50602130021D Overview

Barrier Strip Terminal Block,

50602130021D Parametric

Parameter Name	Attribute value
Maker	PTR Messtechnik GmbH & Co. KG
Reach Compliance Code	compliant
Terminal and terminal strip types	BARRIER STRIP TERMINAL BLOCK

Preview

Download Datasheet

View All

Lift |

Spacing 3.81 mm

AKZ602/..-3.81-V-GREEN

Technical Data

Wire sizes

Solid min

Solid max

Stranded (flexible) min

Stranded (flexible) max

Stranded with Ferrule min

Stranded with Ferrule max

0.14 mm²

1.5 mm²

0.14mm²

1.0 mm²

0.25 mm²

0.5 mm²

Order Data (Spacing 3.81 mm)

Insulating Material

Material

Flammability Class

PA 6.6

7.62

11.43

15.24

19.05

22.86

26.67

30.48

34.29

38.10

41.91

45.72

49.53

53.34

57.15

60.96

AKZ602/2-3.81-V-GREEN

AKZ602/3-3.81-V-GREEN

AKZ602/4-3.81-V-GREEN

AKZ602/5-3.81-V-GREEN

AKZ602/6-3.81-V-GREEN

AKZ602/7-3.81-V-GREEN

AKZ602/8-3.81-V-GREEN

AKZ602/9-3.81-V-GREEN

AKZ602/10-3.81-V-GREEN

AKZ602/11-3.81-V-GREEN

AKZ602/12-3.81-V-GREEN

AKZ602/13-3.81-V-GREEN

AKZ602/14-3.81-V-GREEN

AKZ602/15-3.81-V-GREEN

AKZ602/16-3.81-V-GREEN

Poles

Width (mm)

Article Designation

Article

Number

50602020021 F

50602030021 F

50602040021 F

50602050021 F

50602060021 E

50602070021 E

50602080021 E

50602090021 E

50602100021 D

50602110021 D

50602120021 D

50602130021 D

50602140021 D

50602150021 D

50602160021 D

200

100

UL 94 V-0

Temperatures

Operating Temperature

(without mech. load)

Store Temperature

-40 °C - 105 °C

Dimensions

Stripped Length

PCB Hole Diameter

5.0 mm

1.1 mm

Wave Soldering Process

Soldering Temperature,

recommended

Peak Soldering Time,

recommended

260 °C

3-4 s

Materials

Clamp

Screw

Solder Tab

Brass

Bronze

Copper

Alloy

Reflow Process

Soldering Temperature,

recommended

Peak Soldering Time,

recommended

Colours

GREEN, RAL 6018

LIGHT GREEN, similar RAL 6018

Colours according to RAL, there may be variations on colour due to production conditions. Special

colours on request.

Accessoires

Figure

Designation

Bridge, 2-pole, insulated,

BRI/2-7.0/7.62-L7.5-LIGHT GREY

Article Number

Order Data:

50000000018

Bridge, 2-pole, angled,

BR/2-3.5/3.81-H-L4.7

Order Data:

50000000019

Bridge, 2-pole, BR/2-3.5/3.81-L4.7

Order Data:

50000000013

Bridge, 3-pole, BR/3-3.5/3.81-L4.7

Order Data:

50000000014

Ratings

UseGroup

Rated Voltage

Rated Current

Rated Wire Size

- solid

- stranded

Torque

Screw Size

Test Voltage

300 V

10 A

min

130 V

13.5 A

max

1.0 mm²

0.20 Nm

1.25 kV

AWG 30-16

0.25 Nm

1.60 kV

0.5 mm²

PTR HARTMANN GmbH

• Gewerbehof 38 • 59368 Werne / Germany

Telefon: +49 (0)2389/7988-0 •

E-Mail: info@ptr-hartmann.com

www.ptr.eu
