JA11-300-48 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> JA11-300-48

JA11-300-48: DescriptionDC-DC Regulated Power Supply Module, 1 Output, 15W, Hybrid,; CategoryPower/power management The power supply circuit; File Size908KB，2 Pages; ManufacturerSemiconductor Circuits Inc; Environmental Compliance

Download Datasheet Parametric View All

JA11-300-48 Overview

DC-DC Regulated Power Supply Module, 1 Output, 15W, Hybrid,

JA11-300-48 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Semiconductor Circuits Inc
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	72 V
Minimum input voltage	20 V
Nominal input voltage	48 V
JESD-30 code	S-XDMA-P4
Maximum grid adjustment rate	0.25%
Maximum load regulation	0.25%
Number of functions	1
Output times	1
Number of terminals	4
Maximum operating temperature	71 °C
Minimum operating temperature	-25 °C
Maximum output voltage	5.05 V
Minimum output voltage	4.95 V
Nominal output voltage	5 V
Package body material	UNSPECIFIED
Package shape	SQUARE
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Protect	CURRENT
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Temperature level	COMMERCIAL EXTENDED
Terminal form	PIN/PEG
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	15 W
Fine-tuning/adjustable output	NO

Preview

Download Datasheet

View All

765432121098765432109876543210987654321

ENVIRONMENTAL

GENERAL

OUTPUT

INPUT

Ripple and Noise

Regulation:

Line

Load

Efficiency

I/O Isolation

Switching Frequency

Operating Temperature

Storage Temperature

Cooling

Short Circuit Protection

Temperature Coefficient

Voltage Tolerance

All specifications are typical at nominal line and full load at 25°C unless

otherwise noted and are subject to change without notice.

Filtering

Reverse Polarity Protected

Voltage Range

Remote On/Off Control

DP Series

JA/JP Series

Main

1.0%

2.0%

80-85% (typ)

500 Vdc

100khz (typ)

-25°C to +71°C No Derating

-25°C to +105°C

Free-air Convection

± 1% Main

± 3% Auxiliary

50mV pk-pk (Main)

100mV pk-pk (Aux)

Continuous Power Cycle

0.02% / °C

9-36Vdc

20-72Vdc

All Models

To Nominal Input Current

External Fuse Required

All Models

Aux

2.0%

6.0%

These units are ideally suited for

telecommunications and applications

having a widely varying input voltage

such as automotive test equipment,

process control, minicomputers and

geosurvey equipment.

Applications

he 15-Watt JA/JP series oper-

ates over an ultra wide range of

9-36 Vdc or 20-72 Vdc. Efficien-

cies of 80% are typical over varying

load conditions of 25% to 100%.

Additional features include input

reverse polarity protection, remote

on/off control, logic compatible with

CMOS or open collector TTL, short

circuit protection with auto restart,

overvoltage protection, and an operat-

ing temperature range of -25°C to

+71°C with no derating. Units are

packaged in a six-sided continuous

shielded case for EMI/RFI protection

and measure 2.0” x 2.0” x 0.40”.

Single/Dual/Triple Outputs

15 Watts

4:1 ultra wide input range

9-36 Vdc

20-72 Vdc

Remote shutdown

100kHz switching frequency

Continuous short circuit

protection

Six-sided shielding
