JANHCC1N4614 - JANHCC1N4627
JANKCC1N4614 - JANKCC1N4627
Zener Diode Chip Series
Rev. V2
Features
•
0.5 W Capability with Proper Heat Sinking
•
Electrically Equivalent to 1N4614
-
1N4627
Die
Description
These 0.5 W zener chips are electrically equivalent
to the 1N4614
-
1N4627 series diodes. They are
compatible with all wire bonding and die attach
techniques with the exception of solder reflow.
These diodes are also available in commercial
versions using prefix CD.
Electrical Specifications: Zener Test Current = 250 µA, T
A
= +25°C
Zener Voltage
1
V
Z
@ 250 µA
Nominal
V
4614
4615
4616
4617
4618
4619
4620
4621
4622
4623
4624
4625
4626
4627
1.8
2.0
2.2
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
Zener Impedance
2
Z
ZT
@ 250 µA
Maximum
Ω
1200
1250
1300
1400
1500
1600
1650
1700
1650
1600
1550
1500
1400
1200
µA
3.5
2.5
2.0
1.0
0.5
0.4
3.5
3.5
2.5
2.0
5.0
5.0
5.0
5.0
Reverse Voltage
I
R
@ V
R
Maximum
V
1.0
1.0
1.0
1.0
1.0
1.0
1.5
2.0
2.0
2.0
3.0
3.0
4.0
5.0
Part #
1. Zener voltage range equals nominal voltage ±5% for “A” suffix. No suffix denotes ±10%, “C” suffix = ±2% and “D” suffix = ±1%.
2. Zener impedance is derived by superimposing on I
ZT
at 60 HZ RMS AC current equal to 10% of I
ZT
.
1
* Restrictions on Hazardous Substances, European Union Directive 2011/65/EU.
VPT Components and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.vptcomponents.com
for additional data sheets and product information.
For further information and support please visit:
info@vptcomponents.com
JANHCC1N4614 - JANHCC1N4627
JANKCC1N4614 - JANKCC1N4627
Zener Diode Chip Series
Rev. V2
Absolute Maximum Ratings
3,4
Forward Voltage
Operating Temperature
Storage Temperature
1.5 V @ 200 mA
-65°C
to +175°C
-65°C
to +175°C
Zener Impedance vs. Operating Current
3. Exceeding any one or combination of these limits may cause
permanent damage to this device.
4. VPT Components does not recommend sustained operation
near these survivability limits.
2
VPT Components and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.vptcomponents.com
for additional data sheets and product information.
For further information and support please visit:
info@vptcomponents.com
JANHCC1N4614 - JANHCC1N4627
JANKCC1N4614 - JANKCC1N4627
Zener Diode Chip Series
Rev. V2
VPT COMPONENTS. ALL RIGHTS RESERVED.
Information in this document is provided in connection with VPT Components products. These materials are provided by
VPT Components as a service to its customers and may be used for informational purposes only. Except as provided in VPT
Components Terms and Conditions of Sale for such products or in any separate agreement related to this document, VPT
Components assumes no liability whatsoever. VPT Components assumes no responsibility for errors or omissions in these
materials. VPT Components may make changes to specifications and product descriptions at any time, without notice. VPT
Components makes no commitment to update the information and shall have no responsibility whatsoever for conflicts or
incompatibilities arising from future changes to its specifications and product descriptions. No license, express or implied,
by estoppels or otherwise, to any intellectual property rights is granted by this document.
THESE MATERIALS ARE PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, RELATING TO
SALE AND/OR USE OF VPT COMPONENTS PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A
PARTICULAR PURPOSE, CONSEQUENTIAL OR INCIDENTAL DAMAGES, MERCHANTABILITY, OR INFRINGEMENT OF ANY PA-
TENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. VPT COMPONENTS FURTHER DOES NOT WARRANT THE
ACCURACY OR COMPLETENESS OF THE INFORMATION, TEXT, GRAPHICS OR OTHER ITEMS CON-TAINED WITHIN THESE
MATERIALS. VPT COMPONENTS SHALL NOT BE LIABLE FOR ANY SPECIAL, IN-DIRECT, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES, INCLUDING WITHOUT LIMITATION, LOST REVE-NUES OR LOST PROFITS, WHICH MAY RESULT FROM THE USE
OF THESE MATERIALS.
VPT Components products are not intended for use in medical, lifesaving or life sustaining applications. VPT Components
customers using or selling VPT Components products for use in such applications do so at their own risk and agree to fully
indemnify VPT Components for any damages resulting from such improper use or sale.
4
VPT Components and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.vptcomponents.com
for additional data sheets and product information.
For further information and support please visit:
info@vptcomponents.com
