 & 100VNP.
0.47µF ~ 600µF.
±10%.
DF Code
Blank
DF %
0.03CV + 4µA, or less.
Characteristics of JIS C-5141.
After 1000 hours’ application of rated voltage, capacitors meet the characteristics
requirements mentioned below.
Load Life (105°C)
Capacitance Change
DF
Leakage Current
Shelf Life (105°C)
Within ±20% of initial value.
200% or less of initial specified value.
Initial specified value or less.
S
10
6
R
4
After leaving capacitors under no load for 1000 hours and applying voltage
according to JIS C-5102 4-3 they meet the specified value for load life
characteristics listed above.
DIMENSIONS
RADIAL LEAD TYPE DIMENSIONS (UNIT: mm)
D
dØ
P
α
8
0.5
3.5
1.0
10
13
0.6
5.0
5.0
1.5
1.5
13
5.0
1.5
16
18
0.8
7.5
7.5
1.5
1.5
22
10
2.0
AXIAL LEAD TYPE DIMENSIONS (UNIT: mm)
D
dØ
α
8
1.5
10
0.6
1.5
13
2.0
13
2.0
16
18
0.8
2.0
2.0
22
2.0
© Tecate Industries Phone: (619) 398-9700 Fax: (619) 398-9777 Web Site: www.tecategroup.com
Specifications and dimensions are subject to change without notice.
Please confirm technical specifications with Tecate Group before purchasing.
Tecate Industries
2006/09/08 Rev.01
NON-POLAR NETWORK (1kHz)
Tecate Group
10% DF
6% DF
Cap. (µF)
WVDC (SV)
Radial Leads (RN)
50 (63)
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
10 x 15
10 x 15
10 x 15
10 x 15
10 x 15
10 x 20
10 x 20
13 x 21
13 x 21
13 x 26
13 x 26
16 x 27
16 x 27
16 x 38
100 (125)
10 x 15
10 x 15
10 x 15
10 x 15
10 x 15
10 x 20
10 x 20
13 x 21
13 x 26
13 x 26
13 x 26
16 x 27
16 x 38
16 x 38
WVDC (SV)
Radial Leads (RN)
50 (63)
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
250
300
8 x 13
8 x 13
8 x 13
8 x 13
8 x 13
8 x 15
10 x 15
10 x 15
10 x 20
13 x 21
13 x 26
16 x 27
16 x 27
16 x 27
18 x 38
18 x 38
18 x 38
100 (125)
8 x 13
8 x 13
8 x 13
8 x 13
8 x 13
10 x 15
10 x 15
10 x 15
10 x 20
13 x 21
13 x 26
16 x 27
16 x 27
16 x 32
18 x 38
18 x 38
22 x 42
Axial Leads (TN)
50 (63)
8 x 17
8 x 17
8 x 17
8 x 17
8 x 17
8 x 19
8 x 19
10 x 19
10 x 24
13 x 27
13 x 32
16 x 34
16 x 34
16 x 34
18 x 44
18 x 44
18 x 44
100 (125)
8 x 17
8 x 17
8 x 17
8 x 19
8 x 19
10 x 19
10 x 19
10 x 19
10 x 24
13 x 27
13 x 32
16 x 34
16 x 34
16 x 38
18 x 44
18 x 44
22 x 44
TYPE RN/TN
CASE SIZE OF STANDARD PRODUCTS (STD TOLERANCE 10% @ 1KHZ) (DXL(mm))
Cap. (µF)
Axial Leads (TN)
50 (63)
10 x 19
10 x 19
10 x 19
10 x 19
10 x 19
10 x 24
10 x 24
13 x 27
13 x 27
13 x 32
13 x 32
16 x 34
16 x 34
16 x 42
100 (125)
10 x 19
10 x 19
10 x 19
10 x 19
10 x 19
10 x 24
10 x 24
13 x 27
13 x 32
13 x 32
13 x 32
16 x 34
16 x 42
18 x 44
4% DF
Cap. (µF)
WVDC (SV)
Radial Leads (RN)
50 (63)
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
13 x 21
13 x 21
13 x 21
13 x 26
13 x 26
13 x 26
13 x 26
13 x 26
13 x 26
16 x 27
16 x 27
16 x 32
16 x 38
100 (125)
13 x 21
13 x 21
13 x 21
13 x 26
13 x 26
13 x 26
13 x 26
13 x 26
13 x 26
16 x 27
16 x 27
16 x 32
16 x 38
Axial Leads (TN)
50 (63)
13 x 27
13 x 27
13 x 27
13 x 32
13 x 32
13 x 32
13 x 32
13 x 32
13 x 32
16 x 34
16 x 34
16 x 38
18 x 44
100 (125)
13 x 27
13 x 27
13 x 27
13 x 32
13 x 32
13 x 32
13 x 32
13 x 32
13 x 32
16 x 34
16 x 34
16 x 38
18 x 44
Due to the custom nature of audio components other capacitance
values or sizes are available, consult Factory or Area Representative.
© Tecate Industries Phone: (619) 398-9700 Fax: (619) 398-9777 Web Site: www.tecategroup.com
Specifications and dimensions are subject to change without notice.
Please confirm technical specifications with Tecate Group before purchasing.
Tecate Industries
2006/09/08 Rev.01
