To order a OH200-61003CF with an output frequency of: 6.4 MHz = OH200-61003CF-006.4M
To order a OH200-61003CF with an output frequency of 16.384 MHz = OH200-61003CF-016.384M.
OH200-712005SV-040.0M = 1.1" x 1.4" x 0.5" CO-8 package, -20 to 70°C temperature range, ±10.0 ppb frequency stability, 5.0 Vdc supply
Bulletin
Page
Revision
Date
Cx193
1 of 4
12
19 Nov 2013
voltage, Sinewave output, voltage controlled output frequency VCOCXO, 40 MHz output frequency.
Attention: System Designers please review Application Note AN2093:
System Design Information and Printed Circuit Board Layout Guidelines for OCXO Oscillators.
@ www.conwin.com/technologies.html
2111 Comprehensive Drive
Aurora, Illinois 60505
Phone: 630- 851- 4722
Fax: 630- 851- 5040
www.conwin.com
Absolute Maximum Ratings
Parameter
Storage Temperature
Supply Voltage (Vcc)
Control Voltage (Vc)
Operating Supply Voltage 3.3 Vdc (Vcc)
Operating Supply Voltage 5.0 Vdc (Vcc)
Operating Supply Voltage 12 Vdc (Vcc)
Minimum
-55
-0.5
-0.5
3.13
4.75
11.40
Nominal
-
-
-
3.30
5.00
12.00
Maximum
125
13.5
7.0
3.47
5.25
12.60
Units
°C
Vdc
Vdc
Vdc
Vdc
Vdc
Notes
Absolute Ratings: Stresses beyond those listed under "absolute maximum ratings" may cause permanent damage to the device. These are stress ratings only. The functional
operation of the device at those or any other conditions beyond those indicated under "recommended operating conditions" is not implied. Exposure to conditions outside the
"recommended operating conditions" for any extended period of time may adversely impact device reliability and result in failures not covered by warranty.
Operating Specifications
Parameter
Center Frequency: (Fo)
Operating Temperature Range:
Temperature Code 5
Temperature Code 6
Temperature Code 7
Temperature Code 8
Frequency Calibration:
Frequency Stability vs. Change in Temperature:
Stability Code 06
Stability Code 10
Stability Code 20
Stability Code 50
Frequency Stability vs. Load
Frequency Stability vs. Voltage
Aging: Daily:
5 MHz to 20 MHz
>20 MHz to 40 MHz
Aging: First Year:
5 MHz to 20 MHz
>20 MHz to 40 MHz
Lifetime Tolerance: (20 Years)
5 MHz to 20 MHz-
>20 MHz to 40 MHz
Supply Voltage: (Vcc)
Voltage Code 03
Voltage Code 05
Voltage Code 12
Power Consumption: Turn-On
0 to 70°C Models
-20 to 70°C Models
-20 to 75°C Models
-40 to 85°C Models
Power Consumption: Steady State @ 25°C
0 to 70°C Models
-20 to 70°C Models
-20 to 75°C Models
-40 to 85°C Models
Phase Jitter: (BW: 10 Hz to Fo/2)
Models with Fo: 5 MHz to 20 MHz
Models with Fo: >20 MHz to 40 MHz
Short Term Allan Deviation (1s)
Start-Up Time:
Warm Up Time @ 25°C:
Minimum
5.0
0
-40
-20
-40
-0.1
-3.0
-5.0
-10.0
-25.0
-5.0
-5.0
-1.0
-2.0
-50
-100
-300
-500
3.13
4.75
11.40
-
-
-
-
-
-
-
-
-
-
-
-
-
Nominal
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
3.30
5.00
12.00
-
-
-
-
-
-
-
-
-
-
1.0E-11
-
-
Maximum
40.0
70
85
70
70
0.1
3.0
5.0
10.0
25.0
5.0
5.0
1.0
2.0
50
100
300
500
3.47
5.25
12.60
3.00
3.20
3.30
3.80
1.10
1.10
1.20
1.50
1.0
2.0
-
500
5
Units
MHz
°C
°C
°C
°C
ppm
ppb
ppb
ppb
ppb
ppb
ppb
ppb/day
ppb/day
ppb
ppb
ppb
ppb
Vdc
Vdc
Vdc
W
W
W
W
W
W
W
W
ps rms
ps rms
rms
ms
minutes
Notes
@ 25°C
1
1
1
1
±5%
±5%
2
2
3
3
4
4
4
5
5
5
5
5
5
5
5
6
Notes:
1. Frequency stability vs. change in temperature [±(Fmax-Fmin)/(2*Fo)].
2. At time of shipment after 48 hours of operation.
3. Inclusive of calibration, operating temperature, supply voltage change, load change and 20 years aging.
4. Supply voltage must reach Vcc levels monotonically within a ramp-up time of <12 ms.
5. Measured with Vcc = Nominal, in calm air.
6. Measured @ 25°C, within 5 minutes, referenced one hour after turn-on.
7. To ensure proper operation of VCOCXO, the control voltage input must be biased the nominal control voltage. Failure to bias
the Vc input will cause an unstable output condition.
Specifications subject to change without notification. See Connor-Winfield's website for latest revision. All dimensions in inches.
