JANHCC1N4614 - JANHCC1N4627
JANKCC1N4614 - JANKCC1N4627
Zener Diode Chip Series
Rev. V2
Features
•
0.5 W Capability with Proper Heat Sinking
•
Electrically Equivalent to 1N4614
-
1N4627
Die
Description
These 0.5 W zener chips are electrically equivalent
to the 1N4614
-
1N4627 series diodes. They are
compatible with all wire bonding and die attach
techniques with the exception of solder reflow.
These diodes are also available in commercial
versions using prefix CD.
Electrical Specifications: Zener Test Current = 250 µA, T
A
= +25°C
Zener Voltage
1
V
Z
@ 250 µA
Nominal
V
4614
4615
4616
4617
4618
4619
4620
4621
4622
4623
4624
4625
4626
4627
1.8
2.0
2.2
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
Zener Impedance
2
Z
ZT
@ 250 µA
Maximum
Ω
1200
1250
1300
1400
1500
1600
1650
1700
1650
1600
1550
1500
1400
1200
µA
3.5
2.5
2.0
1.0
0.5
0.4
3.5
3.5
2.5
2.0
5.0
5.0
5.0
5.0
Reverse Voltage
I
R
@ V
R
Maximum
V
1.0
1.0
1.0
1.0
1.0
1.0
1.5
2.0
2.0
2.0
3.0
3.0
4.0
5.0
Part #
1. Zener voltage range equals nominal voltage ±5% for “A” suffix. No suffix denotes ±10%, “C” suffix = ±2% and “D” suffix = ±1%.
2. Zener impedance is derived by superimposing on I
ZT
at 60 HZ RMS AC current equal to 10% of I
ZT
.
1
* Restrictions on Hazardous Substances, European Union Directive 2011/65/EU.
VPT Components and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.vptcomponents.com
for additional data sheets and product information.
For further information and support please visit:
info@vptcomponents.com
JANHCC1N4614 - JANHCC1N4627
JANKCC1N4614 - JANKCC1N4627
Zener Diode Chip Series
Rev. V2
Absolute Maximum Ratings
3,4
Forward Voltage
Operating Temperature
Storage Temperature
1.5 V @ 200 mA
-65°C
to +175°C
-65°C
to +175°C
Zener Impedance vs. Operating Current
3. Exceeding any one or combination of these limits may cause
permanent damage to this device.
4. VPT Components does not recommend sustained operation
near these survivability limits.
2
VPT Components and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.vptcomponents.com
for additional data sheets and product information.
For further information and support please visit:
info@vptcomponents.com
JANHCC1N4614 - JANHCC1N4627
JANKCC1N4614 - JANKCC1N4627
Zener Diode Chip Series
Rev. V2
VPT COMPONENTS. ALL RIGHTS RESERVED.
