Production specification
Schottky Bridge Rectifiers
Features
Metal silicon junction, majority carrier conduction
High surge capability
High temperature soldering guaranteed:
260°C/10 seconds
High current capability, low forward voltage drop
Guarding for over voltage protection
RoHS Compliant
Case: MBF molded plastic
Molding compound, UL flammability classification rating 94V-0
MBFH32S--MBFH34S
Mechanical Data
Terminals: Matte tin plated leads, solderable perJ-STD-002 and JESD22-B102
Polarity indicator: As marked on body
Maximum Ratings
(@T
A
= 25°C unless otherwise specified)
Characteristic
Peak repetitive reverse voltage
RMS reverse voltage
DC blocking voltage
Maximum average forward output current
Peak forward surge current,
8.3ms single half-sine-wave
Symbol
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
MBFH32S
20
14
20
MBFH33S
30
21
30
3.0
80
MBFH34S
40
28
40
Units
V
V
V
A
A
Thermal Characteristics
Parameter
Typical thermal resistance Per Diode
(Note 1)
Operating junction temperature range
Storage temperature range
Symbol
R
R
R
ΘJA
ΘJC
ΘJL
MBFH32S
MBFH33S
72
31
15
- 55 ---- + 150
- 55 ---- + 150
MBFH34S
Units
°C /W
T
J
T
STG
°C
°C
Note:
1. Device mounted on PCB with 10 mm x 20 mm x 0.1mm copper pad areas
MBF714AA
Rev.B
www.gmesemi.com
Production specification
Schottky Bridge Rectifiers
MBFH32S--MBFH34S
Electrical Characteristics
(@T
A
= 25°C unless otherwise specified)
Parameter
Maximum instantaneous
forward voltage(Note 1)
Maximum Reverse current
(Note 2)
I
R
Symbol
V
F
Test
I
F
=3.0A
Per Diode
Rated V
R
,
Per Diode
conditions
@T
A
=25°C
@T
J
=25°C
@T
J
=100°C
Typ.
--
--
--
Max.
0.55
250
15
Units
V
μA
mA
Note:
1.Pulse test: 300us pulse width, 1 % duty cycle
2.Pulse test: Pulse width 40ms
MBF714AA
Rev.B
www.gmesemi.com
Production specification
Schottky Bridge Rectifiers
Fig.1-Forward Current Derating Curve
I
FSM
,Peak Forward Surge Current (A)
3
2.5
Average Current (A)
2
1.5
1
0.5
0
0
25
50
75
100
125
150
MBFH32S--MBFH34S
Ratings and Characteristic Curves
(T
A
=25°C unless otherwise noted)
Fig.2- Surge Current Derating Curve
80
60
40
20
0
1
10
Number of Cycles at 60H
Z
100
Lead Temperature (°C)
Fig.3- Typical Forward Voltage Characteristic
10
Forward Current I
F
(A)
Fig.4- Typical Reverse Characteristic
10000
Tj=125℃
Reverse Current ,I
R
(μ A)
Tj=25℃
1
1000
Tj=125℃
=
100
℃
Tj
Tj=75℃
100
Tj=75℃
=
100
℃
Tj
10
Tj=25℃
0.1
0.1
0.2
0.3 0.4 0.5 0.6
Forward Voltage ,V
F
(V)
0.7
0.8
1
10
20
30
40
50
60
70
80
90 100
Reverse Voltage ,V
R
(%)
MBF714AA
Rev.B
www.gmesemi.com
