7.5 Watt
24 Pin DIL Package V
2:1 Input Range Metal Case
o Wide Input Range
o Pi Input Filter
o 300 kHz Switching Frequency
o Regulated Output
o Single & Dual Output
o Short Circuit Protection
o Standard 1500 VDC I/O-Isolation
MODEL NUMBER
7.5VRS12W3.3LC
7.5VRS12W5LC
7.5VRS12W12LC
7.5VRS12W15LC
7.5VRD12W5LC
7.5VRD12W12LC
7.5VRD12W15LC
7.5VRS24W3.3LC
7.5VRS24W5LC
7.5VRS24W12LC
7.5VRS24W15LC
7.5VRD24W5LC
7.5VRD24W12LC
7.5VRD24W15LC
7.5VRS48W3.3LC
7.5VRS48W5LC
7.5VRS48W12LC
7.5VRS48W15LC
7.5VRD48W5LC
7.5VRD48W12LC
7.5VRD48W15LC
last up-date 02.06.2010
INPUT VOLTAGE
OUTPUT
VOLTAGE
3.3VDC
5VDC
12VDC
OUTPUT
CURRENT
1500mA
1500mA
INPUT CURRENT
%EFF
NO LOAD
FULL LOAD
557mA
801mA
25mA
762mA
74
78
82
79
83
76
79
82
81
83
76
80
82
81
83
625mA
500mA
±750mA
±310mA
±250mA
1500mA
1500mA
20mA
625mA
381mA
500mA
±750mA
±310mA
±250mA
1500mA
1500mA
10mA
625mA
190mA
500mA
±750mA
±310mA
±250mA
15mA
188mA
193mA
136mA
195mA
25mA
377mA
386mA
271mA
396mA
30mA
753mA
791mA
9-18 VDC
15VDC
±5VDC
±12VDC
±15VDC
3.3VDC
5VDC
12VDC
18-36 VDC
15VDC
±5VDC
±12VDC
±15VDC
3.3VDC
5VDC
12VDC
36-72 VDC
15VDC
±5VDC
±12VDC
±15VDC
7.5 Watt - 24 Pin DIL - Package V - 2:1 Input Range - Metal Case
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
INPUT SPECIFICATIONS
Input Voltage Range
Input Filter
2/3
2:1
Pi Network
OUTPUT SPECIFICATIONS
Voltage Accuracy
Voltage Balance, Dual Output
Temperature Coefficient
Ripple & Noise 20MHz BW
Short Circuit Protection
Line Regulation
Load Regulation
Single
Dual
±2%max.
±1%max.
±0.05%/°C
100 mV p-p max.
Continuous
±0.2% max
±0.5% max.
±1.0% max.
Line Regulation measured from High Line to Low Line
Load Regulation Single Output measured from Full Load to 10% Load
Load Regulation Dual Output measured from Full Load to 1/4 Load
GENERAL SPECIFICATION
Efficiency
Isolation Voltage
Isolation Resistance
Switching Frequency
Operating Temperature Range
Storage Temperature Range
Case Temperature
Derating >+71°C
Recommended Reflow Soldering Pb-free*
Cooling
Dimensions
Case Material
MTBF (MIL-HDBK-217F)
*) We do not recommend vapor phase soldering!
see table
1500 VDC min.
1000 Mohms
300 kHz
-25°C to +71°C
-40°C to +100°C
100°C max.
-3.5%/°C
see diagram
Free-Air Convection
1.25x0.8x0.4 Inches (31.8x20.3x10.2 mm)
Black Coated Copper with Non-Conductive Base
1.090.000 hrs min.
M + R Multitronik GmbH
Kaninchenbergweg 78 • 23564 Lübeck • Germany
Tel. (+49) 0451 - 60 99 50 • Fax (+49) 0451 - 60 46 95
www.multitronik.com
info@multitronik.com
7.5 Watt - 24 Pin DIL - Package V - 2:1 Input Range - Metal Case
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
3/3
MECHANICAL SPECIFICATIONS
CASE "V"
PIN
1 & 24
2&3
5
9
10 & 15
11
12 & 13
14
*
PIN CONNECTIONS 1.500VDC
SINGLE
NO PIN
-INPUT
NO PIN
NC
NC
NC
NO PIN
+OUTPUT
-OUTPUT
+INPUT
DUAL
NO PIN
-INPUT
NO PIN
COMMON
NC
-OUTPUT
NO PIN
+OUTPUT
COMMON
+INPUT
16
22 & 23
DIAFRAMS
N O T I C E:
The information in this document has been carefully checked. However, no responsibility is assumed for inaccuracies!
Specifications can be changed without notice. The latest and most complete information can be found on our website.
M + R Multitronik GmbH
Kaninchenbergweg 78 • 23564 Lübeck • Germany
Tel. (+49) 0451 - 60 99 50 • Fax (+49) 0451 - 60 46 95
www.multitronik.com
info@multitronik.com
