Production specification
Schottky Barrier Rectifiers
Features
Metal silicon junction, majority carrier conduction
High surge capability
High temperature soldering guaranteed:
260°C/10 seconds
High current capability, low forward voltage drop
RoHS Compliant
Case: TO-277B molded plastic
Molding compound, UL flammability classification rating 94V-0
D12PS80L--D12PS100L
Top View
Bottom View
Mechanical Data
Terminals: Solder plated, solderable per MIL- STD-202,Method 208
Maximum Ratings
(@T
A
= 25°C unless otherwise specified)
Characteristic
Peak repetitive reverse voltage
RMS reverse voltage
DC blocking voltage
Maximum average forward output current
Peak forward surge current,
8.3ms single half-sine-wave
Symbol
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
D12PS80L
80
56
80
12
250
D12PS100L
100
70
100
Units
V
V
V
A
A
Thermal Characteristics
Parameter
Typical thermal resistance
(Note 1)
Operating junction temperature range
Storage temperature range
Symbol
R
ΘJA
R
ΘJC
R
ΘJL
T
J
T
STG
D12PS80L
60
20
15
- 55 ---- + 150
- 55 ---- + 150
°C
°C
°C /W
D12PS100L
Units
Note:
1. Device mounted on PCB with 10 mm x 20 mm x 0.1mm copper pad areas
T2B432AA
Rev.B
www.gmesemi.com
Production specification
Schottky Barrier Rectifiers
D12PS80L--D12PS100L
Electrical Characteristics
(@T
A
= 25°C unless otherwise specified)
Parameter
Maximum instantaneous
forward voltage(Note 1)
Maximum Reverse current
(Note 2)
@T
J
=25°C
I
R
Rated V
R
,
@T
J
=100°C
--
10
mA
--
250
μA
Symbol
V
F
I
F
=12A
Test
conditions
@T
A
=25°C
Typ.
--
Max.
0.7
Units
V
Note:
1.Pulse test: 300us pulse width, 1 % duty cycle
2.Pulse test: Pulse width 40ms
T2B432AA
Rev.B
www.gmesemi.com
Production specification
Schottky Barrier Rectifiers
D12PS80L--D12PS100L
Ratings and Characteristic Curves
(T
A
=25°C unless otherwise noted)
Fig.1-Forward Current Derating Curve
I
FSM
,Peak Forward Surge Current (A)
0
25
50
75
100
125
Lead Temperature (°C)
150
12
Fig.2- Surge Current Derating Curve
250
200
150
100
50
0
1
10
Number of Cycles at 60H
Z
100
Average Current (A)
9
6
3
0
Fig.3- Typical Forward Voltage Characteristic
100
Forward Current I
F
(A)
Fig.4- Typical Reverse Characteristic
10000
Tj=125℃
Tj=125℃
10
Reverse Current ,I
R
(μ A)
1000
Tj=25℃
=
100
℃
Tj
=
100
℃
Tj
100
Tj=75℃
1
Tj=75℃
10
Tj=25℃
0.1
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
Forward Voltage ,V
F
(V)
1
10
20
30
40
50
60
70
80
90 100
Reverse Voltage ,V
R
(%)
T2B432AA
Rev.B
www.gmesemi.com
