F
E
D
C
B
A
3,3
+ 0,5
-0
3,2
`
0,2
7,5
`
0,3
(5:1)
D
D
15,6
`
0,3
13,06
`
0,3
10,52
`
0,3
67
+ 0,45
-
61,11
+ 0,13
- 0,12
52,5
+ 0,05
- 0,2
15,39
+ 0,36
- 0,4
0,31
7,98
`
0,3
0,17
6,13
+ 0,08
-
C
0,8
C
10°
n
0,65 (78x)
10,82
+ 0,05
- 0,2
METAL BRACKET
FIXING-PLATE
12,24
`
0,2
17,2 max.
164A18649X CONEC ABC
4-40 UNC
B
SEE NOTE 10
6,5
n
4
18 REF.
B
NOTES:
1. METALSHELLS: STEEL; min. 315µin TIN over 40-80µin NICKEL
2. INSULATORS: PBT GF UL 94 V-0; BLACK
3. CONTACTS: COPPER ALLOY
PLATING: 8µin HARD GOLD over min. 50µin NICKEL
4. METAL BRACKETS: STEEL; min. 320µin TIN over 80µin NICKEL
5. THREADED LOCKS: COPPER ALLOY; min. 200µin TIN over 80µin NICKEL
6. PCB-SNAPS: COPPER ALLOY; min. 200µin TIN over 80µin NICKEL
PCB-HOLE:
n
3,1
`
0,1mm; PCB THICKNESS: 1,6mm
7. FIXING-PLATE: PBT GF UL 94 V-0; BLACK
8. P.C.B. HOLE DRILLINGS ON SHEET 2
9. MAXIMUM TORQUE VALUE FOR THREAD: 6 in.LB
10. CONNECTOR IS PART MARKED: 164A18649X CONEC ABC
THIS DRAWING MAY NOT BE COPIED OR
REPRODUCED IN ANY WAY, AND MAY NOT
BE PASSED ON TO A THIRD PARTY WITHOUT
WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION # APPROVAL
CUSTOMER APPROVAL DATE:
DO NOT ALTER CAD DRAWING BY HAND
tolerance
dim. in mm
date
drawn
appd.
norm
d-old
R
scale:
material:
title:
2:1 (5:1)
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION
SEE NOTES
A
A
name
NAME:
TITLE:
22.06.09
23.06.09
Lehmenkühler
Fischer
D-SUB HD FEMALE 90°
78pos. 0.350inch
threaded lock, metal bracket, fixing-plate and snap
dwg no:
Inventor 10
DIN-
COMPANY NAME:
a
Origin
16K1A2495
part no:
A3
sh:
1
A
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION # APPROVAL
rev. description
D
date
name
C
164A18649X
F
E
B
F
E
D
C
B
A
D
D
61,11
+ 0,13
- 0,12
45,847
`
0,05
2,413
`
0,1
n
3,1
`
0,1
(2x)
22,924
`
0,1
7,631
`
0,03
C
1,207
`
0,1
1
C
8,78
`
0,1
+ 0,1
n
0,9
- 0
(78x)
P.C.B. EDGE
P.C.B. HOLE DRILLINGS
( P.C.B. TOP SIDE)
B
B
THIS DRAWING MAY NOT BE COPIED OR
REPRODUCED IN ANY WAY, AND MAY NOT
BE PASSED ON TO A THIRD PARTY WITHOUT
WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION # APPROVAL
CUSTOMER APPROVAL DATE:
DO NOT ALTER CAD DRAWING BY HAND
tolerance
dim. in mm
date
drawn
appd.
norm
d-old
R
scale:
material:
title:
3:1
SEE SHEET 1
A
A
name
NAME:
TITLE:
22.06.09
23.06.09
Lehmenkühler
Fischer
P.C.B. HOLE DRILLINGS
D-SUB HD FEMALE 90° 78pos. 0.350inch
threaded lock, metal bracket, fixing-plate and snap
dwg no:
Inventor 10
DIN-
COMPANY NAME:
2,54
`
0,1
2,54
`
0,1
A
13,04
a
Origin
16K1A2495
part no:
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION # APPROVAL
rev. description
D
date
name
C
SEE SHEET 1
F
E
B
2,54
`
0,1
A3
sh:
2
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION
