SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSORS
SUPPRESSION
.012 (.305)
.006 (.152)
.128 (3.25)
.108 (2.75)
.245 (6.22)
.220 (5.59)
.103 (2.62)
.079 (2.00)
.050 (1.27)
.030 (0.76)
SMC/DO-214AB
Part Number
UNI
BI
1500W Transient Voltage Suppressor
1.5SMCJ5.0
1.5SMCJ5.0C
1.5SMCJ6.0
1.5SMCJ6.0C
1.5SMCJ6.5
1.5SMCJ6.5C
1.5SMCJ7.0
1.5SMCJ7.0C
1.5SMCJ7.5
1.5SMCJ7.5C
1.5SMCJ8.0
1.5SMCJ8.0C
1.5SMCJ8.5
1.5SMCJ8.5C
1.5SMCJ9.0
1.5SMCJ9.0C
1.5SMCJ10
1.5SMCJ10C
1.5SMCJ11
1.5SMCJ11C
1.5SMCJ12
1.5SMCJ12C
1.5SMCJ13
1.5SMCJ13C
1.5SMCJ14
1.5SMCJ14C
1.5SMCJ15
1.5SMCJ15C
1.5SMCJ16
1.5SMCJ16C
1.5SMCJ17
1.5SMCJ17C
1.5SMCJ18
1.5SMCJ18C
1.5SMCJ20
1.5SMCJ20C
1.5SMCJ22
1.5SMCJ22C
1.5SMCJ24
1.5SMCJ24C
1.5SMCJ26
1.5SMCJ26C
1.5SMCJ28
1.5SMCJ28C
1.5SMCJ30
1.5SMCJ30C
1.5SMCJ33
1.5SMCJ33C
1.5SMCJ36
1.5SMCJ36C
1.5SMCJ40
1.5SMCJ40C
1.5SMCJ43
1.5SMCJ43C
1.5SMCJ45
1.5SMCJ45C
1.5SMCJ48
1.5SMCJ48C
1.5SMCJ51
1.5SMCJ51C
1.5SMCJ54
1.5SMCJ54C
1.5SMCJ58
1.5SMCJ58C
1.5SMCJ60
1.5SMCJ60C
1.5SMCJ64
1.5SMCJ64C
1.5SMCJ70
1.5SMCJ70C
1.5SMCJ75
1.5SMCJ75C
1.5SMCJ78
1.5SMCJ78C
1.5SMCJ85
1.5SMCJ85C
1.5SMCJ90
1.5SMCJ90C
1.5SMCJ100
1.5SMCJ100C
1.5SMCJ110
1.5SMCJ110C
1.5SMCJ120
1.5SMCJ120C
1.5SMCJ130
1.5SMCJ130C
1.5SMCJ150
1.5SMCJ150C
1.5SMCJ160
1.5SMCJ160C
1.5SMCJ170
1.5SMCJ170C
1.5SMCJ180
1.5SMCJ180C
1.5SMCJ190
1.5SMCJ190C
1.5SMCJ200
1.5SMCJ200C
1.5SMCJ210
1.5SMCJ210C
1.5SMCJ220
1.5SMCJ220C
Inches (mm)
.280 (7.11)
.260 (6.60)
.320 (8.13)
.305 (7.75)
.008 (.203)
.002 (.051)
Reverse
Stand-Off Voltage
V
RWM
V
5.0
6.0
6.5
7.0
7.5
8.0
8.5
9.0
10
11
12
13
14
15
16
17
18
20
22
24
26
28
30
33
36
40
43
45
48
51
54
58
60
64
70
75
78
85
90
100
110
120
130
150
160
170
180
190
200
210
220
Breakdown Voltage
V
BR
@
IT
Min.
Max.
V
V
6.40
6.67
7.22
7.78
8.33
8.89
9.44
10.0
11.1
12.2
13.3
14.4
15.6
16.7
17.8
18.9
20.0
22.2
24.4
26.7
28.9
31.1
33.3
36.7
40.0
44.4
47.8
50.0
53.3
56.7
60.0
64.4
66.7
71.1
77.8
83.3
86.7
94.4
100
111
122
133
144
167
178
189
198
209
220
231
242
7.55
8.45
9.14
9.86
10.67
11.30
11.92
12.6
14.1
15.4
16.9
18.2
19.8
21.1
22.6
23.9
25.3
28.1
30.9
33.8
36.6
39.4
42.2
46.5
50.7
56.3
60.5
63.3
67.5
71.8
76.0
81.6
84.5
90.1
98.6
105.7
109.8
119.2
126.5
141.0
154.5
169.0
182.5
211.5
226.0
239.5
253.8
267.9
282.0
296.1
310.2
Test
Current
IT
mA
10
10
10
10
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Reverse Leakage
I
R
@
VRWM
UNI
BI
µ
A
µ
A
1000
1000
500
200
100
50
25
10
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
2000
2000
1000
400
200
100
50
20
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
Max. Clamp
Voltage
V
C
@
IPF
V
9.6
11.4
12.3
13.3
14.3
15.0
15.9
16.9
18.8
20.1
22.0
23.8
25.8
26.9
28.8
30.5
32.2
35.8
39.4
43.0
46.6
50.0
53.5
59.0
64.3
71.4
76.7
80.3
85.5
91.1
96.3
103
107
114
125
134
139
151
160
179
196
214
231
268
287
304
322
340
358
376
394
Peak Pulse
Current
I
PP
A
156.2
131.6
122.0
112.8
104.9
100.0
94.3
88.7
79.8
74.6
68.2
63.0
58.1
55.8
52.1
49.2
46.6
41.9
38.1
34.9
32.2
30.0
28.0
25.2
23.3
21.0
19.6
18.7
17.5
18.5
15.6
14.6
14.0
13.2
12.0
11.2
10.8
9.9
9.4
8.4
7.7
7.0
6.5
5.6
5.2
4.9
4.7
4.4
4.1
4.0
3.8
Package
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
SMC/DO-214AB
55
CKE
